name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
pdp1	dec/pdp1.cpp		no	no	no	yes	PDP-1	1961	Digital Equipment Corporation

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	896	672	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	yes	no

chip

type	tag	name	clock
cpu	maincpu	DEC PDP-1 Central Processor	1000000

softwarelist

tag	name	status	filter
ptp_list	pdp1_ptp	original

device_ref

name
pdp1_cpu
screen
crt
pdp1_readtape_image
pdp1_punchtape_image_device
pdp1_typewriter_image
pdp1_cylinder_image
gfxdecode
palette
software_list

sound

channels
0

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
punchtape	readt	pdp1_ptp			punchtape1	ptap1
punchtape	punch				punchtape2	ptap2
printout	typewriter				printout	prin
cylinder	drum				cylinder	cyln

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
punchtape	readt	pdp1_ptp			tap, rim
punchtape	punch				tap, rim
printout	typewriter				typ
cylinder	drum				drm

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	2	no
trackball	1			no	0	255	100
keyboard	1	99		no
joy	2	3	2	no

port, analog

port_tag	analog_masks
:CFG
:CSW
:LIGHTPEN
:LIGHTX	255
:LIGHTY	255
:SENSE
:SPACEWAR
:TSTADD
:TWDLSB
:TWDMSB
:TWR.0
:TWR.1
:TWR.2
:TWR.3

dipswitch

RAM size

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RAM size	CFG	3

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4kw	0	no
32kw	1	no
64kw	2	yes

Hardware multiply

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hardware multiply	CFG	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Hardware divide

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hardware divide	CFG	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Type 20 sequence break system

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type 20 sequence break system	CFG	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	16	no

Type 32 light pen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type 32 light pen	CFG	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	32	no

Sense Switch 6

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Sense Switch 6	SENSE	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Sense Switch 5

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Sense Switch 5	SENSE	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	2	yes

Sense Switch 4

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Sense Switch 4	SENSE	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Sense Switch 3

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Sense Switch 3	SENSE	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Sense Switch 2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Sense Switch 2	SENSE	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	16	no

Sense Switch 1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Sense Switch 1	SENSE	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	32	no
