Power Drift (Japan, Rev C) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
pdriftj	sega/segaybd.cpp		no	no	no	yes	Power Drift (Japan, Rev C)	1988	Sega	pdrift	pdrift

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	60.000000	5376240	342	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
epr-11746a.25	131072	b0f1caf4	1d7e70e740ef513728a72ff6e7b1c4b78e3cb0d5	maincpu	0	good	no
epr-11745a.24	131072	a89720cd	a0393546797f124e1c03bd12945dc6358bb94ba9	maincpu	1	good	no
epr-11748.27	131072	82a76cab	f8d3fe059e18896cd0e64711f1a3ee8b6372b4e0	maincpu	40000	good	no	epr-11748.27
epr-11747.26	131072	9796ece5	f84f5689c2edc0853ff173ce20f93f89758b2f31	maincpu	40001	good	no	epr-11747.26
epr-11752.81	131072	b6bb8111	475ce4e3d92747a9012a0ab03838ece61f6d33e0	subx	0	good	no
epr-11751.80	131072	7f0d0311	7917be201ff44c6b895fc8e9e296e8b1ecf8d639	subx	1	good	no
epr-11750c.54	131072	4e0f4fcb	fdb8ab8d5b015f5fbc89d254859755b78929c7d0	suby	0	good	no
epr-11749c.53	131072	603921f7	5100fd96e2cfa1e2699b6a1ffc2839ef5c8e9282	suby	1	good	no
epr-11485.ic27	32768	069b4201	7a9a87aef17cb65bc5b03ca9dea4d2d5cdda228a	drive_board	0	good	no	epr-11485.ic27
epr-11789.16	131072	b86f8d2b	a053f2021841fd0ef89fd3f28050a698b36c435e	bsprites	0	good	no	epr-11789.16
epr-11791.14	131072	36b2910a	9948b91837f944a7a606542fa685525e74bbe398	bsprites	1	good	no	epr-11791.14
epr-11790.17	131072	2a564e66	5f30fc15bfd017d75cfffe1e9e62ed0bcf32a98e	bsprites	40000	good	no	epr-11790.17
epr-11792.15	131072	c85caf6e	2411ea99ec7f6e2b0b4f219e86ff2172539ad2c4	bsprites	40001	good	no	epr-11792.15
epr-11757.67	131072	e46dc478	baf79e230aef3d63fb50373b2b1626f7c56ee94f	ysprites	0	good	no	epr-11757.67
epr-11758.75	131072	5b435c87	6b42b08e73957c36cd8faa896ca14461d00afd29	ysprites	1	good	no	epr-11758.75
epr-11773.63	131072	1b5d5758	54f58a274740a0566e0553d145c0c284ffd1d36b	ysprites	2	good	no	epr-11773.63
epr-11774.71	131072	2ca0c170	7de74c045bf084659ba70da9458d720125ff25ae	ysprites	3	good	no	epr-11774.71
epr-11759.86	131072	ac8111f6	6412716dc97ae697b438d9c9cd554d1087416bc2	ysprites	4	good	no	epr-11759.86
epr-11760.114	131072	91282af9	fddee7982949b7da724c7830e7bd139aeb84672d	ysprites	5	good	no	epr-11760.114
epr-11775.82	131072	48225793	ee003c2ea24c14e0968da94bac139735660932fe	ysprites	6	good	no	epr-11775.82
epr-11776.110	131072	78c46198	d299e631843da47cb7a46103d52a3dabfab71746	ysprites	7	good	no	epr-11776.110
epr-11761.66	131072	baa5d065	56dc71814e3f0f327781b0c1587038351c60f7b7	ysprites	100000	good	no	epr-11761.66
epr-11762.74	131072	1d1af7a5	86c02565b5aca201588c98678fb0c54faa8d4d6b	ysprites	100001	good	no	epr-11762.74
epr-11777.62	131072	9662dd32	454ec914b6c936f692bf90d2232c8169acec470a	ysprites	100002	good	no	epr-11777.62
epr-11778.70	131072	2dfb7494	4b9f1609e425c5e634e95dbc2d0ca820dd9212bc	ysprites	100003	good	no	epr-11778.70
epr-11763.85	131072	1ee23407	776c868e0e4e601fd6d0a83561b064b4be0560e2	ysprites	100004	good	no	epr-11763.85
epr-11764.113	131072	e859305e	aafcc3209a4fb6e0e8169ae6cce386b370b824f7	ysprites	100005	good	no	epr-11764.113
epr-11779.81	131072	a49cd793	efe77949be39a2ff88b50bfb2b4664b9267d9a09	ysprites	100006	good	no	epr-11779.81
epr-11780.109	131072	d514ed81	fbac3ad085363972a79e77aebb7fdae2200e7cda	ysprites	100007	good	no	epr-11780.109
epr-11765.65	131072	649e2dff	a6c61b71d08b31a0ca175ab0404e2eaf1d09ccc2	ysprites	200000	good	no	epr-11765.65
epr-11766.73	131072	d92fb7fc	2f5c2d88ae0766351b9efe8ffcbebc88fc3a6c59	ysprites	200001	good	no	epr-11766.73
epr-11781.61	131072	9692d4cd	967351ba2c781ca865e3c1ee9eeef1aad2247c27	ysprites	200002	good	no	epr-11781.61
epr-11782.69	131072	c913bb43	9bc15a3180cf4c3134bb55e99e6092f0faf95c56	ysprites	200003	good	no	epr-11782.69
epr-11767.84	131072	1f8ad054	289f5795116ee29540f28e35c3b4f72adeca7891	ysprites	200004	good	no	epr-11767.84
epr-11768.112	131072	db2c4053	a5b6daa6deb7afb0019e289acb81c82d507ec93a	ysprites	200005	good	no	epr-11768.112
epr-11783.80	131072	6d189007	dd871ea3166fdcb59d49707d35dde8b6c7fdc76b	ysprites	200006	good	no	epr-11783.80
epr-11784.108	131072	57f5fd64	6aff54d3f3f76ce0f1a93485d1a35a3987d456d9	ysprites	200007	good	no	epr-11784.108
epr-11769.64	131072	28f0ab51	d7cb7b83e5d85eb59d34cfd5c0d8e6c7ff81e24c	ysprites	300000	good	no	epr-11769.64
epr-11770.72	131072	d7557ea9	62430505d399ee2cc0f94e03144860056345573c	ysprites	300001	good	no	epr-11770.72
epr-11785.60	131072	e6ef32c4	869ba3816f5e3125f613f3b284fec74cd19db79e	ysprites	300002	good	no	epr-11785.60
epr-11786.68	131072	2066b49d	905ce70c921043d07591422a87fedd6e897ff38e	ysprites	300003	good	no	epr-11786.68
epr-11771.83	131072	67635618	f690ace026130ecb95532c92f2ad3741d0d167c1	ysprites	300004	good	no	epr-11771.83
epr-11772.111	131072	0f798d3a	71565ce28b93ae50d64af8c965fba6408a07f031	ysprites	300005	good	no	epr-11772.111
epr-11787.79	131072	e631dc12	3fd6db2eb297890b35dec566b6a90fc2d96bd085	ysprites	300006	good	no	epr-11787.79
epr-11788.107	131072	8464c66e	af93cbcc50acbd929d0298fb9a75da0369e13ff7	ysprites	300007	good	no	epr-11788.107
epr-11753.ic102	65536	e81f5748	dea9425ddc0f9411b1446477b7fdd3c92a1d4742	soundcpu	0	good	no
epr-11894.ic107	262144	b1e573f2	e566dc49b8f2002ca8d72a813856a272e0c9a9ac	pcm	0	good	no
epr-11893.ic106	262144	58b40f19	20a06928392d0e612a5e764d4eb1492070afe526	pcm	80000	good	no
epr-11892.ic105	262144	3248a758	e6fc3a7b2356ef017f59858f8b37eef5d92f54a2	pcm	100000	good	no
epr-11895.ic1	131072	ee99a6fd	4444826e751d9186e6d46b081e47cd99ee3cf853	user1	0	good	no	epr-11895.ic1
epr-11896.ic2	131072	4bebc015	307022ea1c1ee87c9ef3782526888c48c3c69fd2	user1	0	good	no	epr-11896.ic2
epr-11897.ic3	131072	4463cb95	e86fd4611cf83fe72d59950a60fc8c3a7381a1c7	user1	0	good	no	epr-11897.ic3
epr-11898.ic4	131072	5d19d767	d335cd3ef57c75e388df04b04fc3e2881a3902cf	user1	0	good	no	epr-11898.ic4

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000 (Musashi)	12500000
cpu	subx	Motorola MC68000 (Musashi)	12500000
cpu	suby	Motorola MC68000 (Musashi)	12500000
cpu	soundcpu	Zilog Z80	4026987
audio	speaker	Speaker
audio	ymsnd	YM2151 OPM	4026987
audio	pcm	Sega PCM	4026987

device_ref

name
m68000msh
m68000msh
m68000msh
z80
nvram
mb3773
315_5296
msm6253
sega_315_5248
sega_315_5248
sega_315_5248
sega_315_5249
sega_315_5249
sega_315_5249
screen
gfxdecode
sega_sys16b_sprite
sega_yboard_sprite
segaic16_video
palette
speaker
generic_latch_8
ym2151
segapcm

sound

channels
1

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
paddle		1		no	32	224	100	4
pedal				no	0	255	100	20

port, analog

port_tag	analog_masks
:ADC.3	255
:ADC.4	255
:ADC.5	255
:COINAGE
:DSW
:GENERAL
:LIMITSW
:P1

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	COINAGE	15

location

name	number	inverted
SWA	1	no
SWA	2	no
SWA	3	no
SWA	4	no

value

name	value	default
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	COINAGE	240

location

name	number	inverted
SWA	5	no
SWA	6	no
SWA	7	no
SWA	8	no

value

name	value	default
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSW	3

location

name	number	inverted
SWB	1	no
SWB	2	no

value

name	value	default
Moving	3	no
Upright/Sit Down	2	yes
Mini Upright	1	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	4

location

name	number	inverted
SWB	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	no
On	0	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	8

location

name	number	inverted
SWB	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Initial Credit

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Initial Credit	DSW	16

location

name	number	inverted
SWB	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	0	yes
2	16	no

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	DSW	32

location

name	number	inverted
SWB	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	32	yes

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW	192

location

name	number	inverted
SWB	7	no
SWB	8	no

value

name	value	default
Easy	128	no
Normal	192	yes
Hard	64	no
Hardest	0	no
