Pocket Gal Deluxe (Japan v3.00) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
pktgaldxj	dataeast/pktgaldx.cpp		no	no	no	yes	Pocket Gal Deluxe (Japan v3.00)	1993	Data East Corporation (Nihon System license)	pktgaldx	pktgaldx

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	240	58.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
kg00-2.12a	524288	62dc4137	23887dc3f6e7c4cdcb1bf4f4c87fe3cbe8cdbe69	maincpu	0	good	no
maz-02.2h	1048576	c9d35a59	07b44c7d7d76b668b4d6ca5672bd1c2910228e68	tiles	0	good	no	maz-02.2h
maz-00.1b	524288	fa3071f4	72e7d920e9ca94f8cb166007a9e9e5426a201af8	sprites	0	good	no	maz-00.1b
maz-01.3b	524288	4934fe21	b852249f59906d69d32160ebaf9b4781193227e4	sprites	80000	good	no	maz-01.3b
ke01.14f	131072	8a106263	229ab17403c2b8f4e89a90a8cda2f3c3a4b55d9e	oki1	0	good	no	ke01.14f
maz-03.13f	1048576	a313c964	4a3664c4e2c44a017a0ab6a6d4361799cbda57b5	oki2	0	good	no	maz-03.13f

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	14000000
audio	mono	Speaker
audio	oki1	OKI MSM6295 ADPCM	1006875
audio	oki2	OKI MSM6295 ADPCM	2013750

device_ref

name
m68000
screen
palette
gfxdecode
deco16ic
decospr
deco104
speaker
okim6295
okim6295

sound

channels
1

input

players	coins	service	tilt
2	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	3	8	no

port, analog

port_tag	analog_masks
:DSW
:INPUTS
:SYSTEM

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW	7

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3 Coins/1 Credit	0	no
2 Coins/1 Credit	1	no
1 Coin/1 Credit	7	yes
1 Coin/2 Credits	6	no
1 Coin/3 Credits	5	no
1 Coin/4 Credits	4	no
1 Coin/5 Credits	3	no
1 Coin/6 Credits	2	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW	56

location

name	number	inverted
SW1	4	no
SW1	5	no
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3 Coins/1 Credit	0	no
2 Coins/1 Credit	8	no
1 Coin/1 Credit	56	yes
1 Coin/2 Credits	48	no
1 Coin/3 Credits	40	no
1 Coin/4 Credits	32	no
1 Coin/5 Credits	24	no
1 Coin/6 Credits	16	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

2 Coins to Start, 1 to Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2 Coins to Start, 1 to Continue	DSW	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSW	768

location

name	number	inverted
SW2	1	no
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2	0	no
3	256	no
4	768	yes
5	512	no

Time

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Time	DSW	3072

location

name	number	inverted
SW2	3	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
60	0	no
80	1024	no
100	3072	yes
120	2048	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	4096

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4096	yes
On	0	no

Free Play

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free Play	DSW	8192

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8192	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW	16384

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16384	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW	32768

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32768	no
On	0	yes
