PN-8800FXB - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
pn8800	brother/pn8800fxb.cpp		no	no	no	yes	PN-8800FXB	1996	Brother

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	lcd	0	640	200	70.230000	8989440	640	0	640	200	0	200	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
uc8254-a-pn88.5	1048576	d9601c1a	1699714befeaf2fe17232c1b4f49d4242f5367f4	maincpu	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80180	12288000
audio	mono	Speaker
audio	buzzer	Beep	4000
audio	fdc:0:35hd:flopsndout	Speaker
audio	fdc:0:35hd:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
floppy_list	brother_pn	original

device_ref

name
z80180
z180asci_channel_0
z180asci_channel_1
z180csio
timer
screen
palette
gfxdecode
speaker
beep
hd63266f
floppy_connector
floppy_35_hd
speaker
flopsnd
output_latch
centronics
tc8521
software_list

sound

channels
2

feature

type	status	overall
graphics	imperfect

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	fdc:0:35hd	floppy_3_5			floppydisk	flop

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	fdc:0:35hd	floppy_3_5			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, ima, img, ufi, 360, ipf

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		58		no

port, analog

port_tag	analog_masks
:KO0
:KO1
:KO2
:KO3
:KO4
:KO5
:KO6
:KO7
:KO8
:misc
:power

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
fdc:0	35hd	floppy_35_hd	yes
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	no

configuration

AC Adaptor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
AC Adaptor	misc	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Good	0	yes
Not Good	4	no

Li Battery

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Li Battery	power	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Good	0	yes
Not Good	1	no

NiCd Battery

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
NiCd Battery	power	6

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Good	0	yes
Low	2	no
Not Good	4	no
