Mahjong Pon Chin Kan (Japan set 1) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ponchin	seta/srmp2.cpp		no	no	no	yes	Mahjong Pon Chin Kan (Japan set 1)	1991	Visco

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	384	240	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
um2_1_1.u22	131072	cf88efbb	7bd2304d365524fc5bcf3fb30752f5efec73a9f5	maincpu	0	good	no
um2_1_3.u42	131072	e053458f	db4a34589a08d0252d700144a6260a0f6c4e8e30	maincpu	1	good	no
um2_1_2.u29	131072	5c2f9bcf	e2880123373653c7e5d85fb957474e1c5774640d	maincpu	40000	good	no
um2_1_4.u44	131072	2ad4e0c7	ca97b825af41f86ebbfc2cf88faafb240c4058d1	maincpu	40001	good	no
x0-005_258.bin	2048			mcu1	0	nodump	no
um2_1_8.u55	524288	f74a8cb3	d1bf712f7ef97a96fc251c7729b39e9f10aab45d	gfx1	0	good	no
um2_1_7.u43	524288	1e87ca84	5ddbfd92d6ed1947a3c35f3e93cbcca5059fa1f9	gfx1	1	good	no
um2_1_6.u28	524288	b11e85a7	02971b45791d06f88efbae8e0713d28105faf341	gfx1	200000	good	no
um2_1_5.u20	524288	a5469d11	7e96af23c8434c32f87be1482309999d6a7b33bb	gfx1	200001	good	no
um2_1_9.u56	524288	9165c79a	854e30fc6121f7b3e5e1e5b6772757a92b63aef8	adpcm	0	good	no
um2_1_10.u63	524288	53e643e9	3b221217e8f846ae96a9a47149037cea19d97549	adpcm	80000	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
audio	mono	Speaker
audio	aysnd	AY-3-8910A PSG	1000000
audio	msm	OKI MSM5205 ADPCM	384000

device_ref

name
m68000
nvram
x1_001
screen
palette
speaker
ay8910
msm5205

sound

channels
1

input

players	coins	service	tilt
2	1	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mahjong	1	26		no
mahjong	2	26		no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:DSW3-1
:DSW3-2
:KEY0
:KEY1
:KEY2
:KEY3
:KEY4
:KEY5
:KEY6
:KEY7
:SERVICE
:SYSTEM

dipswitch

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW1	7

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 (Easy)	6	no
2	5	no
3	4	no
4	7	yes
5	3	no
6	2	no
7	1	no
8 (Hard)	0	no

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	DSW1	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Player Score

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Player Score	DSW1	48

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1000	48	yes
2000	32	no
3000	0	no

Debug Mode (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug Mode (Cheat)	DSW1	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Auto Tsumo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto Tsumo	DSW1	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	128	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW2	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSW2	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright	0	yes
Cocktail	2	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW2	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	no
On	0	yes

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW2	48

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3 Coins/1 Credit	0	no
2 Coins/1 Credit	16	no
1 Coin/1 Credit	48	yes
1 Coin/2 Credits	32	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW2	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Free Play

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Free Play	DSW2	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Debug 0 (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug 0 (Cheat)	DSW3-1	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Debug 1 (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug 1 (Cheat)	DSW3-1	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Debug 2 (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug 2 (Cheat)	DSW3-1	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Debug 3 (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug 3 (Cheat)	DSW3-1	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Debug 4 (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug 4 (Cheat)	DSW3-2	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Debug 5 (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug 5 (Cheat)	DSW3-2	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Debug 6 (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug 6 (Cheat)	DSW3-2	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Debug 7 (Cheat)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Debug 7 (Cheat)	DSW3-2	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no
