Puzzli (revision B) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
puzzli	metro/metro.cpp		no	no	no	yes	Puzzli (revision B)	1995	Metro / Banpresto

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	58.232800								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
pz_jb5.20e	131072	33bbbd28	41a98cfbdd60a638e4aa08f15f1730a2436106f9	maincpu	0	good	no
pz_jb6.20c	131072	e0bdea18	9941a2cd88d7a3c1a640f837d9f34c39ba643ee5	maincpu	1	good	no
pz_jb8.3i	131072	c652da32	907eba5103373ca6204f9d62c426ccdeef0a3791	audiocpu	0	good	no
pz_jb2.14i	524288	0c0997d4	922d8553ef505f65238e5cc77b45861a80022d75	vdp2	0	good	no
pz_jb4.18i	524288	576bc5c2	08c10e0a3356ee1f79b78eff92395d8b18e43485	vdp2	2	good	no
pz_jb1.12i	524288	29f01eb3	1a56f0b8efb599ae4f3cd0a4f0b6a6152ea6b117	vdp2	4	good	no
pz_jb3.16i	524288	6753e282	49d092543db34f2cb54697897790df12ca3eda74	vdp2	6	good	no
pz_jb7.3g	262144	b3aab610	9bcf1f98e19a7e26b22e152313dfbd43c882f008	oki	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	16000000
cpu	audiocpu	NEC uPD78C10	12000000
audio	mono	Speaker
audio	ymsnd	YM2151 OPM	3579545
audio	oki	OKI MSM6295 ADPCM	1200000

device_ref

name
m68000
upd78c10
i4220
palette
buffered_spriteram16
screen
speaker
ym2151
okim6295
timer

sound

channels
1

feature

type	status	overall
graphics	imperfect

input

players	coins	service	tilt
2	2	no	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	2	8	no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:DSW0
:IN0
:IN1
:IN2

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSW0	7

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	1	no
3 Coins/1 Credit	2	no
2 Coins/1 Credit	3	no
1 Coin/1 Credit	7	yes
1 Coin/2 Credits	6	no
1 Coin/3 Credits	5	no
1 Coin/4 Credits	4	no
Free Play	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSW0	56

location

name	number	inverted
SW1	4	no
SW1	5	no
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	8	no
3 Coins/1 Credit	16	no
2 Coins/1 Credit	24	no
1 Coin/1 Credit	56	yes
1 Coin/2 Credits	48	no
1 Coin/3 Credits	40	no
1 Coin/4 Credits	32	no
Free Play	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW0	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSW0	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW0	768

location

name	number	inverted
SW2	1	no
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	512	no
Normal	768	yes
Hard	0	no

Join In

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Join In	DSW0	1024

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1024	yes

2 Players Game

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2 Players Game	DSW0	2048

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Credit	0	no
2 Credits	2048	yes

Winning Rounds (Player VS Player)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Winning Rounds (Player VS Player)	DSW0	4096

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1/1	0	no
2/3	4096	yes

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	DSW0	8192

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8192	yes

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW0	16384

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	16384	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSW0	32768

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32768	yes
On	0	no
