QX-10 - mame (0277) machine

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	romof	cloneof
qx10	epson/qx10.cpp		no	no	no	yes	QX-10	1983	Epson

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	640	400	45.408486	16670000	872	152	792	421	4	404	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	status	optional	bios
ipl006.bin	2048	3155056a	67cc0ae5055d472aa42eb40cddff6da69ffc6553	maincpu	good	no	v006
ipl003.bin	2048	3cbc4008	cc8c7d1aa0cca8f9753d40698b2dc6802fd5f890	maincpu	good	no	v003
qga.2e	4096	4120b128	9b96f6d78cfd402f8aec7c063ffb70a21b78eff0	chargen	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	3993600
cpu	8237dma_1	AM9517A	3993600
cpu	8237dma_2	AM9517A	3993600
cpu	kbd:qx10_hasci:mcu	Intel 8049	11000000
audio	upd765:0:525dd:flopsndout	Speaker
audio	upd765:0:525dd:floppysound	Floppy sound	44100
audio	upd765:1:525dd:flopsndout	Speaker
audio	upd765:1:525dd:floppysound	Floppy sound	44100
audio	mono	Speaker
audio	speaker	Filtered DAC

softwarelist

tag	name	status	filter
flop_list	qx10_flop	original

device_ref

name
z80
screen
gfxdecode
palette
pit8253
pit_counter
pit_counter
pit_counter
pit8253
pit_counter
pit_counter
pit_counter
pic8259
pic8259
upd7201
i8274_channel
i8274_channel
am9517a
am9517a
i8255
upd7220
mc146818
upd765a
floppy_connector
floppy_525_dd
speaker
flopsnd
floppy_connector
floppy_525_dd
speaker
flopsnd
rs232
epson_qx_kbd
qx10_keyboard_hasci
i8049
output_latch
centronics
speaker
speaker_sound_device
ram
epson_qx_option_bus
epson_qx_option_slot
epson_qx_option_slot
epson_qx_option_slot
epson_qx_option_slot
epson_qx_option_slot
software_list
quickload

biosset

name	description	default
v006	v0.06	no
v003	v0.03	no

sound

channels
3

ramoption

name	default
256K	yes

device, instance

type	tag	interface	name	briefname
floppydisk	upd765:0:525dd	floppy_5_25	floppydisk1	flop1
floppydisk	upd765:1:525dd	floppy_5_25	floppydisk2	flop2
quickload	quickload		quickload	quik

device, extension

type	tag	interface	extension_names
floppydisk	upd765:0:525dd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	upd765:1:525dd	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
quickload	quickload		com, cpm

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		104		no

port, analog

port_tag	analog_masks
:CONFIG
:DSW
:kbd:qx10_hasci:LINE0
:kbd:qx10_hasci:LINE1
:kbd:qx10_hasci:LINE2
:kbd:qx10_hasci:LINE3
:kbd:qx10_hasci:LINE4
:kbd:qx10_hasci:LINE5
:kbd:qx10_hasci:LINE6
:kbd:qx10_hasci:LINE7
:kbd:qx10_hasci:LINE8
:kbd:qx10_hasci:LINE9
:kbd:qx10_hasci:LINEA
:kbd:qx10_hasci:LINEB
:kbd:qx10_hasci:LINEC
:kbd:qx10_hasci:LINED
:kbd:qx10_hasci:LINEE
:kbd:qx10_hasci:LINEF

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
upd765:0	525dd	floppy_525_dd	yes
upd765:1	525dd	floppy_525_dd	yes
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	rs_printer	rs_serial_printer	no
kbd	qx10_ascii	qx10_keyboard_ascii	no
kbd	qx10_hasci	qx10_keyboard_hasci	yes
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	no
option1	ym2149	epson_qx_option_sound_card	no
option1	multifont	epson_qx_option_multifont	no
option1	ide	epson_qx_option_ide	no
option1	cr1510	epson_qx_option_cr1510	no
option1	cqgmem	epson_qx_option_cqgmem	no
option2	ym2149	epson_qx_option_sound_card	no
option2	multifont	epson_qx_option_multifont	no
option2	ide	epson_qx_option_ide	no
option2	cr1510	epson_qx_option_cr1510	no
option2	cqgmem	epson_qx_option_cqgmem	no
option3	ym2149	epson_qx_option_sound_card	no
option3	multifont	epson_qx_option_multifont	no
option3	ide	epson_qx_option_ide	no
option3	cr1510	epson_qx_option_cr1510	no
option3	cqgmem	epson_qx_option_cqgmem	no
option4	ym2149	epson_qx_option_sound_card	no
option4	multifont	epson_qx_option_multifont	no
option4	ide	epson_qx_option_ide	no
option4	cr1510	epson_qx_option_cr1510	no
option4	cqgmem	epson_qx_option_cqgmem	no
option5	ym2149	epson_qx_option_sound_card	no
option5	multifont	epson_qx_option_multifont	no
option5	ide	epson_qx_option_ide	no
option5	cr1510	epson_qx_option_cr1510	no
option5	cqgmem	epson_qx_option_cqgmem	no

configuration

Video Board

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Video Board	CONFIG	3

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Monochrome	2	yes
Color	1	no

dipswitch

DSW

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DSW	DSW	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	no
On	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	no
On	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	no
On	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	no
On	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
