Racing Hero (bootleg of FD1094 317-0144 set) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
racherod	sega/segaxbd.cpp		no	no	no	yes	Racing Hero (bootleg of FD1094 317-0144 set)	1989	bootleg	rachero	rachero

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
mainpcb:screen	raster	0	320	224	59.637405	6250000	400	0	320	262	0	224	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
bootleg_epr-13129.ic58	131072	82ee7312	4d011529b538885bbc3bb1cb23048b785d3be318	mainpcb:maincpu	0	good	no
bootleg_epr-13130.ic63	131072	53fb8649	8b66d6e2018f92c7c992944ed5d4a685d9f13a6d	mainpcb:maincpu	1	good	no
epr-12855.ic57	131072	cecf1e73	3f8631379f32dbfda7720ef345276f9be23ada06	mainpcb:maincpu	40000	good	no	epr-12855.ic57
epr-12856.ic62	131072	da900ebb	595ed65248185ddf8666b3f30ad6329162116448	mainpcb:maincpu	40001	good	no	epr-12856.ic62
epr-12857.ic20	131072	8a2328cc	c34498428ddfb3eeb986f4153a6165a685d8fc8a	mainpcb:subcpu	0	good	no	epr-12857.ic20
epr-12858.ic29	131072	38a248b7	a17672123665403c1c56fedab6c8abf44b1131f9	mainpcb:subcpu	1	good	no	epr-12858.ic29
epr-12879.ic154	65536	c1a9de7a	2425456a9d4ba92e1f2da6c2f164a6d5a5dee7c7	mainpcb:gfx1	0	good	no	epr-12879.ic154
epr-12880.ic153	65536	27ff04a5	b554a6e060f4803100be8efa52977b503eb0f31d	mainpcb:gfx1	10000	good	no	epr-12880.ic153
epr-12881.ic152	65536	72f14491	b7a6cbd08470a5edda77cdd0337abd502c4905fd	mainpcb:gfx1	20000	good	no	epr-12881.ic152
epr-12872.ic90	131072	68d56139	b5f32edbda10c31d52f90defea2bae226676069f	mainpcb:sprites	0	good	no	epr-12872.ic90
epr-12873.ic94	131072	3d3ec450	ac96ad8c7b365478bd1e5826a073e242f1208247	mainpcb:sprites	1	good	no	epr-12873.ic94
epr-12874.ic98	131072	7d6bde23	88b12ec6386cdad60b0028b72033a0037a0cdbdb	mainpcb:sprites	2	good	no	epr-12874.ic98
epr-12875.ic102	131072	e33092bf	31e211e25adac0a98befb459093f23c905fbc1e6	mainpcb:sprites	3	good	no	epr-12875.ic102
epr-12868.ic91	131072	96289583	4d37e67860bc0e6ef69f0a0775c28f6f2fd6875e	mainpcb:sprites	80000	good	no	epr-12868.ic91
epr-12869.ic95	131072	2ef0de02	11ee3d77df2cddd3156da52e50565505f95f4cd4	mainpcb:sprites	80001	good	no	epr-12869.ic95
epr-12870.ic99	131072	c76630e1	7b76e4819990e147639d6b930b17b6fa10df191c	mainpcb:sprites	80002	good	no	epr-12870.ic99
epr-12871.ic103	131072	23401b1a	eaf465ffda84bdb83cc85daf781275bada396aab	mainpcb:sprites	80003	good	no	epr-12871.ic103
epr-12864.ic92	131072	77d6cff4	1e625204801d03369311844efb26d22216253ac4	mainpcb:sprites	100000	good	no	epr-12864.ic92
epr-12865.ic96	131072	1e7e685b	532fe361357383aa9dada833cbe31716c58001e5	mainpcb:sprites	100001	good	no	epr-12865.ic96
epr-12866.ic100	131072	fdf31329	9c229a0f9d8b8114acfe4f17b45a9b8640560b3e	mainpcb:sprites	100002	good	no	epr-12866.ic100
epr-12867.ic104	131072	b25e37fd	fef5bfe4690b3203b83fd565d883b2c63f439633	mainpcb:sprites	100003	good	no	epr-12867.ic104
epr-12860.ic93	131072	86b64119	d39aedad0f05e500e33af888126bd2fc22539141	mainpcb:sprites	180000	good	no	epr-12860.ic93
epr-12861.ic97	131072	bccff19b	32c3f7802a12be02a114b78cd898c46fcb1c0a61	mainpcb:sprites	180001	good	no	epr-12861.ic97
epr-12862.ic101	131072	7d4c3b05	4e25a077b403549c681c5047912d0e28f4c07720	mainpcb:sprites	180002	good	no	epr-12862.ic101
epr-12863.ic105	131072	85095053	f93194ecc0300956280cc0515b3e3ba2c9f71364	mainpcb:sprites	180003	good	no	epr-12863.ic105
epr-12859.ic17	65536	d57881da	75b7f331ea8c2e33d6236e0c8fc8dabe5eef8160	mainpcb:soundcpu	0	good	no	epr-12859.ic17
epr-12876.ic11	131072	f72a34a0	28f7d077c24352557da3a91a7e49b0c5b79f2a2e	mainpcb:pcm	0	good	no	epr-12876.ic11
epr-12877.ic12	131072	18c1b6d2	860cbb96999ab76c40ce96996bba70c42d845abc	mainpcb:pcm	20000	good	no	epr-12877.ic12
epr-12878.ic13	131072	7c212c15	360b332d2fb32d88949ff8b357a863ffaaca39c2	mainpcb:pcm	40000	good	no	epr-12878.ic13

chip

type	tag	name	clock
cpu	mainpcb:maincpu	Motorola MC68000	12500000
cpu	mainpcb:subcpu	Motorola MC68000	12500000
cpu	mainpcb:soundcpu	Zilog Z80	4000000
audio	mainpcb:speaker	Speaker
audio	mainpcb:ymsnd	YM2151 OPM	4000000
audio	mainpcb:pcm	Sega PCM	4000000

device_ref

name
segaxbd_pcb_reg
m68000
m68000
z80
nvram
nvram
mb3773
sega_315_5248
sega_315_5248
sega_315_5249
sega_315_5249
sega_315_5250
sega_315_5250
cxd1095
cxd1095
adc0804
gfxdecode
palette
screen
sega_xboard_sprite
segaic16_video
segaic16_road
speaker
ym2151
segapcm

sound

channels
1

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
paddle				yes	32	224	100	4
pedal				no	0	255	100	40

port, analog

port_tag	analog_masks
:mainpcb:ADC0	255
:mainpcb:ADC1	255
:mainpcb:ADC2	255
:mainpcb:IO0PORTA
:mainpcb:IO0PORTB
:mainpcb:IO1PORTA
:mainpcb:IO1PORTB
:mainpcb:IO1PORTC
:mainpcb:IO1PORTD

dipswitch

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	mainpcb:IO1PORTC	15

location

name	number	inverted
SWA	1	no
SWA	2	no
SWA	3	no
SWA	4	no

value

name	value	default
4 Coins/1 Credit	7	no
3 Coins/1 Credit	8	no
2 Coins/1 Credit	9	no
2 Coins/1 Credit, 5/3, 6/4	5	no
2 Coins/1 Credit, 4/3	4	no
1 Coin/1 Credit	15	yes
1 Coin/1 Credit, 5/6	3	no
1 Coin/1 Credit, 4/5	2	no
1 Coin/1 Credit, 2/3	1	no
2 Coins/3 Credits	6	no
1 Coin/2 Credits	14	no
1 Coin/3 Credits	13	no
1 Coin/4 Credits	12	no
1 Coin/5 Credits	11	no
1 Coin/6 Credits	10	no
Free Play (if Coin B too) or 1/1	0	no

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	mainpcb:IO1PORTC	240

location

name	number	inverted
SWA	5	no
SWA	6	no
SWA	7	no
SWA	8	no

value

name	value	default
4 Coins/1 Credit	112	no
3 Coins/1 Credit	128	no
2 Coins/1 Credit	144	no
2 Coins/1 Credit, 5/3, 6/4	80	no
2 Coins/1 Credit, 4/3	64	no
1 Coin/1 Credit	240	yes
1 Coin/1 Credit, 5/6	48	no
1 Coin/1 Credit, 4/5	32	no
1 Coin/1 Credit, 2/3	16	no
2 Coins/3 Credits	96	no
1 Coin/2 Credits	224	no
1 Coin/3 Credits	208	no
1 Coin/4 Credits	192	no
1 Coin/5 Credits	176	no
1 Coin/6 Credits	160	no
Free Play (if Coin A too) or 1/1	0	no

Credits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credits	mainpcb:IO1PORTD	1

location

name	number	inverted
SWB	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 to Start, 1 to Continue	1	yes
2 to Start, 1 to Continue	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	mainpcb:IO1PORTD	2

location

name	number	inverted
SWB	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	no
On	0	yes

Allow Continue

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Allow Continue	mainpcb:IO1PORTD	4

location

name	number	inverted
SWB	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	mainpcb:IO1PORTD	8

location

name	number	inverted
SWB	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Time

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Time	mainpcb:IO1PORTD	48

location

name	number	inverted
SWB	5	no
SWB	6	no

value

name	value	default
Easy	16	no
Normal	48	yes
Hard	32	no
Very Hard	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	mainpcb:IO1PORTD	192

location

name	number	inverted
SWB	7	no
SWB	8	no

value

name	value	default
Easy	64	no
Normal	192	yes
Hard	128	no
Very Hard	0	no
