Racin' Force (ver UAB) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
racinfrcu	konami/konamigx.cpp		no	no	no	yes	Racin' Force (ver UAB)	1994	Konami	racinfrc	racinfrc

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	288	224	59.185606	62060606	1024	24	312	1024	16	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
300a01.34k	131072	d5fa95f5	c483aa98ff8ef40cdac359c19ad23fea5ecc1906	maincpu	0	good	no	300a01.34k
250uab02.34n	524288	315040c6	940d54c1eb898d9a44d823f9f5ae9e91a20f746f	maincpu	200000	good	no
250uab03.31n	524288	171134ab	308b7e76a80c3d860a15408a144b1e0f76fcee87	maincpu	200002	good	no
250a04.34s	2097152	45e4d43c	a668431d53b50fd41e1fa3c8959c0dc96e50c52b	maincpu	400000	good	no	250a04.34s
250a05.31s	2097152	a235af3e	381cd16552f007ccb508411a03fdfd18e32203d0	maincpu	400002	good	no	250a05.31s
250a06.8p	131072	2d0a3ff1	ce4261d5f86821e98e971a35403c793506d0566b	soundcpu	0	good	no	250a06.8p
250a07.6p	131072	612b670a	255515fa5096fcc4681b32defa0ae855286d8ed1	soundcpu	1	good	no	250a07.6p
250a15.19y	1048576	60abc472	ff360d81222e2d8cd55b907ca5a9947f958aaaab	k056832	0	good	no	250a15.19y
250a14.21y	524288	d14abf98	14827a01deb659c96fd38a5c76f1c9cead5f83c7	k056832	4	good	no	250a14.21y
250a12.26y	2097152	e4ca3cff	5dfddda4b5257e98a53fb8669714004ae3aeb3a7	k055673	0	good	no	250a12.26y
250a10.31y	2097152	75c02d12	3ca471d887b92261b1c3f50777903df13f07b1a9	k055673	2	good	no	250a10.31y
250a13.24y	2097152	7aeef929	9f656e2ede27aea7d51f0f0a3a91a8f2c2d250c0	k055673	400000	good	no	250a13.24y
250a11.28y	2097152	dfbce309	831444e7a7588833ffc9b712412f7aef34a7fa2e	k055673	400002	good	no	250a11.28y
250a08.36y	2097152	25ff6414	0af4ef7fe00d7da5fcb5dd0770d470a556c62d61	k055673	800000	good	no	250a08.36y
250a20.10d	1048576	26a2fcaf	d2e38dc0c61e6fed93441dfe2b811993ac9f0ad3	gfx3	0	good	no	250a20.10d
250a21.7d	1048576	370d7771	59ab52287d5aca37baa68d941db165d8da212c69	gfx3	1	good	no	250a21.7d
250a22.5d	1048576	c66a7775	80087b2a3a221f8b2d6c4d1c1c535602e611b561	gfx3	2	good	no	250a22.5d
250a24.10h	1048576	a14547da	a379ff2f62b340a6ea46c84878a865ccff0d132c	gfx4	0	good	no	250a24.10h
250a25.7h	1048576	58310501	e0be82f112fd86cdb448c9c8ceda0ad4cc03e3e4	gfx4	1	good	no	250a25.7h
250a26.5h	1048576	f72e4cbe	822895b42fe4dc8fc1c55501009b6d6e57ee46a1	gfx4	2	good	no	250a26.5h
250a17.14y	2097152	adefa079	d25911e3a02d92dc936c3d7e9d76fc270bd1a75a	k054539	0	good	no	250a17.14y
250a18.12y	2097152	8014a2eb	d82f0a7d559340ae05a78ecc8bb69bb35b9c0658	k054539	200000	good	no	250a18.12y
racinfrcu.nv	128	369e1a84	bfed0145d89550b1a1661f3ccc612505053063f8	eeprom	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68EC020	24000000
cpu	soundcpu	Motorola MC68000	8000000
cpu	dasp	Texas Instruments TMS57002 "DASP"	12000000
audio	dasp	Texas Instruments TMS57002 "DASP"	12000000
audio	speaker	Speaker
audio	k054539_1	Konami 054539 ADPCM	18432000
audio	k054539_2	Konami 054539 ADPCM	18432000

device_ref

name
m68ec020
m68000
tms57002
k053252
93c46_16
screen
palette
k056832
k055555
k054338
k055673
speaker
k056800
k054539
k054539
gfxdecode
adc0834

sound

channels
1

feature

type	status	overall
graphics	imperfect
sound		imperfect
lan	unemulated

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
paddle		2		yes	56	200	35	35
pedal				yes	144	255	35	35

port, analog

port_tag	analog_masks
:ADC-RDPORT
:ADC-WRPORT
:AN0	255
:AN1	255
:EEPROMOUT
:INPUTS
:SERVICE
:SYSTEM_DSW

dipswitch

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SYSTEM_DSW	65536

location

name	number	inverted
SW2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	65536	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SYSTEM_DSW	131072

location

name	number	inverted
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	131072	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SYSTEM_DSW	262144

location

name	number	inverted
SW2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	262144	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SYSTEM_DSW	524288

location

name	number	inverted
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	524288	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SYSTEM_DSW	1048576

location

name	number	inverted
SW2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1048576	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SYSTEM_DSW	2097152

location

name	number	inverted
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2097152	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SYSTEM_DSW	4194304

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4194304	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SYSTEM_DSW	8388608

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8388608	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SYSTEM_DSW	16777216

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16777216	yes
On	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	SYSTEM_DSW	33554432

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	33554432	yes
On	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	SYSTEM_DSW	67108864

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	67108864	yes
Yes	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	SYSTEM_DSW	402653184

location

name	number	inverted
SW1	4	no
SW1	5	no

value

name	value	default
2in1	402653184	no
Upright (Mono)	268435456	no
Unused	134217728	no
Upright (Stereo)	0	yes

Car Number & Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Car Number & Color	SYSTEM_DSW	3758096384

location

name	number	inverted
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default
No. 1 (Red)	3758096384	yes
No. 2 (Blue)	3221225472	no
No. 3 (Yellow)	2684354560	no
No. 4 (Green)	2147483648	no
No. 5 (Red)	1610612736	no
No. 6 (Blue)	1073741824	no
No. 7 (Yellow)	536870912	no
No. 8 (Green)	0	no
