Racing Beat (World) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
racingb	taito/taito_z.cpp		no	no	no	yes	Racing Beat (World)	1991	Taito Corporation Japan

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	240	60.055992	6671500	424	0	320	262	16	256	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
c84-110.3	131072	119a8d3b	bcda256730c4427c25aab17d2178814289361a78	maincpu	0	good	no
c84-111.5	131072	1f095692	6a36f3a62de9fc24724e68a23de782bc21c01734	maincpu	1	good	no
c84-104.2	131072	37077fc6	3498db29936f806e1cb624031940fda2e7e601fe	maincpu	40000	good	no
c84-103.4	131072	4ca1d1c2	cd526db226362b7d4429a29392dee40bcc519556	maincpu	40001	good	no
c84-99.35	131072	24778f40	5a588be1774af4e179bdc0e16cd118e74bb9f6ff	sub	0	good	no
c84-100.36	131072	2b99258a	ff2da0f3a0391f55e20655554d72b82cc29fbc87	sub	1	good	no
c84-101.42	131072	9322106e	6c42ee7b9c76483fec2e397ec2737c030a082267	audiocpu	0	good	no
c84-90.12	524288	83ee0e8d	a3b6067913f15656e1f74b30b4c0364a50d1846a	tc0480scp	0	good	no
c84-89.11	524288	aae43c87	cfc05553f7a18132127ae5f1d181fcc582432b56	tc0480scp	2	good	no
c84-92.25	1048576	56e8fd55	852446d4069a446dd9b88b29e461b83b8d626b2c	sprites	0	good	no
c84-94.33	1048576	6117c19b	6b9587fb864a325aec17a73046ba5b7be08a8dd2	sprites	2	good	no
c84-91.23	1048576	b1b0146c	d01f08085d644b17445d904a4684c00f133f7bae	sprites	4	good	no
c84-93.31	1048576	8837bb4e	c41fff198a3c87c6e1672174ede589434374c1b3	sprites	6	good	no
c84-84.12	524288	34dc486b	2f503be67adbc5293f2d1218c838416fd931796c	tc0150rod	0	good	no
c84-88.3	524288	edd1f49c	f11c419dcc7da03ef1f1665c1344c27ff35fe867	spritemap	0	good	no
c84-86.33	1048576	98d9771e	0cbb6b08e1fa5e632309962d7ad7dca448ef4d78	ymsnd:adpcma	0	good	no
c84-87.46	524288	9c1dd80c	e1bae4e02fd94413fac4683e39e530f9d508d658	ymsnd:adpcma	100000	good	no
c84-85.31	524288	24cd838d	18139f7df191ff2d005d76b3a85a6fafb630ea42	ymsnd:adpcmb	0	good	no
c84-19.15	65536	7245a6f6	5bdde4e3bcde8c59dc84478c3cc079d7ef8ee9c5	user2	0	good	no
c84-07.22	256	95a15c77	10246020776cf23c0659f41db66ae2c86db09ed2	user2	0	good	no
c84-09.74	256	71217472	69352cd484b4d5b41b37697aea24107dff8f1b24	user2	0	good	no
c84-10.16	1024	643e8bfc	a6e6086fb8fbd102e01ec72fe60a4232f5909565	user2	0	good	no
c84-11.17	1024	10728853	45d7cc8e06fbe01295cc2194bca9586f0ef8b12b	user2	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	16000000
cpu	audiocpu	Zilog Z80	4000000
cpu	sub	Motorola MC68000	16000000
audio	speaker	Speaker
audio	ymsnd	YM2610 OPNB	8000000
audio	2610.1.r	Volume Filter
audio	2610.1.l	Volume Filter
audio	2610.2.r	Volume Filter
audio	2610.2.l	Volume Filter

device_ref

name
m68000
z80
m68000
tc0510nio
watchdog
screen
gfxdecode
palette
tc0480scp
tc0150rod
speaker
ym2610
filter_volume
filter_volume
filter_volume
filter_volume
tc0140syt

sound

channels
1

feature

type	status	overall
graphics	imperfect
lan	unemulated

input

players	coins	service	tilt
1	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
dial		4		no	0	65535	100	4
paddle				no	0	255	100	4

port, analog

port_tag	analog_masks
:DSWA
:DSWB
:IN0
:IN1
:IN2
:STEER	65535, 255

dipswitch

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSWA	1

location

name	number	inverted
SW A	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Type 0	0	no
Type 1	1	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	2

location

name	number	inverted
SW A	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSWA	4

location

name	number	inverted
SW A	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSWA	8

location

name	number	inverted
SW A	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	8	yes

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSWA	48

location

name	number	inverted
SW A	5	no
SW A	6	no

value

name	value	default
4 Coins/1 Credit	0	no
3 Coins/1 Credit	16	no
2 Coins/1 Credit	32	no
1 Coin/1 Credit	48	yes

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSWA	192

location

name	number	inverted
SW A	7	no
SW A	8	no

value

name	value	default
1 Coin/2 Credits	192	yes
1 Coin/3 Credits	128	no
1 Coin/4 Credits	64	no
1 Coin/6 Credits	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	1

location

name	number	inverted
SW B	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	2

location

name	number	inverted
SW B	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Steering Wheel Range

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Steering Wheel Range	DSWB	4

location

name	number	inverted
SW B	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Normal	4	yes
High	0	no

Steering Wheel Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Steering Wheel Type	DSWB	8

location

name	number	inverted
SW B	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Free	0	no
Locked	8	yes

Network

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Network	DSWB	16

location

name	number	inverted
SW B	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Player Car

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Player Car	DSWB	96

location

name	number	inverted
SW B	6	no
SW B	7	no

value

name	value	default
Red	96	yes
Blue	64	no
Green	32	no
Yellow	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	128

location

name	number	inverted
SW B	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no
