Racing Jam (GQ676AAC) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
racingja	konami/nwk-tr.cpp		no	no	no	yes	Racing Jam (GQ676AAC)	1998	Konami	racingj	racingj

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	512	400	55.210490	16000000	644	44	556	450	31	431	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
676gnc01.27p	2097152	690346b5	157ab6788382ef4f5a8772f08819f54d0856fcc8	prgrom	0	good	no	676gnc01.27p
676a04.16t	2097152	d7808cb6	0668fae5bb94cc120fe196d4b18200f7b512317f	datarom	0	good	no	676a04.16t
676a05.14t	2097152	fb4de1ad	f6aa4eb1b5d22901a2aaf899ed3237a9dfdc55b5	datarom	2	good	no	676a05.14t
676a13.8x	4194304	29077763	ee087ca0d41966ca0fd10727055bb1dcd05a0873	cgboard_0	0	good	no	676a13.8x
676a14.16x	4194304	50a7e3c0	7468a66111a3ddf7c043cd400fa175cae5f65632	cgboard_0	2	good	no	676a14.16x
676a13.8x	4194304	29077763	ee087ca0d41966ca0fd10727055bb1dcd05a0873	cgboard_1	0	good	no	676a13.8x
676a14.16x	4194304	50a7e3c0	7468a66111a3ddf7c043cd400fa175cae5f65632	cgboard_1	2	good	no	676a14.16x
676gna08.7s	524288	8973f6f2	f5648a7e0205f7e979ccacbb52936809ce14a184	audiocpu	0	good	no	676gna08.7s
676a09.16p	4194304	f85c8dc6	8b302c80be309b5cc68b75945fcd7b87a56a4c9b	rfsnd	0	good	no	676a09.16p
676a10.14p	4194304	7b5b7828	aec224d62e4b1e8fdb929d7947ce70d84ba676cf	rfsnd	400000	good	no	676a10.14p
gq676aa_m48t58y.35d	8192	0eb8209d	eb5bc411378423f05f2708d673d5b06687c59dbf	m48t58	0	good	no

chip

type	tag	name	clock
cpu	maincpu	IBM PowerPC 403GA	32000000
cpu	audiocpu	Motorola MC68000	16000000
cpu	dsp1	Analog Devices ADSP21062 "SHARC"	36000000
cpu	dsp2	Analog Devices ADSP21062 "SHARC"	36000000
audio	speaker	Speaker
audio	rfsnd	Ricoh RF5C400	16934400

device_ref

name
ppc403ga
m68000
adsp21062
adsp21062
m48t58
adc12138
k033906
k033906
voodoo_1
voodoo_1
screen
palette
palette
k001604
k001604
speaker
k056800
rf5c400
konppc
konami_gn676a_lan
konppc_jvs_host

sound

channels
1

feature

type	status	overall
graphics	imperfect
sound	imperfect
lan		unemulated

input

players	coins	service	tilt
1	2	yes	no

control

type	ways	reverse	minimum	maximum	sensitivity	keydelta
joy	vertical2	no
paddle		no	0	4095	100	60
pedal		no	0	4095	100	60

port, analog

port_tag	analog_masks
:ANALOG1	4095
:ANALOG2	4095
:ANALOG3	4095
:ANALOG4
:ANALOG5
:DSW
:IN0
:IN1
:IN2

dipswitch

DIP8

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DIP8	DSW	1

location

name	number	inverted
SW	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

DIP7

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DIP7	DSW	2

location

name	number	inverted
SW	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

DIP6

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DIP6	DSW	4

location

name	number	inverted
SW	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

DIP5

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DIP5	DSW	8

location

name	number	inverted
SW	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

DIP4

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DIP4	DSW	16

location

name	number	inverted
SW	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

DIP3

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DIP3	DSW	32

location

name	number	inverted
SW	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Disable Machine Init

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Disable Machine Init	DSW	64

location

name	number	inverted
SW	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	no
On	0	yes

Skip Post

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Skip Post	DSW	128

location

name	number	inverted
SW	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	no
On	0	yes
