Relief Pitcher (Rev C, 26 Apr 1992 / 08 Apr 1992) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
relief2	atari/relief.cpp		no	no	no	yes	Relief Pitcher (Rev C, 26 Apr 1992 / 08 Apr 1992)	1992	Atari Games	relief	relief

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	336	240	59.922743	7159090	456	0	336	262	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
136093-0011c_cs_baff.19e	131072	41373e02	1982be3d2b959f3504cd7e4afacd96bbebc27b8e	maincpu	0	good	no
136093-0012c_cs_8afe.19j	131072	8187b026	1408b5482194161c1fbb30911bb5b64a14b8ffb0	maincpu	1	good	no
136093-0013_cs_cbbf.17e	131072	1e1e82e5	d33c84ae950db9775f9db9bf953aa63188d3f2f9	maincpu	40000	good	no	136093-0013_cs_cbbf.17e
136093-0014_cs_3ebe.17j	131072	19e5decd	8d93d93f966df46d59cf9f4cdaa689e4dcd2689a	maincpu	40001	good	no	136093-0014_cs_3ebe.17j
136093-0025a.14s	524288	1b9e5ef2	d7d14e75ca2d56c5c67154506096570c9ccbcf8e	gfx	0	good	no	136093-0025a.14s
136093-0026a.8d	524288	09b25d93	94d424b21410182b5121201066f4acfa415f4b6b	gfx	80000	good	no	136093-0026a.8d
136093-0027a.18s	524288	5bc1c37b	89f1bca55dd431ca3171b89347209decf0b25e12	gfx	100000	good	no	136093-0027a.18s
136093-0028a.10d	524288	55fb9111	a95508f0831842fa79ca2fc168cfadc8c6d3fbd4	gfx	180000	good	no	136093-0028a.10d
136093-0029.4d	262144	e4593ff4	7360ec7a65aabc90aa787dc30f39992e342495dd	gfx	200001	good	no	136093-0029a.4d
136093-0030a.9b	524288	f4c567f5	7e8c1d54d918b0b41625eacbaf6dcb5bd99d1949	oki	0	good	no	136093-0030a.9b
136093-0031a.10b	524288	ba908d73	a83afd86f4c39394cf624b728a87b8d8b6de1944	oki	80000	good	no	136093-0031a.10b
relief-eeprom.bin	2048	2131fc40	72a9f5f6647fbc74e645b6639db2fdbfbe6456e2	eeprom	0	good	no
gal16v8a-136093-0002.15f	279	b111d5f2	0fe5b4ca786e839e6927a485109d33fe31c737a2	plds	0	good	no	gal16v8a-136093-0002.15f
gal16v8a-136093-0003.11r	279	67165ed2	c7d9b9c45dd34e588c3db4e23c9c562334d2172a	plds	200	good	no	gal16v8a-136093-0003.11r
gal16v8a-136093-0004.5n	279	047b384a	d268a65cf2d0fc0cfc7dd6b5c7a77572337c1707	plds	400	good	no	gal16v8a-136093-0004.5n
gal16v8a-136093-0005.3f	279	f76825b7	2cd9cbb2564e5005a833403ae73f1a964dcb66fa	plds	600	good	no	gal16v8a-136093-0005.3f
gal16v8a-136093-0006.5f	279	c580d2a9	b070fa53ec083fbeda8cd592bfbbd1e029b4dbe7	plds	800	good	no	gal16v8a-136093-0006.5f
gal16v8a-136093-0008.3e	279	0117910e	c8baecd24af201ad51cf13bf46c5cc0e7f7f2a94	plds	a00	good	no	gal16v8a-136093-0008.3e
gal16v8a-136093-0009.8a	279	b8679030	09ab39c9c293381bbc082780f00d112c71e9c889	plds	c00	good	no	gal16v8a-136093-0009.8a
gal16v8a-136093-0010.15a	279	5f49c736	91ff18e4780ee6c904735fc0f0e73ffb5a80b49a	plds	e00	good	no	gal16v8a-136093-0010.15a

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	7159090
audio	mono	Speaker
audio	oki	OKI MSM6295 ADPCM	1193181
audio	ymsnd	YM2413 OPLL	3579545

device_ref

name
m68000
2816
watchdog
gfxdecode
palette
atarivad
tilemap
tilemap
atarimo
screen
speaker
okim6295
ym2413

sound

channels
1

input

players	coins	service	tilt
2	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	3	8	no
joy	2	3	8	no

port, analog

port_tag	analog_masks
:260000
:260002
:260010
:260012

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	260000	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	260000	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	260000	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	260000	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	260002	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	260002	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	260002	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	260010	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no
