Mahjong Ren-ai Club (Japan) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
renaiclb	nichibutsu/nbmj9195.cpp		no	no	no	yes	Mahjong Ren-ai Club (Japan)	1993	Fujic

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	640	240	60.000000	31457280	1024	0	640	512	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
1.7c	65536	82f99130	afb19d716b71c10ca3e8c014be9e9a6105aa660b	maincpu	0	good	no
2.12e	131072	9f6204a1	8d20e0893bb8ceaf8f5076fb0ade24c040f4fc82	nichisnd:audiorom	0	good	no
3.1h	524288	3d205506	f92511c8bff0f21e02587d01d5e046dbbb1dc342	blitter	0	good	no
4.3h	524288	d9c1af55	1fb5e43c2d1bed652499e5f1a2c928d37860df29	blitter	80000	good	no
5.5h	524288	3860cae7	b1277acc567d9290ab6e4d69a58968f6a945a022	blitter	100000	good	no
6.6h	524288	f5a43aaa	c83e7f3891556428970021b220b42b1a416467a3	blitter	180000	good	no
7.7h	524288	31676c54	3127ce38763584e4832996c5cb7c999656c554d9	blitter	200000	good	no

chip

type	tag	name	clock
cpu	maincpu	Toshiba TMPZ84C011	6000000
cpu	nichisnd:audiocpu	Toshiba TMPZ84C011	8000000
audio	nichisnd:speaker	Speaker
audio	nichisnd:ymsnd	YM3812 OPL2	4000000
audio	nichisnd:dac1	8-Bit R-2R DAC
audio	nichisnd:dac2	8-Bit R-2R DAC

device_ref

name
tmpz84c011
z80ctc
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80ctc_channel
ttl166
timer
ttl166
timer
screen
palette
nichisnd
tmpz84c011
z80ctc
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80ctc_channel
speaker
generic_latch_8
ym3812
dac_8bit_r2r
dac_8bit_r2r

sound

channels
1

input

players	coins	service	tilt
2	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mahjong	1	26		no
mahjong	2	26		no

port, analog

port_tag	analog_masks
:DSWA
:DSWB
:P1_KEY0
:P1_KEY1
:P1_KEY2
:P1_KEY3
:P1_KEY4
:P2_KEY0
:P2_KEY1
:P2_KEY2
:P2_KEY3
:P2_KEY4
:SYSTEM

dipswitch

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSWA	7

location

name	number	inverted
DSWA	1	no
DSWA	2	no
DSWA	3	no

value

name	value	default
1 (Easy)	7	yes
2	6	no
3	5	no
4	4	no
5	3	no
6	2	no
7	1	no
8 (Hard)	0	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSWA	24

location

name	number	inverted
DSWA	4	no
DSWA	5	no

value

name	value	default
2 Coins/1 Credit	0	no
1 Coin/1 Credit	24	yes
1 Coin/2 Credits	16	no
1 Coin/3 Credits	8	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSWA	32

location

name	number	inverted
DSWA	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	no
On	0	yes

Voices

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Voices	DSWA	64

location

name	number	inverted
DSWA	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	no
On	0	yes

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSWA	128

location

name	number	inverted
DSWA	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	1

location

name	number	inverted
DSWB	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	2

location

name	number	inverted
DSWB	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	4

location

name	number	inverted
DSWB	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	8

location

name	number	inverted
DSWB	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	16

location

name	number	inverted
DSWB	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWB	32

location

name	number	inverted
DSWB	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Character Display Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Character Display Test	DSWB	64

location

name	number	inverted
DSWB	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Graphic ROM Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Graphic ROM Test	DSWB	128

location

name	number	inverted
DSWB	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	SYSTEM	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no
