Revolution X (rev 1.0 6/16/94) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
revx	midway/midxunit.cpp		no	no	no	yes	Revolution X (rev 1.0 6/16/94)	1994	Midway

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	400	254	54.706840	8000000	506	101	501	289	20	274	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
l1_revolution_x_game_rom_u51.u51	524288	9960ac7c	441322f061d627ca7573f612f370a85794681d0f	maincpu	0	good	no
l1_revolution_x_game_rom_u52.u52	524288	fbf55510	8a5b0004ed09391fe37f0f501b979903d6ae4868	maincpu	1	good	no
l1_revolution_x_game_rom_u53.u53	524288	a045b265	b294d3a56e41f5ec4ab9bbcc0088833b1cab1879	maincpu	2	good	no
l1_revolution_x_game_rom_u54.u54	524288	24471269	262345bd147402100785459af422dafd1c562787	maincpu	3	good	no
l1_revolution_x_sound_rom_u2.u2	524288	d2ed9f5e	415ce5e41a560d135ea41c7924219fdeda504237	dcs	0	good	no
l1_revolution_x_sound_rom_u3.u3	524288	af8f253b	25a0000cab177378070f7a6e3c7378fe87fad63e	dcs	200000	good	no
l1_revolution_x_sound_rom_u4.u4	524288	3ccce59c	e81a31d64c64e7b1d25f178c53da3d68453c203c	dcs	400000	good	no
l1_revolution_x_sound_rom_u5.u5	524288	a0438006	560d216d21cb8073dbee0fd20ebe589932a9144e	dcs	600000	good	no
l1_revolution_x_sound_rom_u6.u6	524288	b7b34f60	3b9682c6a00fa3bdb47e69d8e8ceccc244ee55b5	dcs	800000	good	no
l1_revolution_x_sound_rom_u7.u7	524288	6795fd88	7c3790730a8b99b63112c851318b1c7e4989e5e0	dcs	a00000	good	no
l1_revolution_x_sound_rom_u8.u8	524288	793a7eb5	4b1f81b68f95cedf1b356ef362d1eb37acc74b16	dcs	c00000	good	no
l1_revolution_x_sound_rom_u9.u9	524288	14ddbea1	8dba9dc5529ea77c4312ea61f825bf9062ffc6c3	dcs	e00000	good	no
419_revolution-x_u444.u444	8192	7df57330	fa6733972f45d90563c184b6735da7a40cee1bf2	pic	0	good	no
p5_revolution_x_game_rom_u120.u120	524288	523af1f0	a67c0fd757e860fc1c1236945952a295b4d5df5a	video	0	good	no
p5_revolution_x_game_rom_u121.u121	524288	78201d93	fb0b8f887eec433f7624f387d7fb6f633ea30d7c	video	1	good	no
p5_revolution_x_game_rom_u122.u122	524288	2cf36144	22ed0eefa2c7c836811fac5f717c3f38254eabc2	video	2	good	no
p5_revolution_x_game_rom_u123.u123	524288	6912e1fb	416f0de711d80e9182ede524c568c5095b1bec61	video	3	good	no
p5_revolution_x_game_rom_u110.u110	524288	e3f7f0af	5877d9f488b0f4362a9482007c3ff7f4589a036f	video	200000	good	no
p5_revolution_x_game_rom_u111.u111	524288	49fe1a69	9ae54b461f0524c034fbcb6fcd3fd5ccb5d7265a	video	200001	good	no
p5_revolution_x_game_rom_u112.u112	524288	7e3ba175	dd2fe90988b544f67dbe6151282fd80d49631388	video	200002	good	no
p5_revolution_x_game_rom_u113.u113	524288	c0817583	2f866e5888e212b245984344950d0e1fb8957a73	video	200003	good	no
p5_revolution_x_game_rom_u101.u101	524288	5a08272a	17da3c9d71114f5fdbf50281a942be3da3b6f564	video	400000	good	no
p5_revolution_x_game_rom_u102.u102	524288	11d567d2	7ebe6fd39a0335e1fdda150d2dc86c3eaab17b2e	video	400001	good	no
p5_revolution_x_game_rom_u103.u103	524288	d338e63b	0a038217542667b3a01ecbcad824ee18c084f293	video	400002	good	no
p5_revolution_x_game_rom_u104.u104	524288	f7b701ee	0fc5886e5857326bee7272d5d482a878cbcea83c	video	400003	good	no
p5_revolution_x_game_rom_u91.u91	524288	52a63713	dcc0ff3596bd5d273a8d4fd33b0b9b9d588d8354	video	600000	good	no
p5_revolution_x_game_rom_u92.u92	524288	fae3621b	715d41ea789c0c724baa5bd90f6f0f06b9cb1c64	video	600001	good	no
p5_revolution_x_game_rom_u93.u93	524288	7065cf95	6c5888da099e51c4b1c592721c5027c899cf52e3	video	600002	good	no
p5_revolution_x_game_rom_u94.u94	524288	600d5b98	6aef98c91f87390c0759fe71a272a3ccadd71066	video	600003	good	no
p5_revolution_x_game_rom_u81.u81	524288	729eacb1	d130162ae22b99c84abfbe014c4e23e20afb757f	video	800000	good	no
p5_revolution_x_game_rom_u82.u82	524288	19acb904	516059b516bc5b1669c9eb085e0cdcdee520dff0	video	800001	good	no
p5_revolution_x_game_rom_u83.u83	524288	0e223456	1eedbd667f4a214533d1c22ca5312ecf2d4a3ab4	video	800002	good	no
p5_revolution_x_game_rom_u84.u84	524288	d3de0192	2d22c5bac07a7411f326691167c7c70eba4b371f	video	800003	good	no
p5_revolution_x_game_rom_u71.u71	524288	2b29fddb	57b71e5c18b56bf58216e690fdefa6d30d88d34a	video	a00000	good	no
p5_revolution_x_game_rom_u72.u72	524288	2680281b	d1ae0701d20166a00d8733d9d12246c140a5fb96	video	a00001	good	no
p5_revolution_x_game_rom_u73.u73	524288	420bde4d	0f010cdeddb59631a5420dddfc142c50c2a1e65a	video	a00002	good	no
p5_revolution_x_game_rom_u74.u74	524288	26627410	a612121554549afff5c8e8c54774ca7b0220eda8	video	a00003	good	no
p5_revolution_x_game_rom_u63.u63	524288	3066e3f3	25548923db111bd6c6cff44bfb63cb9eb2ef0b53	video	c00000	good	no
p5_revolution_x_game_rom_u64.u64	524288	c33f5309	6bb333f563ea66c4c862ffd5fb91fb5e1b919fe8	video	c00001	good	no
p5_revolution_x_game_rom_u65.u65	524288	6eee3e71	0ef22732e0e2bb5207559decd43f90d1e338ad7b	video	c00002	good	no
p5_revolution_x_game_rom_u66.u66	524288	b43d6fff	87584e7aeea9d52a43023d40c359591ff6342e84	video	c00003	good	no
l1_revolution_x_game_rom_u51.u51	524288	9960ac7c	441322f061d627ca7573f612f370a85794681d0f	video	e00000	good	no
l1_revolution_x_game_rom_u52.u52	524288	fbf55510	8a5b0004ed09391fe37f0f501b979903d6ae4868	video	e00001	good	no
l1_revolution_x_game_rom_u53.u53	524288	a045b265	b294d3a56e41f5ec4ab9bbcc0088833b1cab1879	video	e00002	good	no
l1_revolution_x_game_rom_u54.u54	524288	24471269	262345bd147402100785459af422dafd1c562787	video	e00003	good	no
a-17722.u1	279	054de7a3	bb7abaec50ed704c03b44d5d54296898f7c80d38	plds	0	good	no
a-17721.u955	279	033fe902	6efb4e519ed3c9d49fff046a679762b506b3a75b	plds	200	good	no
snd-gal16v8a.u17	279			plds	400	nodump	no

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS34020	40000000
cpu	pic	Microchip PIC16C57	625000
cpu	dcs:dcs	Analog Devices ADSP-2105	10000000
audio	mono	Speaker
audio	dcs	DCS Audio 2K UART
audio	dcs:dac	DMA-driven DAC

device_ref

name
wunitvid
tms34020
nvram
palette
screen
pic16c57
adc0848
speaker
dcs_audio_2k_uart
adsp2105
timer
timer
dmadac

sound

channels
1

input

players	coins	service	tilt
3	4	yes	yes

control

type	player	buttons	reverse	maximum	sensitivity	keydelta
stick	1	2	yes	255	20	10
stick	2	2	yes	255	20	10
stick	3	2	yes	255	20	10

port, analog

port_tag	analog_masks
:AN0	255
:AN1	255
:AN2	255
:AN3	255
:AN4	255
:AN5	255
:DSW
:IN0
:IN1
:IN2

dipswitch

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSW	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Dipswitch Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Dipswitch Coinage	DSW	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW	28

value

name	value	default
1	28	yes
2	24	no
3	20	no
ECA	12	no
Free Play	0	no

Credits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Credits	DSW	224

value

name	value	default
3 Start/1 Continue	32	no
2 Start/2 Continue	224	no
2 Start/1 Continue	160	no
1 Start/4 Continue	0	no
1 Start/3 Continue	64	no
1 Start/1 Continue	96	yes

Country

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Country	DSW	768

value

name	value	default
USA	768	yes
French	256	no
German	512	no
Unused	0	no

Bill Validator

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bill Validator	DSW	1024

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1024	yes
On	0	no

Two Counters

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Two Counters	DSW	2048

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2048	no
On	0	yes

Players

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Players	DSW	4096

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
3 Players	4096	yes
2 Players	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSW	8192

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Rev X	8192	yes
Terminator 2	0	no

Video Freeze

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Video Freeze	DSW	16384

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16384	yes
On	0	no

Test Switch

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Switch	DSW	32768

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32768	yes
On	0	no
