Rampage: World Tour (rev 1.1) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
rmpgwt11	midway/midwunit.cpp		no	no	no	yes	Rampage: World Tour (rev 1.1)	1997	Midway	rmpgwt	rmpgwt

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	400	254	54.706840	8000000	506	101	501	289	20	274	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
1.0_rampage_world_tour_u2_sound.u2	1048576	0e82f83d	215eebb6c229ef9ad0fcbcbc6e4e07300c05654f	dcs	0	good	no	1.0_rampage_world_tour_u2_sound.u2
1.0_rampage_world_tour_u3_sound.u3	1048576	3ff54d15	827805602091313ec68ea1bccf667bd3b3fc6b8b	dcs	200000	good	no	1.0_rampage_world_tour_u3_sound.u3
1.0_rampage_world_tour_u4_sound.u4	1048576	5c7f5656	6c9d692bad539fec8b5aa0bfb56de3ef3719c68a	dcs	400000	good	no	1.0_rampage_world_tour_u4_sound.u4
1.0_rampage_world_tour_u5_sound.u5	1048576	fd9aaf24	d60dc076e72618c99ecac9d081d8c49d337b90c7	dcs	600000	good	no	1.0_rampage_world_tour_u5_sound.u5
1.1_rampage_world_u54_game.u54	524288	3aa514eb	4ed8db55f257da6d872586d0f9f0cdf1c30e0d22	maincpu	0	good	no
1.1_rampage_world_u63_game.u63	524288	031c908f	531669b13c33921ff199be1e841dd337c86fec50	maincpu	1	good	no
465_rampage_wt.u64	4105	5c14d850	f57aef8350e477252bff1fa0f930c1b5d0ceb03f	serial_security:pic	0	good	no	465_rampage_wt.u64
1.0_rampage_world_tour_u133_image.u133	1048576	5b5ac449	1c01dde9a9dbd9f4a6cd30aea9f6410cab13c2c9	video	0	good	no	1.0_rampage_world_tour_u133_image.u133
1.0_rampage_world_tour_u132_image.u132	1048576	7b3f09c6	477658481ee96d5ce462d5e198d80faff4d4352c	video	1	good	no	1.0_rampage_world_tour_u132_image.u132
1.0_rampage_world_tour_u131_image.u131	1048576	fdecf12e	bcbd29009dabed484e2357dc75c38c7d7bade251	video	2	good	no	1.0_rampage_world_tour_u131_image.u131
1.0_rampage_world_tour_u130_image.u130	1048576	4a983b05	022753e6fa3b3d74eff5b2ec835b07787f5473ab	video	3	good	no	1.0_rampage_world_tour_u130_image.u130
1.0_rampage_world_tour_u129_image.u129	1048576	dc495c6e	7ec80d293f06a013c4f95bfb3fafe5b4a71cf170	video	400000	good	no	1.0_rampage_world_tour_u129_image.u129
1.0_rampage_world_tour_u128_image.u128	1048576	5545503d	75298ca742339d70f86460645a6145070737a883	video	400001	good	no	1.0_rampage_world_tour_u128_image.u128
1.0_rampage_world_tour_u127_image.u127	1048576	6e1756ba	6e88ee4f239d41430cdcacfbfe9dfe9e75c5e4ed	video	400002	good	no	1.0_rampage_world_tour_u127_image.u127
1.0_rampage_world_tour_u126_image.u126	1048576	c300eb1b	e2fffa31c773737d5f5f3f053f9afee4690fcd3d	video	400003	good	no	1.0_rampage_world_tour_u126_image.u126
1.0_rampage_world_tour_u125_image.u125	1048576	7369bf5d	edd84d4119d63263bc65adf953370a6e36c797d3	video	800000	good	no	1.0_rampage_world_tour_u125_image.u125
1.0_rampage_world_tour_u124_image.u124	1048576	c0bf88c8	5ea348bcd208c1c1f5f5943f1e1ef81d25d2b95d	video	800001	good	no	1.0_rampage_world_tour_u124_image.u124
1.0_rampage_world_tour_u123_image.u123	1048576	ac4c712a	ccf40d004ddf1b62870b99da359b00d9fd702944	video	800002	good	no	1.0_rampage_world_tour_u123_image.u123
1.0_rampage_world_tour_u122_image.u122	1048576	609862a2	366c70d5de9135c28934ed6ccf4f373c5a76c748	video	800003	good	no	1.0_rampage_world_tour_u122_image.u122
1.0_rampage_world_tour_u121_image.u121	1048576	f65119b7	4c3110f3be370cad0b031a7aa8605559bdd14842	video	c00000	good	no	1.0_rampage_world_tour_u121_image.u121
1.0_rampage_world_tour_u120_image.u120	1048576	6d643dee	923ad01a0eb5a26d2a913f09fde254605113c868	video	c00001	good	no	1.0_rampage_world_tour_u120_image.u120
1.0_rampage_world_tour_u119_image.u119	1048576	4e49c133	0f83b0d645286f6c6196bcf316ac010378b96c43	video	c00002	good	no	1.0_rampage_world_tour_u119_image.u119
1.0_rampage_world_tour_u118_image.u118	1048576	43a6f51e	cb9d698a6a2ab9134339264e851b57e599db135c	video	c00003	good	no	1.0_rampage_world_tour_u118_image.u118

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS34010	50000000
cpu	dcs:dcs	Analog Devices ADSP-2105	10000000
cpu	serial_security:pic	Microchip PIC16C57	4000000
audio	mono	Speaker
audio	dcs	DCS Audio 8K
audio	dcs:dac	DMA-driven DAC

device_ref

name
wunitvid
tms34010
nvram
palette
screen
speaker
dcs_audio_8k
adsp2105
timer
timer
dmadac
midway_serial_pic_emu
pic16c57

sound

channels
1

input

players	coins	service	tilt
3	4	yes	yes

control

type	player	buttons	ways	reverse
joy	1	3	8	no
joy	2	3	8	no
joy	3	3	8	no

port, analog

port_tag	analog_masks
:DSW
:IN0
:IN1
:IN2

dipswitch

Coinage Source

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage Source	DSW	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Dipswitch	1	no
CMOS	0	yes

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW	62

value

name	value	default
USA-1	62	yes
USA-2	60	no
USA-3	58	no
USA-4	56	no
USA-9	52	no
USA-10	50	no
USA-ECA	54	no
USA-Free Play	48	no
German-1	46	no
German-2	44	no
German-3	42	no
German-4	40	no
German-5	36	no
German-ECA	38	no
German-Free Play	32	no
French-1	30	no
French-2	28	no
French-3	26	no
French-4	24	no
French-11	20	no
French-12	18	no
French-ECA	22	no
French-Free Play	16	no

Counters

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Counters	DSW	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
One	64	no
Two	0	yes

Bill Validator

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bill Validator	DSW	256

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	yes
On	0	no

Powerup Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Powerup Test	DSW	1024

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1024	no

Test Switch

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Switch	DSW	32768

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32768	yes
On	0	no
