Sonic Blast Man (US) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
sbm	taito/taito_b.cpp		no	no	yes	yes	Sonic Blast Man (US)	1990	Taito Corporation

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
c69-20-2.ic10	131072	225952a3	d95ef971929d4a8c19193e80499052f57d205001	maincpu	0	good	no
c69-22-2.ic12	131072	d900ce83	b86c3e7c2f9f2dbd415b7a355e5978de46fc3564	maincpu	1	good	no
c69-19-2.ic9	131072	d6cfacfb	0f910e92a81e0d7ac35d0ffc799dd723f64d47d1	maincpu	40000	good	no
c69-25-2.ic11	131072	70903898	879412e3c385533fd0bf1e47956e3e9bea78378d	maincpu	40001	good	no
c69-31.ic28	65536	c999f753	5d944b492893a0bb605743e2928c802427a85fbf	audiocpu	0	good	no
c69-01.ic5	1048576	521fabe3	f81303688ac014145a7e9325affc4a0f86755ba9	tc0180vcu	0	good	no
c69-13.ic2	131072	d1550884	f3a65827c45959fe5ac4bfc92831a8bed76bf287	tc0180vcu	100000	good	no
c69-12.ic1	131072	eb56582c	41b77704aeaecf3eaa3f87e97c0b59fd00e5349e	tc0180vcu	100001	good	no
c69-02.ic6	1048576	f0e20d35	af67f39498f68523ece4cd91045456092038e0a4	tc0180vcu	200000	good	no
c69-15.ic4	131072	9761d316	f03216bbade96948ff433a925e8bffb8760b4101	tc0180vcu	300000	good	no
c69-14.ic3	131072	0ed0272a	03b15654213ff71ffc96d3a87657bdeb724e9269	tc0180vcu	300001	good	no
c69-26.ic36	524288	8784058b	c3d9c620704fb5e80719e996e97f6191a5bd9f8c	ymsnd:adpcma	0	good	no
c69-04.ic6	260	80498715	076c26f365b74f3b6adb2c4c1a3add5a46a257ea	plds	0	good	no
c69-05.ic25	260	35e345b4	befbea944c645dafb143d8dba83fcc16f1edd3e6	plds	200	good	no
c69-06.ic17	324	3988e5d1	24e03455fd9e653e3fc901bef2c3f3ea59f04ea5	plds	400	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	12000000
cpu	audiocpu	Zilog Z80	4000000
audio	mono	Speaker
audio	ymsnd	YM2610B OPNB2	8000000

device_ref

name
m68000
z80
tc0510nio
watchdog
screen
palette
tc0180vcu
speaker
ym2610b
tc0140syt

sound

channels
1

input

players	coins	service	tilt
2	2	no	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	4	8	no
joy	2		8	no

port, analog

port_tag	analog_masks
:DSWA
:DSWB
:JOY
:PHOTOSENSOR
:START

dipswitch

Tickets

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Tickets	DSWA	1

location

name	number	inverted
SW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	1	yes

Win Bonus Tickets

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Win Bonus Tickets	DSWA	2

location

name	number	inverted
SW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	2	yes

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSWA	4

location

name	number	inverted
SW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSWA	8

location

name	number	inverted
SW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	8	yes

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSWA	48

location

name	number	inverted
SW1	5	no
SW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 Coins/1 Credit	0	no
3 Coins/1 Credit	16	no
2 Coins/1 Credit	32	no
1 Coin/1 Credit	48	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	64

location

name	number	inverted
SW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSWA	128

location

name	number	inverted
SW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSWB	3

location

name	number	inverted
SW2	1	no
SW2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Easy	2	no
Medium	3	yes
Hard	1	no
Hardest	0	no

Punch Power

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Punch Power	DSWB	12

location

name	number	inverted
SW2	3	no
SW2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Lower	8	no
Medium	12	yes
Higher	4	no
Highest	0	no

Tickets Payout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Tickets Payout	DSWB	48

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Total Power / 120	0	no
Total Power / 80	16	no
Total Power / 50	48	yes
Total Power / 40	32	no

Win Bonus Tickets Payout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Win Bonus Tickets Payout	DSWB	192

location

name	number	inverted
SW2	7	no
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1, 2, 3, 4, 5	192	yes
2, 4, 6, 8, 10	128	no
3, 4, 5, 6, 7	64	no
2, 4, 8, 16, 32	0	no
