Take Note (Bellfruit) (Scorpion 4) (set 2) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
sc4taknta	bfm/bfm_sc4.cpp		no	no	no	yes	Take Note (Bellfruit) (Scorpion 4) (set 2)	200?	BFM	sc4taknt	sc4taknt

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
95407760.lo	524288	d873b140	aedc72d2804ebf1cc4fb04c54ffc1fba1e192363	maincpu	1	good	no
95407761.hi	524288	73e60179	9c0913b8a9dba5794a01bdcb02b15cdde976da26	maincpu	0	good	no
95008273.bin	1048576	c8695859	5998d1f3467e522d4fa5ad6cf75b86ae1760fdd6	ymz	0	good	no	95008273.bin

chip

type	tag	name	clock
cpu	maincpu	MC68307	16000000
audio	mono	Speaker
audio	ymz	Yamaha YMZ280B PCMD8	16000000

device_ref

name
mc68307
mc68681
duart_channel
duart_channel
speaker
nvram
mc68681
duart_channel
duart_channel
bfm_bda
ymz280b
sec
stepper
stepper
stepper
stepper

sound

channels
1

input

players	coins	service	tilt
1	6	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mahjong		30		no
