Scrabble (rev. F) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
scrabble	jpm/jpmimpct.cpp		no	no	no	yes	Scrabble (rev. F)	1997	JPM

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	400	300	48.858662	10000000	624	0	400	328	0	300	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
1562.bin	524288	d7303b98	46e8ed04c8fdc092b7d8910d3e3f6cc62f691646	maincpu	0	good	no
1563.bin	524288	77f61ba1	276dc8b2c23880740309c456d4e4b2eae249cdde	maincpu	1	good	no
scra-q1.bin	524288	bcbc6328	cbf8901e80e7bc1f82f6f7d4d5f6a658af98a6f9	maincpu	c00000	good	no
scra-q2.bin	524288	c2147999	f21dc0f3f4ba0d6304801bc492a759534447d747	maincpu	c00001	good	no
scra-q3.bin	524288	622cebb9	9b7c2204462d4912462bad6c4dcf096abe1381bb	maincpu	d00000	good	no
scra-q4.bin	524288	fd4b587b	e29512a075fbc511271d6902c8900a9b0261355c	maincpu	d00001	good	no
scra-q5.bin	524288	fbc28978	ce2549da858888d49677ec982ab3c21cf292939b	maincpu	e00000	good	no
scra-q6.bin	524288	8b792c9c	9a5cc6c4d7e807cbabd174ab7454cdaa93dc3cec	maincpu	e00001	good	no
scra-g1.bin	1048576	04a17df9	c215c90d8add3ff608c24aac242369874f6bf9d7	user1	0	good	no
scra-g2.bin	1048576	724375e6	709211a2d7b86f4e83c94a37010fe61ef9a734de	user1	1	good	no
scra-snd.bin	524288	287759ef	bd37500689b7b2fb4fbc65056e92486c0c00ff61	upd	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	8000000
cpu	dsp	Texas Instruments TMS34010	40000000
audio	mono	Speaker
audio	upd	NEC uPD7759	640000

device_ref

name
m68000
mc68681
duart_channel
duart_channel
timer
nvram
i8255
timer
timer
timer
timer
timer
timer
speaker
upd7759
meters
bacta_datalogger
tms34010
mc68681
duart_channel
duart_channel
screen
bt477
jpmtouch

sound

channels
1

input

players	coins	service	tilt
1	6	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
lightgun		1		no	0	255	45	15

port, analog

port_tag	analog_masks
:COINS
:COIN_SENSE
:DSW
:J10_0
:J10_1
:J10_2
:J9_0
:J9_1
:J9_2
:PAYCOIN_LEVEL
:PERCENT
:PIA_PORTB
:PIA_PORTC
:TEST_DEMO
:TOUCH
:TOUCH_X	255
