SD-1 (32 voice) - mame (0286) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
sd132	ensoniq/esq5505.cpp		no	no	no	yes	SD-1 (32 voice)	1991	Ensoniq

snap

SD-1 (32 voice) png snap

SD-1 (32 voice) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems
sd132	21690	20/01/2026 15:17:42	640	480	96	96	0	Format24bppRgb	305:MAME 0.284 (mame0284)

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
sd1_410_lo.bin	131072	faa613a6	60066765cddfa9d3b5d09057d8f83fb120f4e65e	osrom	1	good	no		410
sd1_410_hi.bin	65536	618c0aa8	74acf458aa1d04a0a7a0cd5855c49e6855dbd301	osrom	0	good	no		410
sd1_32_402_lo.bin	131072	5da2572b	cb6ddd637ed13bfeb40a99df56000479e63fc8ec	osrom	1	good	no		402
sd1_32_402_hi.bin	65536	fc45c210	23b81ebd9176112e6eae0c7c75b39fcb1656c953	osrom	0	good	no		402
u34.bin	524288	85592299	1aa7cf612f91972baeba15991d9686ccde01599c	waverom	1	good	no
u35.bin	524288	c0055975	5a22f1d5e437c6277eb0cfb1ff1b3f8dcdea1cc6	waverom	100001	good	no
u38.bin	1048576	a904190e	e4fd4e1130906086fb4182dcb8b51269969e2836	waverom2	0	good	no
u37.bin	1048576	d706cef3	24ba35248509e9ca45110e2402b8085006ea0cfc	waverom2	100000	good	no
u36.bin	524288	c3ddaf95	44a7bd89cd7e82952cc5100479e110c385246559	nibbles	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	15238090
cpu	esp	Ensoniq ES5510	10000000
audio	speaker	Speaker
audio	pump	Ensoniq 5505/5506 to 5510 interface	15238090
audio	otis	Ensoniq ES5505	15238090
audio	aux	Speaker
audio	wd1772:0:35dd:flopsndout	Speaker
audio	wd1772:0:35dd:floppysound	Floppy sound	44100

softwarelist

tag	name	status	filter
vfxsd_flop	vfxsd_flop	original
sd1_flop	sd1_flop	original
sd132_flop	sd132_flop	original

device_ref

tag	name
:maincpu	m68000
:esp	es5510
:duart	mc68681
:duart:cha	duart_channel
:duart:chb	duart_channel
:mdin	midi_port
:mdin:midiin	midiin_port
:mdin:midiin:midiinimg	midiin
:mdout	midi_port
:mdout:midiout	midiout_port
:mdout:midiout:midioutimg	midiout
:speaker	speaker
:pump	esq_5505_5510_pump
:otis	es5505
:cart	ensoniq_vfx_cartridge
:panel	esqpanel240_vfx
:panel:vfd	esq2x40_vfx
:osram	nvram
:seqram	nvram
:aux	speaker
:wd1772	wd1772
:wd1772:0	floppy_connector
:wd1772:0:35dd	floppy_35_dd
:wd1772:0:35dd:flopsndout	speaker
:wd1772:0:35dd:floppysound	flopsnd
:vfxsd_flop	software_list
:sd1_flop	software_list
:sd132_flop	software_list

adjuster

name	default
Data Entry	512
Modulation	1023
Volume	1023

biosset

name	description	default
410	SD-1 v4.10	no
402	SD-1 v4.02	no

sound

channels
3

feature

type	status	overall
sound	imperfect

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
midiin	mdin:midiin:midiinimg				midiin	min
midiout	mdout:midiout:midioutimg				midiout	mout
cartridge	cart				cartridge	cart
floppydisk	wd1772:0:35dd	floppy_3_5			floppydisk	flop

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
midiin	mdin:midiin:midiinimg				mid, syx
midiout	mdout:midiout:midioutimg				mid
cartridge	cart				rom, cart, eeprom, sc32
floppydisk	wd1772:0:35dd	floppy_3_5			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, img, hfe

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
paddle				no	0	16383	1	1
keypad		66		no

port, analog

port_tag	analog_masks
:mdin:midiin:midiinimg:CFG
:panel:analog_data_entry
:panel:analog_mod_wheel
:panel:analog_pitch_bend	1023
:panel:analog_volume
:panel:buttons_0
:panel:buttons_32
:panel:key_0	16383
:panel:key_1	16383
:panel:key_10	16383
:panel:key_11	16383
:panel:key_12	16383
:panel:key_13	16383
:panel:key_14	16383
:panel:key_15	16383
:panel:key_16	16383
:panel:key_17	16383
:panel:key_18	16383
:panel:key_19	16383
:panel:key_2	16383
:panel:key_20	16383
:panel:key_21	16383
:panel:key_22	16383
:panel:key_23	16383
:panel:key_24	16383
:panel:key_25	16383
:panel:key_26	16383
:panel:key_27	16383
:panel:key_28	16383
:panel:key_29	16383
:panel:key_3	16383
:panel:key_30	16383
:panel:key_31	16383
:panel:key_32	16383
:panel:key_33	16383
:panel:key_34	16383
:panel:key_35	16383
:panel:key_36	16383
:panel:key_37	16383
:panel:key_38	16383
:panel:key_39	16383
:panel:key_4	16383
:panel:key_40	16383
:panel:key_41	16383
:panel:key_42	16383
:panel:key_43	16383
:panel:key_44	16383
:panel:key_45	16383
:panel:key_46	16383
:panel:key_47	16383
:panel:key_48	16383
:panel:key_49	16383
:panel:key_5	16383
:panel:key_50	16383
:panel:key_51	16383
:panel:key_52	16383
:panel:key_53	16383
:panel:key_54	16383
:panel:key_55	16383
:panel:key_56	16383
:panel:key_57	16383
:panel:key_58	16383
:panel:key_59	16383
:panel:key_6	16383
:panel:key_60	16383
:panel:key_7	16383
:panel:key_8	16383
:panel:key_9	16383
:panel:patch_select

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
mdin	midiin	midiin_port	yes
mdout	midiout	midiout_port	yes

configuration

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin:midiin:midiinimg:CFG	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no
