Super GT 24h - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
sgt24h	sega/model2.cpp		no	no	no	yes	Super GT 24h	1996	Jaleco

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	496	384	57.524160	16000000	656	0	496	424	0	384	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
epr-19155.15	524288	593952fd	1fc4afc6e3910cc8adb0688542e61a9efb442e56	maincpu	0	good	no
epr-19156.16	524288	a91fc4ee	a37611da0295f7d7e5d2411c3f9b73140d311f74	maincpu	2	good	no
mpr-19146.11	4194304	d66b5b0f	c2a5b83c9041d8f46dfac4a3ff8cfdefb96d02b3	main_data	0	good	no
mpr-19147.12	4194304	d5558f48	c9f40328d6974b7767fa6ba719d0d2b7a173c210	main_data	2	good	no
mpr-19148.9	4194304	a14c86db	66cd8672c00e4e2572de7c5648de595674ffa8f8	main_data	800000	good	no
mpr-19149.10	4194304	94ef5849	3e1748dc5e61c93eedbf0ca6b1946a30be722403	main_data	800002	good	no
mpr-19150.17	4194304	e0ad870e	3429d9f9434d75ddb5fa05d4b493828adfe826a4	polygons	0	good	no
mpr-19151.21	4194304	e2a1b125	cc5c2d9ab8a01f52e66969464f53ae3cefca6a09	polygons	2	good	no
mpr-19153.27	2097152	136adfd0	70ce4e609c8b003ff04518044c18d29089e6a353	textures	0	good	no
mpr-19152.25	2097152	363769a2	51b2f11a01fb72e151025771f8a8496993e605c2	textures	2	good	no
epr-18643a.7	131072	b5e048ec	8182e05a2ffebd590a936c1359c81e60caa79c2a	cpu4	0	good	no
epr-19157.31	524288	8ffea0cf	439e784081329db2fe03419681150f3216f4ccff	audiocpu	0	good	no
mpr-19154.32	4194304	7cd9e679	b9812c4f3042f95febc96bcdd46e3b0724ad4b4f	samples	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Intel 80960KB	25000000
cpu	copro_adsp	Analog Devices ADSP21062 "SHARC"	32000000
cpu	audiocpu	Motorola MC68000	11289600
cpu	billboard:billcpu	Zilog Z80	8000000
audio	speaker	Speaker
audio	scsp	Yamaha YMF292-F SCSP	22579200

device_ref

name
i80960kb
timer
adsp21062
generic_fifo_u32_device
generic_fifo_u32_device
93c46_16
nvram
315_5649
timer
timer
timer
timer
segas24_tile
screen
palette
m68000
speaker
scsp
i8251
clock
m2comm
segabill
z80
315_5338a

sound

channels
1

feature

type	status	overall
graphics	imperfect
sound		imperfect

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
paddle		3		no	0	255	30	10
pedal				yes	0	255	30	30

port, analog

port_tag	analog_masks
:ACCEL	255
:BRAKE	255
:IN0
:IN1
:IN2
:STEER	255
:SW
:billboard:dsw

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	SW	1

location

name	number	inverted
SW3	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	SW	2

location

name	number	inverted
SW3	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	SW	4

location

name	number	inverted
SW3	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	SW	8

location

name	number	inverted
SW3	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	SW	16

location

name	number	inverted
SW3	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	SW	32

location

name	number	inverted
SW3	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	SW	64

location

name	number	inverted
SW3	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	SW	128

location

name	number	inverted
SW3	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Test Winner LED P1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Winner LED P1	billboard:dsw	1

location

name	number	inverted
DSW	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Test Winner LED P2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Winner LED P2	billboard:dsw	2

location

name	number	inverted
DSW	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Test 7-Segment P1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test 7-Segment P1	billboard:dsw	4

location

name	number	inverted
DSW	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Test 7-Segment P2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test 7-Segment P2	billboard:dsw	8

location

name	number	inverted
DSW	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	billboard:dsw	16

location

name	number	inverted
DSW	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	billboard:dsw	32

location

name	number	inverted
DSW	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Demo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo	billboard:dsw	64

location

name	number	inverted
DSW	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Testmode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Testmode	billboard:dsw	128

location

name	number	inverted
DSW	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no
