Six-Trak (Model 610) Rev B/C - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
sixtrak	sequential/sixtrak.cpp		no	no	no	yes	Six-Trak (Model 610) Rev B/C	1984	Sequential Circuits

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
sixtrak	15209	29/12/2025 11:31:44	640	295	96	96	0	Format24bppRgb	305:MAMEUI 0.282.0 (2025-10-31)	77e8283e5b82d633c651ff314c9df0388677a633

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	supported	no	no	no	no

name	size	crc	sha1	region	status	optional	bios
trak-11.bin	16384	4d361d4f	f14d4291c1a6a3e9462ae9786641cef11a9aac9a	maincpu	good	no	v11
trak-9.bin	16384	d1e6261c	bdad57290c24a9ce02c3a5161f8d12f8f96fc74a	maincpu	good	no	v9
nvram_a-11.bin	4096	e36e5a14	e31fc4fb23ddb34374c785233980023e01a4bffa	nvram_a	good	no	v11
nvram_a-9.bin	4096	4dac5eea	7afd40b7a79ac0d9e8f081766391232354fb7028	nvram_a	good	no	v9
nvram_b-11.bin	2048	ea2e2fb9	d70bf42adf33b2e9970ffd5f1ef3e57217ce349d	nvram_b	good	no	v11
nvram_b-9.bin	2048	ea2e2fb9	d70bf42adf33b2e9970ffd5f1ef3e57217ce349d	nvram_b	good	no	v9

type	tag	name	clock
cpu	maincpu	Zilog Z80	4000000
audio	noise	Six-Trak PNP-based noise generator
audio	wheel_rc_0	RC-based Envelope Generator
audio	wheel_rc_1	RC-based Envelope Generator
audio	gain_rc_1	RC-based Envelope Generator
audio	freq_rc_1	RC-based Envelope Generator
audio	cem3394_1	CEM3394 Synthesizer Voice
audio	cem3394_1:vcf	4th order LPF
audio	gain_rc_2	RC-based Envelope Generator
audio	freq_rc_2	RC-based Envelope Generator
audio	cem3394_2	CEM3394 Synthesizer Voice
audio	cem3394_2:vcf	4th order LPF
audio	gain_rc_3	RC-based Envelope Generator
audio	freq_rc_3	RC-based Envelope Generator
audio	cem3394_3	CEM3394 Synthesizer Voice
audio	cem3394_3:vcf	4th order LPF
audio	gain_rc_4	RC-based Envelope Generator
audio	freq_rc_4	RC-based Envelope Generator
audio	cem3394_4	CEM3394 Synthesizer Voice
audio	cem3394_4:vcf	4th order LPF
audio	gain_rc_5	RC-based Envelope Generator
audio	freq_rc_5	RC-based Envelope Generator
audio	cem3394_5	CEM3394 Synthesizer Voice
audio	cem3394_5:vcf	4th order LPF
audio	gain_rc_6	RC-based Envelope Generator
audio	freq_rc_6	RC-based Envelope Generator
audio	cem3394_6	CEM3394 Synthesizer Voice
audio	cem3394_6:vcf	4th order LPF
audio	voicemixer	Generic Audio Mixer
audio	mute	Volume Filter
audio	master_volume	Volume Filter
audio	mono	Speaker

name	description	default
v11	Six-Trak V11 (1985)	yes
v9	Six-Trak V9	no

channels
1

type	status	overall
sound	imperfect

type	tag	interface	fixed_image	mandatory	name	briefname
midiin	mdin:midiin:midiinimg				midiin	min
midiout	mdout:midiout:midioutimg				midiout	mout

type	tag	interface	fixed_image	mandatory	extension_names
midiin	mdin:midiin:midiinimg				mid, syx
midiout	mdout:midiout:midioutimg				mid

players	coins	service	tilt
1		no	no

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
paddle				no	0	100	30	15
keypad		28		no

slot_name	slotoption_name	slotoption_devname	slotoption_default
mdin	midiin	midiin_port	yes
mdout	midiout	midiout_port	yes

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin:midiin:midiinimg:CFG	255

name	description
sixtraka	Six-Trak (Model 610) Rev A
