Spectra IV - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
spectra	pinball/spectra.cpp	genpin	no	no	yes	yes	Spectra IV	1979	Valley

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
spect_u5.dat	1024	49e0759f	c3badc90ff834cbc92d8c519780069310c2b1507	maincpu	400	good	no
spect_u4.dat	1024	15e53712	e03049178569313cb89cfe0f09043c21d05b1988	maincpu	800	good	no
spect_u3.dat	1024	9ca7510f	a87849f16903836158063d593bb4a2e90c7473c8	maincpu	c00	good	no

chip

type	tag	name	clock
cpu	maincpu	MOS Technology 6503	894886
audio	mechvol	Speaker
audio	samples	Samples
audio	mono	Speaker
audio	snsnd	TI SN76477 CSG

device_ref

name
m6503
mos6532
nvram
timer
timer
speaker
samples
speaker
sn76477

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
2

input

players	coins	service	tilt
1	1	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		28		no

port, analog

port_tag	analog_masks
:X0
:X1
:X2
:X3

dipswitch

Test Switch

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Switch	X3	96

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Play	96	yes
Setup	32	no
Test	64	no
