Spirit of 76 - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
spirit76	pinball/spirit76.cpp	genpin	no	no	yes	yes	Spirit of 76	1975	Mirco

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
1g.bin	512	57d7213c	0897876f5c662b2518a680bcbfe282bb3a19a161	maincpu	0	good	no
5g.bin	512	90e22786	da9e0eae1e8576c6c8ac734a9557784d9e59c141	maincpu	0	good	no
2c.bin	512	4b996a52	c73378e61598f84e20c1022b811780e300b01cd1	maincpu	200	good	no
3c.bin	512	448626fa	658b9589ba60ef62ff692192f743038d622776ba	maincpu	200	good	no
2e.bin	512	faaa907e	ee9227944911a7c068216dd7b1b8dec284f90e3b	maincpu	400	good	no
3e.bin	512	3463168e	d98643179eac5ecbf1a559df59da620ea544bdee	maincpu	400	good	no
2f.bin	512	4d1a71ec	6d3aa8fc4f7cec27d7fae2ecc73425388f8d9d52	maincpu	600	good	no
3f.bin	512	bf23f0fd	62e2ef7df0c057f25685a99e57cf95aae2e75cdb	maincpu	600	good	no
2g.bin	512	6236f053	6183c8fa7dbd32ec40c4668cab8010b5e8c49949	maincpu	800	good	no
3g.bin	512	ae7192cd	9ba76e81b8603163c22f47f1a99da310b4325e84	maincpu	800	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6800	500000
audio	mechvol	Speaker
audio	samples	Samples

device_ref

name
m6800
timer
pia6821
speaker
samples

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
1

input

players	coins	service	tilt
1	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		35		no

port, analog

port_tag	analog_masks
:X0
:X1
:X10
:X11
:X12
:X13
:X14
:X15
:X2
:X3
:X4
:X5
:X6
:X7
:X8
:X9

dipswitch

Balls

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Balls	X12	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
5	0	no
3	1	yes

Add-a-ball

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Add-a-ball	X12	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off	2	yes

Match

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Match	X12	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	4	no

Preset score award allowed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Preset score award allowed	X12	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	yes
Off	8	no

Preset score

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Preset score	X13	15

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
40k	15	yes
50k	14	no
60k	13	no
70k	12	no
80k	11	no
90k	10	no
100k	9	no
120k	8	no
140k	7	no
160k	6	no
180k	5	no
200k	4	no
240k	3	no
280k	2	no
320k	1	no
400k	0	no

Coinage Left Slot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage Left Slot	X14	15

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1C_1C	15	yes
1C_2C	14	no
1C_3C	13	no
1C_4C	12	no

Coinage Right Slot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage Right Slot	X15	15

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1C_1C	15	yes
1C_2C	14	no
1C_3C	13	no
1C_4C	12	no
