name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ssystem4	saitek/ssystem3.cpp		no	no	no	yes	Chess Champion: Super System IV	1980	SciSys / Philidor Software

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	svg	0	960	364	60.000000	20966400	960	0	960	364	0	364	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
c45021_ss4-lrom	4096	fc86a4fc	ee292925165d4bf7b948c60a81d95f7a4064e797	maincpu	d000	good	no
c45022_ss4-mrom	4096	c6110af1	4b63454a23b2fe6b5c8f3fa6718eb49770cb6907	maincpu	e000	good	no
c45023_ss4-hrom	4096	ab4a4343	6eeee7168e13dc1115cb5833f1938a8ea8c01d69	maincpu	f000	good	no
ssystem4.svg	53552	b69b12e3	c2e39d015397d403309f1c23619fe8abc3745d87	screen	0	good	no

chip

type	tag	name	clock
cpu	maincpu	MOS Technology 6502	2000000
audio	speaker	Speaker
audio	dac	1-Bit DAC

device_ref

name
m6502
mos6522
md4332b
screen
pwm_display
speaker
dac

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		14		no

port, analog

port_tag	analog_masks
:IN.0
:IN.1
:IN.2
:IN.3
:IN.4
:IN.5

configuration

Sound

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Sound	IN.4	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	1	yes

LCD 1 Light

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
LCD 1 Light	IN.4	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	2	yes
