swtpc S/09 OS9 - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
swtpc09o	swtpc/swtpc09.cpp		no	no	no	yes	swtpc S/09 OS9	1980	SWTPC	swtpc09	swtpc09

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
swtpc09o	1107	29/12/2025 11:31:46	1285	240	96	96	0	Format24bppRgb	305:MAME 0.219 (Feb 27 2020)	7971f81ade7e3f9c7efe5cec4e039c3154a40330

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
io0:mps2:rs232_upper:terminal:terminal_screen	raster	0	640	240	50.000000								no
io0:mps2:rs232_lower:terminal:terminal_screen	raster	0	640	240	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	unsupported	no	no	yes	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
os9l1v12.bin	7168	f2ee7523	4e47f672c43ee2dbb5f332feb276d2c109f08e78	bankdev	e400	good	no		os9l1v12

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809	8000000
audio	io0:mps2:rs232_upper:terminal:bell	Speaker
audio	io0:mps2:rs232_upper:terminal:beeper	Beep	2000
audio	io0:mps2:rs232_lower:terminal:bell	Speaker
audio	io0:mps2:rs232_lower:terminal:beeper	Beep	2000
audio	io1:dc5:fdc:0:sssd35:flopsndout	Speaker
audio	io1:dc5:fdc:0:sssd35:floppysound	Floppy sound	44100
audio	io1:dc5:fdc:1:sssd35:flopsndout	Speaker
audio	io1:dc5:fdc:1:sssd35:floppysound	Floppy sound	44100
audio	io1:dc5:fdc:2:sssd35:flopsndout	Speaker
audio	io1:dc5:fdc:2:sssd35:floppysound	Floppy sound	44100
audio	io1:dc5:fdc:3:sssd35:flopsndout	Speaker
audio	io1:dc5:fdc:3:sssd35:floppysound	Floppy sound	44100

device_ref

tag	name
:maincpu	mc6809
:bankdev	address_map_bank
:io0	ss50_interface
:io0:mps2	ss50_mps2
:io0:mps2:acia_upper	acia6850
:io0:mps2:rs232_upper	rs232
:io0:mps2:rs232_upper:terminal	serial_terminal
:io0:mps2:rs232_upper:terminal:terminal_screen	screen
:io0:mps2:rs232_upper:terminal:keyboard	generic_keyboard
:io0:mps2:rs232_upper:terminal:bell	speaker
:io0:mps2:rs232_upper:terminal:beeper	beep
:io0:mps2:acia_lower	acia6850
:io0:mps2:rs232_lower	rs232
:io0:mps2:rs232_lower:terminal	serial_terminal
:io0:mps2:rs232_lower:terminal:terminal_screen	screen
:io0:mps2:rs232_lower:terminal:keyboard	generic_keyboard
:io0:mps2:rs232_lower:terminal:bell	speaker
:io0:mps2:rs232_lower:terminal:beeper	beep
:io0:mps2:irq	ipt_merge_any_hi
:io1	ss50_interface
:io1:dc5	ss50_dc5
:io1:dc5:fdc	wd2797
:io1:dc5:fdc:0	floppy_connector
:io1:dc5:fdc:0:sssd35	floppy_525_sssd_35t
:io1:dc5:fdc:0:sssd35:flopsndout	speaker
:io1:dc5:fdc:0:sssd35:floppysound	flopsnd
:io1:dc5:fdc:1	floppy_connector
:io1:dc5:fdc:1:sssd35	floppy_525_sssd_35t
:io1:dc5:fdc:1:sssd35:flopsndout	speaker
:io1:dc5:fdc:1:sssd35:floppysound	flopsnd
:io1:dc5:fdc:2	floppy_connector
:io1:dc5:fdc:2:sssd35	floppy_525_sssd_35t
:io1:dc5:fdc:2:sssd35:flopsndout	speaker
:io1:dc5:fdc:2:sssd35:floppysound	flopsnd
:io1:dc5:fdc:3	floppy_connector
:io1:dc5:fdc:3:sssd35	floppy_525_sssd_35t
:io1:dc5:fdc:3:sssd35:flopsndout	speaker
:io1:dc5:fdc:3:sssd35:floppysound	flopsnd
:io2	ss50_interface
:io3	ss50_interface
:io4	ss50_interface
:io4:mpt	ss50_mpt
:io4:mpt:pia	pia6821
:io5	ss50_interface
:io6	ss50_interface
:io7	ss50_interface
:pia	pia6821
:ptm	ptm6840
:brg	mc14411
:mainirq	ipt_merge_any_hi
:mainfirq	ipt_merge_any_hi

biosset

name	description	default
os9l1v12	OS9 Level 1 version 1.2	no

sound

channels
6

device, instance

type	tag	interface	name	briefname
floppydisk	io1:dc5:fdc:0:sssd35	floppy_5_25	floppydisk1	flop1
floppydisk	io1:dc5:fdc:1:sssd35	floppy_5_25	floppydisk2	flop2
floppydisk	io1:dc5:fdc:2:sssd35	floppy_5_25	floppydisk3	flop3
floppydisk	io1:dc5:fdc:3:sssd35	floppy_5_25	floppydisk4	flop4

device, extension

type	tag	interface	extension_names
floppydisk	io1:dc5:fdc:0:sssd35	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, os9
floppydisk	io1:dc5:fdc:1:sssd35	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, os9
floppydisk	io1:dc5:fdc:2:sssd35	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, os9
floppydisk	io1:dc5:fdc:3:sssd35	floppy_5_25	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk, os9

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keyboard	1	73		no
keyboard	2	73		no

port, analog

port_tag	analog_masks
:BAUD_RATE_HIGH
:FDC_CLOCK
:FLOPPY_EXPECTED_DENSITY
:FLOPPY_EXPECTED_SECTORS
:FLOPPY_TRACK_ZERO_EXPECTED_SECTORS
:MAINCPU_CLOCK
:PIAIDE_FLEX_BOOT_CD00
:SBUG_DOUBLE_DENSITY
:io0:mps2:RX_BAUD_LOWER
:io0:mps2:RX_BAUD_UPPER
:io0:mps2:TX_BAUD_LOWER
:io0:mps2:TX_BAUD_UPPER
:io0:mps2:rs232_lower:terminal:RS232_DATABITS
:io0:mps2:rs232_lower:terminal:RS232_PARITY
:io0:mps2:rs232_lower:terminal:RS232_RXBAUD
:io0:mps2:rs232_lower:terminal:RS232_STOPBITS
:io0:mps2:rs232_lower:terminal:RS232_TXBAUD
:io0:mps2:rs232_lower:terminal:TERM_CONF
:io0:mps2:rs232_lower:terminal:keyboard:GENKBD_CFG
:io0:mps2:rs232_lower:terminal:keyboard:GENKBD_MOD
:io0:mps2:rs232_lower:terminal:keyboard:GENKBD_ROW0
:io0:mps2:rs232_lower:terminal:keyboard:GENKBD_ROW1
:io0:mps2:rs232_lower:terminal:keyboard:GENKBD_ROW2
:io0:mps2:rs232_lower:terminal:keyboard:GENKBD_ROW3
:io0:mps2:rs232_upper:terminal:RS232_DATABITS
:io0:mps2:rs232_upper:terminal:RS232_PARITY
:io0:mps2:rs232_upper:terminal:RS232_RXBAUD
:io0:mps2:rs232_upper:terminal:RS232_STOPBITS
:io0:mps2:rs232_upper:terminal:RS232_TXBAUD
:io0:mps2:rs232_upper:terminal:TERM_CONF
:io0:mps2:rs232_upper:terminal:keyboard:GENKBD_CFG
:io0:mps2:rs232_upper:terminal:keyboard:GENKBD_MOD
:io0:mps2:rs232_upper:terminal:keyboard:GENKBD_ROW0
:io0:mps2:rs232_upper:terminal:keyboard:GENKBD_ROW1
:io0:mps2:rs232_upper:terminal:keyboard:GENKBD_ROW2
:io0:mps2:rs232_upper:terminal:keyboard:GENKBD_ROW3
:io1:dc5:ADDRESS_MODE
:io1:dc5:CTRL_REG_BIT7_SIDE_SELECT
:io1:dc5:EXPECTED_CLOCK
:io1:dc5:EXPECTED_DENSITY
:io1:dc5:EXPECTED_SECTORS
:io1:dc5:FORCE_READY
:io1:dc5:INTERRUPT_SELECT
:io1:dc5:TRACK_ZERO_EXPECTED_SECTORS
:io1:dc5:TWO_CONTROL_REGS
:io4:mpt:IRQA
:io4:mpt:IRQB

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
io0	mpt	ss50_mpt	no
io0	mps	ss50_mps	no
io0	mpc	ss50_mpc	no
io0	piaide	ss50_piaide	no
io0	mps2	ss50_mps2	yes
io0	dc5	ss50_dc5	no
io0:mps2:rs232_upper	terminal	serial_terminal	yes
io0:mps2:rs232_upper	sunkbd	sunkbd_adaptor	no
io0:mps2:rs232_upper	votraxtnt	serial_votraxtnt	no
io0:mps2:rs232_upper	rs_printer	rs_serial_printer	no
io0:mps2:rs232_upper	dec_loopback	dec_rs232_loopback	no
io0:mps2:rs232_upper	h19	serial_heath_h19	no
io0:mps2:rs232_upper	ie15	ie15_terminal	no
io0:mps2:rs232_upper	null_modem	null_modem	no
io0:mps2:rs232_upper	keyboard	serial_keyboard	no
io0:mps2:rs232_upper	patch	rs232_patch_box	no
io0:mps2:rs232_upper	swtpc8212	swtpc8212_terminal	no
io0:mps2:rs232_upper	printer	serial_printer	no
io0:mps2:rs232_upper	scorpion	scorpion_ic	no
io0:mps2:rs232_upper	loopback	rs232_loopback	no
io0:mps2:rs232_upper	mockingboard	mockingboardd	no
io0:mps2:rs232_upper	msystems_mouse	rs232_mouse_hle_msystems	no
io0:mps2:rs232_upper	nss_tvi	nss_tvinterface	no
io0:mps2:rs232_upper	rs232_sync_io	rs232_sync_io	no
io0:mps2:rs232_upper	pty	pseudo_terminal	no
io0:mps2:rs232_lower	terminal	serial_terminal	yes
io0:mps2:rs232_lower	sunkbd	sunkbd_adaptor	no
io0:mps2:rs232_lower	votraxtnt	serial_votraxtnt	no
io0:mps2:rs232_lower	rs_printer	rs_serial_printer	no
io0:mps2:rs232_lower	dec_loopback	dec_rs232_loopback	no
io0:mps2:rs232_lower	h19	serial_heath_h19	no
io0:mps2:rs232_lower	ie15	ie15_terminal	no
io0:mps2:rs232_lower	null_modem	null_modem	no
io0:mps2:rs232_lower	keyboard	serial_keyboard	no
io0:mps2:rs232_lower	patch	rs232_patch_box	no
io0:mps2:rs232_lower	swtpc8212	swtpc8212_terminal	no
io0:mps2:rs232_lower	printer	serial_printer	no
io0:mps2:rs232_lower	scorpion	scorpion_ic	no
io0:mps2:rs232_lower	loopback	rs232_loopback	no
io0:mps2:rs232_lower	mockingboard	mockingboardd	no
io0:mps2:rs232_lower	msystems_mouse	rs232_mouse_hle_msystems	no
io0:mps2:rs232_lower	nss_tvi	nss_tvinterface	no
io0:mps2:rs232_lower	rs232_sync_io	rs232_sync_io	no
io0:mps2:rs232_lower	pty	pseudo_terminal	no
io1	mpt	ss50_mpt	no
io1	mps	ss50_mps	no
io1	mpc	ss50_mpc	no
io1	piaide	ss50_piaide	no
io1	mps2	ss50_mps2	no
io1	dc5	ss50_dc5	yes
io1:dc5:fdc:0	8ssdd	floppy_8_ssdd	no
io1:dc5:fdc:0	8dssd	floppy_8_dssd	no
io1:dc5:fdc:0	8dsdd	floppy_8_dsdd	no
io1:dc5:fdc:0	ssqd	floppy_525_ssqd	no
io1:dc5:fdc:0	8sssd	floppy_8_sssd	no
io1:dc5:fdc:0	ssdd	floppy_525_ssdd	no
io1:dc5:fdc:0	dssd	floppy_525_sd	no
io1:dc5:fdc:0	qd	floppy_525_qd	no
io1:dc5:fdc:0	dssd35	floppy_525_sd_35t	no
io1:dc5:fdc:0	35hd	floppy_35_hd	no
io1:dc5:fdc:0	dd	floppy_525_dd	no
io1:dc5:fdc:0	sssd	floppy_525_sssd	no
io1:dc5:fdc:0	sssd35	floppy_525_sssd_35t	yes
io1:dc5:fdc:1	8ssdd	floppy_8_ssdd	no
io1:dc5:fdc:1	8dssd	floppy_8_dssd	no
io1:dc5:fdc:1	8dsdd	floppy_8_dsdd	no
io1:dc5:fdc:1	ssqd	floppy_525_ssqd	no
io1:dc5:fdc:1	8sssd	floppy_8_sssd	no
io1:dc5:fdc:1	ssdd	floppy_525_ssdd	no
io1:dc5:fdc:1	dssd	floppy_525_sd	no
io1:dc5:fdc:1	qd	floppy_525_qd	no
io1:dc5:fdc:1	dssd35	floppy_525_sd_35t	no
io1:dc5:fdc:1	35hd	floppy_35_hd	no
io1:dc5:fdc:1	dd	floppy_525_dd	no
io1:dc5:fdc:1	sssd	floppy_525_sssd	no
io1:dc5:fdc:1	sssd35	floppy_525_sssd_35t	yes
io1:dc5:fdc:2	8ssdd	floppy_8_ssdd	no
io1:dc5:fdc:2	8dssd	floppy_8_dssd	no
io1:dc5:fdc:2	8dsdd	floppy_8_dsdd	no
io1:dc5:fdc:2	ssqd	floppy_525_ssqd	no
io1:dc5:fdc:2	8sssd	floppy_8_sssd	no
io1:dc5:fdc:2	ssdd	floppy_525_ssdd	no
io1:dc5:fdc:2	dssd	floppy_525_sd	no
io1:dc5:fdc:2	qd	floppy_525_qd	no
io1:dc5:fdc:2	dssd35	floppy_525_sd_35t	no
io1:dc5:fdc:2	35hd	floppy_35_hd	no
io1:dc5:fdc:2	dd	floppy_525_dd	no
io1:dc5:fdc:2	sssd	floppy_525_sssd	no
io1:dc5:fdc:2	sssd35	floppy_525_sssd_35t	yes
io1:dc5:fdc:3	8ssdd	floppy_8_ssdd	no
io1:dc5:fdc:3	8dssd	floppy_8_dssd	no
io1:dc5:fdc:3	8dsdd	floppy_8_dsdd	no
io1:dc5:fdc:3	ssqd	floppy_525_ssqd	no
io1:dc5:fdc:3	8sssd	floppy_8_sssd	no
io1:dc5:fdc:3	ssdd	floppy_525_ssdd	no
io1:dc5:fdc:3	dssd	floppy_525_sd	no
io1:dc5:fdc:3	qd	floppy_525_qd	no
io1:dc5:fdc:3	dssd35	floppy_525_sd_35t	no
io1:dc5:fdc:3	35hd	floppy_35_hd	no
io1:dc5:fdc:3	dd	floppy_525_dd	no
io1:dc5:fdc:3	sssd	floppy_525_sssd	no
io1:dc5:fdc:3	sssd35	floppy_525_sssd_35t	yes
io2	mpt	ss50_mpt	no
io2	mps	ss50_mps	no
io2	mpc	ss50_mpc	no
io2	piaide	ss50_piaide	no
io2	mps2	ss50_mps2	no
io2	dc5	ss50_dc5	no
io3	mpt	ss50_mpt	no
io3	mps	ss50_mps	no
io3	mpc	ss50_mpc	no
io3	piaide	ss50_piaide	no
io3	mps2	ss50_mps2	no
io3	dc5	ss50_dc5	no
io4	mpt	ss50_mpt	yes
io4	mps	ss50_mps	no
io4	mpc	ss50_mpc	no
io4	piaide	ss50_piaide	no
io4	mps2	ss50_mps2	no
io4	dc5	ss50_dc5	no
io5	mpt	ss50_mpt	no
io5	mps	ss50_mps	no
io5	mpc	ss50_mpc	no
io5	piaide	ss50_piaide	no
io5	mps2	ss50_mps2	no
io5	dc5	ss50_dc5	no
io6	mpt	ss50_mpt	no
io6	mps	ss50_mps	no
io6	mpc	ss50_mpc	no
io6	piaide	ss50_piaide	no
io6	mps2	ss50_mps2	no
io6	dc5	ss50_dc5	no
io7	mpt	ss50_mpt	no
io7	mps	ss50_mps	no
io7	mpc	ss50_mpc	no
io7	piaide	ss50_piaide	no
io7	mps2	ss50_mps2	no
io7	dc5	ss50_dc5	no

configuration

High baud rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
High baud rate	BAUD_RATE_HIGH	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Low (x1)	0	yes
High (x4)	1	no

DMAF2/3 FDC clock

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DMAF2/3 FDC clock	FDC_CLOCK	16777215

setting

name	value	default
1.0 MHz	1000000	no
1.2 MHz	1200000	no
2.0 MHz	2000000	yes
2.4 MHz	2400000	no

DMAF2/3 expected density

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DMAF2/3 expected density	FLOPPY_EXPECTED_DENSITY	7

setting

name	value	default
-	0	yes
single density	1	no
double density, with single density track zero head zero	2	no
double density, with single density track zero all heads	3	no
double density	4	no

DMAF2/3 FLEX expected sectors per side

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DMAF2/3 FLEX expected sectors per side	FLOPPY_EXPECTED_SECTORS	255

setting

name	value	default
-	0	yes
10	10	no
15	15	no
16	16	no
18	18	no
26	26	no
36	36	no

DMAF2/3 FLEX track zero expected sectors per side

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DMAF2/3 FLEX track zero expected sectors per side	FLOPPY_TRACK_ZERO_EXPECTED_SECTORS	255

setting

name	value	default
-	0	yes
10	10	no
15	15	no
16	16	no
18	18	no
26	26	no
36	36	no

CPU clock

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CPU clock	MAINCPU_CLOCK	16777215

setting

name	value	default
1.0 MHz	1000000	no
2.0 MHz	2000000	yes
4.0 MHz	4000000	no

PIA IDE PROM patch FLEX entry to 0xcd00

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
PIA IDE PROM patch FLEX entry to 0xcd00	PIAIDE_FLEX_BOOT_CD00	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No - FLEX entry 0xc850	0	yes
Yes - FLEX entry 0xcd00	1	no

SBUG patch for double density (SSO) disk boot

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
SBUG patch for double density (SSO) disk boot	SBUG_DOUBLE_DENSITY	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No - single density	0	yes
Yes - double density	1	no

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	io0:mps2:rs232_lower:terminal:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	io0:mps2:rs232_lower:terminal:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	io0:mps2:rs232_lower:terminal:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	io0:mps2:rs232_lower:terminal:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	io0:mps2:rs232_lower:terminal:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	io0:mps2:rs232_lower:terminal:TERM_CONF	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type	io0:mps2:rs232_lower:terminal:TERM_CONF	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Underline	0	no
Block	2	yes

Blinking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blinking	io0:mps2:rs232_lower:terminal:TERM_CONF	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	4	yes

Invert

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Invert	io0:mps2:rs232_lower:terminal:TERM_CONF	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Color	io0:mps2:rs232_lower:terminal:TERM_CONF	48

setting

name	value	default
Green	0	yes
Amber	16	no
White	32	no

Auto CR on LF

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto CR on LF	io0:mps2:rs232_lower:terminal:TERM_CONF	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	64	yes

Auto LF on CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto LF on CR	io0:mps2:rs232_lower:terminal:TERM_CONF	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	128	no

Local echo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Local echo	io0:mps2:rs232_lower:terminal:TERM_CONF	256

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	256	no

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	io0:mps2:rs232_lower:terminal:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	io0:mps2:rs232_lower:terminal:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	io0:mps2:rs232_lower:terminal:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	io0:mps2:rs232_upper:terminal:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	io0:mps2:rs232_upper:terminal:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	io0:mps2:rs232_upper:terminal:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	io0:mps2:rs232_upper:terminal:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	io0:mps2:rs232_upper:terminal:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
76800	23	no
78125	24	no
111900	22	no
115200	13	no

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	io0:mps2:rs232_upper:terminal:TERM_CONF	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type	io0:mps2:rs232_upper:terminal:TERM_CONF	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Underline	0	no
Block	2	yes

Blinking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blinking	io0:mps2:rs232_upper:terminal:TERM_CONF	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	4	yes

Invert

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Invert	io0:mps2:rs232_upper:terminal:TERM_CONF	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Color	io0:mps2:rs232_upper:terminal:TERM_CONF	48

setting

name	value	default
Green	0	yes
Amber	16	no
White	32	no

Auto CR on LF

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto CR on LF	io0:mps2:rs232_upper:terminal:TERM_CONF	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	64	yes

Auto LF on CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto LF on CR	io0:mps2:rs232_upper:terminal:TERM_CONF	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	128	no

Local echo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Local echo	io0:mps2:rs232_upper:terminal:TERM_CONF	256

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	256	no

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	io0:mps2:rs232_upper:terminal:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	io0:mps2:rs232_upper:terminal:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	io0:mps2:rs232_upper:terminal:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no

Control register bit 7

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Control register bit 7	io1:dc5:CTRL_REG_BIT7_SIDE_SELECT	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Inhibits drive selection	0	yes
Erroneous side select	1	no

FDC expected clock rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
FDC expected clock rate	io1:dc5:EXPECTED_CLOCK	15

setting

name	value	default
-	0	yes
1.0 MHz	12	no
1.2 MHz	10	no
2.0 MHz	6	no
2.4 MHz	5	no

Expected density

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Expected density	io1:dc5:EXPECTED_DENSITY	7

setting

name	value	default
-	0	yes
single density	1	no
double density, with single density track zero head zero	2	no
double density, with single density track zero all heads	3	no
double density	4	no

FLEX expected sectors per side

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
FLEX expected sectors per side	io1:dc5:EXPECTED_SECTORS	255

setting

name	value	default
-	0	yes
10	10	no
15	15	no
16	16	no
18	18	no
26	26	no
36	36	no

Force ready

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Force ready	io1:dc5:FORCE_READY	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	1	no

FLEX track zero expected sectors per side

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
FLEX track zero expected sectors per side	io1:dc5:TRACK_ZERO_EXPECTED_SECTORS	255

setting

name	value	default
-	0	yes
10	10	no
15	15	no
16	16	no
18	18	no
26	26	no
36	36	no

dipswitch

Lower RX Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lower RX Baud Rate	io0:mps2:RX_BAUD_LOWER	31

value

name	value	default
110 / 440	30	no
300 / 1200	27	no
1200 / 4800	15	no
4800 / 19200	23	no
9600 / 38400	29	yes

Upper RX Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Upper RX Baud Rate	io0:mps2:RX_BAUD_UPPER	31

value

name	value	default
110 / 440	30	no
300 / 1200	27	no
1200 / 4800	15	no
4800 / 19200	23	no
9600 / 38400	29	yes

Lower TX Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lower TX Baud Rate	io0:mps2:TX_BAUD_LOWER	31

value

name	value	default
110 / 440	30	no
300 / 1200	27	no
1200 / 4800	15	no
4800 / 19200	23	no
9600 / 38400	29	yes

Upper TX Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Upper TX Baud Rate	io0:mps2:TX_BAUD_UPPER	31

value

name	value	default
110 / 440	30	no
300 / 1200	27	no
1200 / 4800	15	no
4800 / 19200	23	no
9600 / 38400	29	yes

Address mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Address mode	io1:dc5:ADDRESS_MODE	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
4 address	0	no
16 address	1	yes

Interrupt select

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Interrupt select	io1:dc5:INTERRUPT_SELECT	3

value

name	value	default
N/C	0	yes
IRQ	1	no
NMI/FIRQ	2	no

Two control registers

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Two control registers	io1:dc5:TWO_CONTROL_REGS	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No, DC4 compatible	0	yes
Yes, DC5 extension	1	no

IRQ-A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
IRQ-A	io4:mpt:IRQA	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

IRQ-B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
IRQ-B	io4:mpt:IRQB	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	1	yes
