Star Wars Trilogy Arcade (location test, 16.09.98) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
swtrilgyp	sega/model3.cpp		no	no	no	yes	Star Wars Trilogy Arcade (location test, 16.09.98)	1998	Sega / LucasArts	swtrilgy	swtrilgy

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	496	384	57.524160	16000000	656	0	496	424	0	384	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
epr-crom3.17	2097152	84734e94	53c11ecd95292bbb5aa1466db24d6a11d7fc4abd	user1	6	good	no
epr-crom2.18	2097152	e4147534	dd61d80996692a50c84839da4f751fe4c68a38df	user1	4	good	no
epr-crom1.19	2097152	322b67a5	fa049b2a5b1726b92618dc400fad33e3fcdd5bfe	user1	2	good	no
epr-crom0.20	2097152	da7d49fa	92b366775ca2eec8c9134c8679354c39c7468ffa	user1	0	good	no
epr-crom03.01	4194304	0ddf1f80	a940e1960dd555d2d31790f6fb0155949533c26b	user1	800006	good	no
epr-crom02.02	4194304	1d69c716	ac9adfe0ef888a0903e79198c1116febbdf90ef8	user1	800004	good	no
epr-crom01.03	4194304	4d13685d	c4826447297996c7034fba731ea4582be634e957	user1	800002	good	no
epr-crom00.04	4194304	dc0d974d	f67feaf19ebe6735fb7acc7227a33a3100617fd8	user1	800000	good	no
epr-crom13.05	4194304	ead1d983	d353e7e8cd073bec4d7200e8bc4eec229765a831	user1	1800006	good	no
epr-crom12.06	4194304	fe2f392e	29a55d93c33a801b9170f840226b12209d2f3e75	user1	1800004	good	no
epr-crom11.07	4194304	a04f3b5e	822b80f03a35c0f41a90a3fddcd1ea3edb3b8c4e	user1	1800002	good	no
epr-crom10.08	4194304	7ac2dfe6	9467d7fffdc9c9f198adda8a39aa6fee53b3dc4c	user1	1800000	good	no
epr-vrom01.26	4194304	750287bb	d5284f5e97e70b8a9380d876c44c73487f310cc9	user3	2	good	no
epr-vrom00.27	4194304	ac5d8de5	4194ebbd220f538aa7a8f49cf4b260ff49719d3d	user3	0	good	no
epr-vrom03.28	4194304	9fc09636	7ec10f929e0cdf2bb67ba72fada719131b9c5a1b	user3	6	good	no
epr-vrom02.29	4194304	34190386	8d76a242773f6a48962baf3887878848a1478d09	user3	4	good	no
epr-vrom05.30	4194304	2c941427	cfaec32ca2b8dc3ad630cefad3bdadd16e9cf8cf	user3	a	good	no
epr-vrom04.31	4194304	ee0733e2	aec2a401b1e20e775ed5c8625bab20655cf528ce	user3	8	good	no
epr-vrom07.32	4194304	50b9f673	f34b352c03fe25002aecba897c619c9d7ad19f61	user3	e	good	no
epr-vrom06.33	4194304	d1c345c6	2c253644b99d9c8f921bc7b166c7ea78f0cfbe57	user3	c	good	no
epr-vrom11.34	4194304	39fe8657	82ff3f02694d44253900daa48cfe12b4882d2424	user4	2	good	no
epr-vrom10.35	4194304	fd18cb56	69de424256cb388599e3e7f59eae607b1766921f	user4	0	good	no
epr-vrom13.36	4194304	f6efe50d	ebd41f5fe429dff74200322a7e50534f9b3ed498	user4	6	good	no
epr-vrom12.37	4194304	6e4ac064	5b2f13da87255e420a0ee16de0f00be316792359	user4	4	good	no
epr-vrom15.38	4194304	ced63c05	b8a962a73ecf078dd6f52bd448ec023ea488e492	user4	a	good	no
epr-vrom14.39	4194304	2bd25533	66f23393a5e9a6f921d19503b60453ca2e1d09b8	user4	8	good	no
epr-vrom17.40	4194304	4f23de3e	5a1b9589af52142cd3435c08f335997489e8f2fb	user4	e	good	no
epr-vrom16.41	4194304	14f9785e	1febbd7e32e6d4850eb64c10d7462af2596ef865	user4	c	good	no
epr-srom0.21	524288	2bb06489	be7bbef4862fbc727a3b660790bf97b2132cb357	audiocpu	0	good	no
epr-srom1.22	4194304	0e52e2ec	7d17781fced1a06a0dc7ca590e7bef83a70e149e	samples	0	good	no
epr-srom3.24	4194304	841ed823	450b255184b503351f17ffb3b5776634ec4f02e6	samples	400000	good	no
epr-21384.2	131072	12fa4780	a10ce82d81045cc49efcfba490693d06aeced3ae	dsb2:mpegcpu	0	good	no	epr-21384.2
mpr-21375.18	4194304	735157a9	d1ff5dc7a6be8c8b0b6ba33fdf353c2008507afc	dsb2:mpeg	0	good	no	mpr-21375.18
mpr-21376.20	4194304	e635f81e	3eb4243fd275946ce0e85d074abd59b5ed31bbcd	dsb2:mpeg	400000	good	no	mpr-21376.20
mpr-21377.22	4194304	720621f8	191bd8159010c172a82159d0ebfa56637c2a8462	dsb2:mpeg	800000	good	no	mpr-21377.22
mpr-21378.24	4194304	1fcf715e	9706f36e7a61d885d34a6974311a2410fe3d6760	dsb2:mpeg	c00000	good	no	mpr-21378.24

chip

type	tag	name	clock
cpu	maincpu	IBM PowerPC 603R	166000000
cpu	audiocpu	Motorola MC68000	11289600
cpu	billboard:billcpu	Zilog Z80	8000000
cpu	comm_board:m3commcpu	Motorola MC68000	10000000
cpu	dsb2:mpegcpu	Motorola MC68000	8000000
audio	speaker	Speaker
audio	scsp1	Yamaha YMF292-F SCSP	22579200
audio	scsp2	Yamaha YMF292-F SCSP	22579200
audio	dsb2	Sega 68k-based Digital Sound Board 2

device_ref

name
ppc603r
m68000
93c46_16
nvram
rtc72421
315_5649
screen
palette
gfxdecode
speaker
scsp
scsp
segabill
z80
315_5338a
m3comm
m68000
ram
dsb2_device
m68000
i8251
clock
i8251
clock

sound

channels
1

feature

type	status	overall
graphics	imperfect
sound	imperfect

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
stick		2		no	0	255	30	30

port, analog

port_tag	analog_masks
:AN0	255
:AN1	255
:AN2
:AN3
:AN4
:AN5
:AN6
:AN7
:DSW
:IN0
:IN1
:IN2
:IN3
:billboard:dsw

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	1

location

name	number	inverted
SW	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	2

location

name	number	inverted
SW	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	4

location

name	number	inverted
SW	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	8

location

name	number	inverted
SW	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	16

location

name	number	inverted
SW	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	32

location

name	number	inverted
SW	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	64

location

name	number	inverted
SW	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	128

location

name	number	inverted
SW	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Test Winner LED P1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Winner LED P1	billboard:dsw	1

location

name	number	inverted
DSW	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Test Winner LED P2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Winner LED P2	billboard:dsw	2

location

name	number	inverted
DSW	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Test 7-Segment P1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test 7-Segment P1	billboard:dsw	4

location

name	number	inverted
DSW	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Test 7-Segment P2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test 7-Segment P2	billboard:dsw	8

location

name	number	inverted
DSW	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	billboard:dsw	16

location

name	number	inverted
DSW	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	billboard:dsw	32

location

name	number	inverted
DSW	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Demo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo	billboard:dsw	64

location

name	number	inverted
DSW	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Testmode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Testmode	billboard:dsw	128

location

name	number	inverted
DSW	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no
