SYS1121 - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
sys1121	motorola/sys1121.cpp		no	no	no	yes	SYS1121	1984	Motorola

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
vme:slot1:mvme120:rs232:terminal:terminal_screen	raster	0	640	240	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

chip

type	tag	name	clock
cpu	vme:slot1:mvme120:maincpu	Motorola MC68010	10000000
audio	vme:slot1:mvme120:rs232:terminal:bell	Speaker
audio	vme:slot1:mvme120:rs232:terminal:beeper	Beep	2000

device_ref

name
vme
vme_slot
mvme120
m68010
mc68901
rs232
serial_terminal
screen
generic_keyboard
speaker
beep
vme
vme_slot
vme_slot
vme_slot
vme_slot
vme_slot
vme_slot
vme_slot

sound

channels
1

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1		no	no
