E-22 Display Terminal - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tabe22	tab/tabe22.cpp		no	no	no	yes	E-22 Display Terminal	1986	Tab Products

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	720	378	60.000000	21756600	918	0	720	395	0	378	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
e22_u3__2.17.86__v2.00.bin	32768	fd931bc5	013d5a5ed759bb9684bff18a3e848fa6d1167e10	maincpu	0	good	no
e22_u2__2.17.86__v2.00.bin	16384	45d5e895	a2b4e04dbc881230462a38de98ed843d5683c1b9	maincpu	8000	good	no
e22_u43__char_gen.bin	8192	33880908	7f26dede2feaf3591312d67e3dabfc1ad8bb3181	chargen	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Intel 8085A	10000000

device_ref

name
i8085a
address_map_bank
screen
palette
gfxdecode
scn2674
scn2681
duart_channel
duart_channel
rs232
rs232
i8251
e22_kbd_hle

sound

channels
0

feature

type	status	overall
graphics	imperfect
sound	unemulated

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		128		no

port, analog

port_tag	analog_masks
:kbd:row_0
:kbd:row_1
:kbd:row_2
:kbd:row_3
:kbd:row_4
:kbd:row_5
:kbd:row_6
:kbd:row_7

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
host	terminal	serial_terminal	no
host	sunkbd	sunkbd_adaptor	no
host	dec_loopback	dec_rs232_loopback	no
host	ie15	ie15_terminal	no
host	null_modem	null_modem	no
host	keyboard	serial_keyboard	no
host	patch	rs232_patch_box	no
host	swtpc8212	swtpc8212_terminal	no
host	printer	serial_printer	no
host	scorpion	scorpion_ic	no
host	loopback	rs232_loopback	no
host	mockingboard	mockingboardd	no
host	msystems_mouse	rs232_mouse_hle_msystems	no
host	nss_tvi	nss_tvinterface	no
host	rs232_sync_io	rs232_sync_io	no
host	pty	pseudo_terminal	no
host	votraxtnt	serial_votraxtnt	no
host	rs_printer	rs_serial_printer	no
printer	printer	serial_printer	no
