Tank 8 (set 4) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tank8c	atari/tank8.cpp		no	no	no	yes	Tank 8 (set 4)	1976	Atari (Kee Games)	tank8	tank8

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	480	464	60.020848	22110000	703	16	496	524	0	464	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
a05071.c1	2048	2211fb2c	6d44d1e9c94a7cb364c8809445c015a6510b8c5f	maincpu	400	good	no
a05072.e1	2048	d907b116	290a77e6095d4ffc2365d784e74e115fe90617fb	maincpu	c00	good	no	a05072.e1
a05473.f1	512	109020db	c8517a09c1ff36a1b08c4a71acaae55dc48fc45b	maincpu	1400	good	no
a05474.j1	512	64d8a386	fdb6669762ddebbd775c66d67d82876428dfe009	maincpu	1600	good	no
5075.n6	512	2d6519b3	3837687893d0fca683ff9b86b335a77d98fd4230	tiles	0	good	no	5075.n6
5079.h5	256	5c32d471	983c7f15ad3a50ab87157b6894b9c292358de5a1	tank1	0	good	no	5079.h5
5078.j5	256	ab083245	e084627a4a17dd274d31638c938a04aa5049359b	tank2	0	good	no	5078.j5

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6800	1105500
audio	mono	Speaker
audio	discrete	Discrete Sound

device_ref

name
m6800
f9334
f9334
screen
gfxdecode
palette
speaker
discrete

adjuster

name	default
Crash, Explosion Volume	50

sound

channels
1

input

players	coins	service	tilt
8	8	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
doublejoy	1	1	vertical2	no					vertical2
doublejoy	2	1	vertical2	no					vertical2
doublejoy	3	1	vertical2	no					vertical2
doublejoy	4	1	vertical2	no					vertical2
doublejoy	5	1	vertical2	no					vertical2
doublejoy	6	1	vertical2	no					vertical2
doublejoy	7	1	vertical2	no					vertical2
doublejoy	8	1	vertical2	no					vertical2

port, analog

port_tag	analog_masks
:CRASH
:DSW1
:DSW2
:P1
:P2
:P3
:P4
:P5
:P6
:P7
:P8
:RC
:VBLANK

dipswitch

Play Time

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Play Time	DSW1	15

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
60 seconds	15	no
70 seconds	7	no
80 seconds	11	no
90 seconds	3	no
100 seconds	13	no
110 seconds	5	no
120 seconds	9	no
130 seconds	1	no
140 seconds	14	no
150 seconds	6	no
160 seconds	10	no
170 seconds	2	no
180 seconds	12	no
190 seconds	4	no
200 seconds	8	yes
210 seconds	0	no

Remote

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remote	DSW2	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no
