Tecmo Bowl (World, set 1) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Lists: 731 - Software: 139884 - rom: 235974 - disk: 11384

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tbowl	tecmo/tbowl.cpp		no	no	no	yes	Tecmo Bowl (World, set 1)	1987	Tecmo

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
lscreen	raster	0	256	224	60.000000								no
rscreen	raster	0	256	224	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
4.b11	32768	db8a4f5d	730dee040c18ed8736c07a7de0b986f667b0f2f5	maincpu	0	good	no
6206b-5.b13	65536	133c5c11	7d4e76db3505ccf033d0d9b8d21feaf09b76dcc4	maincpu	10000	good	no
6206c-24.h5	65536	040c8138	f6fea192bf2ef0a3f0876133c761488184f54f50	sub	0	good	no
6206c-25.h7	65536	92c3cef5	75883663b309bf46be544114c6e9086ab222300d	sub	10000	good	no
6206a-1.f11	32768	4370207b	2c929b571c86d35e646870644751e86bd16b5e22	audiocpu	0	good	no
14.13l	32768	f9cf60b9	0a79ed29f82ac7bd08062f922f79e439c194f30a	characters	0	good	no
15.15l	32768	a23f6c53	0bb64894a27f41d74117ec492aafd52bc5b16ca4	characters	1	good	no
6206b-8.e1	65536	b9615ffa	813896387291f5325ed7e4058347fe35c0d7b839	bg_tiles	40001	good	no
6206b-8.e4	65536	6389c719	8043907d6f5b37228c09f05bbf12b4b9bb9bc130	bg_tiles	40000	good	no
6206b-7.e2	65536	d139c397	4093220e6bddb95d0af445944bead7a064b64c39	bg_tiles	1	good	no
6206b-9.e6	65536	975ded4c	4045ee12f43dd23dadf6f9d0f7b25d04f9fda3d8	bg_tiles	0	good	no
6206b-10.l1	65536	9b4fa82e	88df18985a04c6653a71db07fbbe0ce0670fe540	bg_tiles	60001	good	no
6206b-12.l4	65536	7d0030f6	24f0eca87ce38b974b9f359dd5f12f3be1ae7ff1	bg_tiles	60000	good	no
6206b-11.l2	65536	06bf07bb	9f12a39b8832bff2ffd84b7e6c1ddb2855ff924b	bg_tiles	20001	good	no
6206b-13.l6	65536	4ad72c16	554474987349b5b11e181ee8a2d1308777b030c1	bg_tiles	20000	good	no
6206c-16.b11	65536	1a2fb925	bc96ee87372826d5bee2b4d2aefde4c47b9ee80a	sprites	60001	good	no
6206c-20.d11	65536	70bb38a3	5145b246f7720dd0359b97be35aa027af07cb6da	sprites	60000	good	no
6206c-17.b13	65536	de16bc10	88e2452c7caf44cd541c27fc56c99703f3330bd7	sprites	40001	good	no
6206c-21.d13	65536	41b2a910	98bf0fc9728240f35385ab0370bb47108f2d2bc2	sprites	40000	good	no
6206c-18.b14	65536	0684e188	3d3c71c915cff62021baa17df37d0a68847d57cf	sprites	20001	good	no
6206c-22.d14	65536	cf660ebc	3ca9577a36708c44a1bc9238faf14dbab1a0c3ca	sprites	20000	good	no
6206c-19.b16	65536	71795604	57ef4f14dfe1829d5dddeba81bf2f7354d971d27	sprites	1	good	no
6206c-23.d16	65536	97fba168	107de19614d57453a37462e1a4d499d14633d50b	sprites	0	good	no
6206a-3.l18	65536	3aa24744	06de3f9a2431777218cc67f59230fddbfa01cf2d	adpcm	0	good	no
6206a-2.l16	65536	1e9e5936	60370d1de28b1c5ffeff7843702aaddb19ff1f58	adpcm	10000	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	8000000
cpu	sub	Zilog Z80	8000000
cpu	audiocpu	Zilog Z80	4000000
audio	mono	Speaker
audio	ym1	YM3812 OPL2	4000000
audio	ym2	YM3812 OPL2	4000000
audio	msm1	OKI MSM5205 ADPCM	384000
audio	msm2	OKI MSM5205 ADPCM	384000

device_ref

name
z80
z80
z80
gfxdecode
palette
tecmo_spr
screen
screen
speaker
generic_latch_8
ym3812
ym3812
msm5205
msm5205

sound

channels
1

input

players	coins	service	tilt
4	4	no	no

control

type	player	buttons	ways	reverse
joy	1	2	8	no
joy	2	2	8	no
joy	3	2	8	no
joy	4	2	8	no

port, analog

port_tag	analog_masks
:DSW1
:DSW2
:DSW3
:P1
:P2
:P3
:P4
:SYSTEM

dipswitch

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW1	7

location

name	number	inverted
SW1	1	no
SW1	2	no
SW1	3	no

value

name	value	default
8 Coins/1 Credit	0	no
7 Coins/1 Credit	1	no
6 Coins/1 Credit	2	no
5 Coins/1 Credit	3	no
4 Coins/1 Credit	4	no
3 Coins/1 Credit	5	no
2 Coins/1 Credit	6	no
1 Coin/1 Credit	7	yes

Time (Players)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Time (Players)	DSW1	248

location

name	number	inverted
SW1	4	no
SW1	5	no
SW1	6	no
SW1	7	no
SW1	8	no

value

name	value	default
7:00	0	no
6:00	8	no
5:00	16	no
4:30	24	no
3:40	32	no
3:20	40	no
3:00	48	no
2:50	56	no
2:40	64	no
2:30	72	no
2:20	80	no
2:10	88	no
2:00	96	no
1:55	104	no
1:50	112	no
1:45	120	no
1:40	128	no
1:35	136	no
1:25	144	no
1:20	152	no
1:15	160	no
1:10	168	no
1:05	176	no
1:00	184	yes
1:00	248	no
0:55	192	no
0:50	200	no
0:45	208	no
0:40	216	no
0:35	224	no
0:30	232	no
0:25	240	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSW2	3

location

name	number	inverted
SW2	1	no
SW2	2	no

value

name	value	default
Easy	2	no
Normal	3	yes
Hard	1	no
Hardest	0	no

Extra Time (Players)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Extra Time (Players)	DSW2	12

location

name	number	inverted
SW2	3	no
SW2	4	no

value

name	value	default
0:30	0	no
0:20	4	no
0:10	8	no
None	12	yes

Timer Speed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Timer Speed	DSW2	48

location

name	number	inverted
SW2	5	no
SW2	6	no

value

name	value	default
Slowest	0	no
Slow	16	no
Normal	48	yes
Fast	32	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW2	64

location

name	number	inverted
SW2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	64	yes

Hi-Score Reset

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hi-Score Reset	DSW2	128

location

name	number	inverted
SW2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	128	yes

Time (Quarter)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Time (Quarter)	DSW3	3

location

name	number	inverted
SW3	1	no
SW3	2	no

value

name	value	default
8:00	0	no
5:00	1	no
4:00	3	yes
3:00	2	no

Bonus Frequency

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Frequency	DSW3	12

location

name	number	inverted
SW3	3	no
SW3	4	no

value

name	value	default
Most	0	no
More	4	no
Normal	8	yes
Least	12	no
