Total Control 4 - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tc4	handheld/hh_tms1k.cpp		no	no	no	yes	Total Control 4	1981	Coleco

snap

Total Control 4 png snap

Total Control 4 jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
tc4	9957	29/12/2025 11:31:46	640	480	96	96	0	Format24bppRgb	305:MAME 0.203 (Oct 31 2018)	f11c0a8c16600594be047e9293b09ae504a30299

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
mp7334	4096	923f3821	a9ae342d7ff8dae1dedcd1e4984bcfae68586581	maincpu	0	good	no
tms1100_common1_micro.pla	867	62445fc9	d6297f2a4bc7a870b76cc498d19dbb0ce7d69fec	maincpu:mpla	0	good	no
tms1400_tc4_output.pla	557	3b908725	f83bf5faa5b3cb51f87adc1639b00d6f9a71ad19	maincpu:opla	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS1400	450000
audio	mono	Speaker
audio	speaker	Filtered DAC

softwarelist

tag	name	status	filter
cart_list	tc4	original

device_ref

tag	name
:maincpu	tms1400
:maincpu:mpla	pla
:maincpu:opla	pla
:display	pwm_display
:mono	speaker
:speaker	speaker_sound_device
:cartslot	generic_cartslot
:cart_list	software_list

sound

channels
1

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
cartridge	cartslot	tc4_cart		1	cartridge	cart

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
cartridge	cartslot	tc4_cart		1	bin

input

players	coins	service	tilt
2		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
doublejoy	1	4	8	no					8
doublejoy	2	4	8	no					8

port, analog

port_tag	analog_masks
:IN.0
:IN.1
:IN.2
:IN.3
:IN.4
:IN.5

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
cartslot
