TDV-2115L - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tdv2115l	tandberg/tdv2115l.cpp		no	no	no	yes	TDV-2115L	1976	Tandberg

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
tdv2115l	966	29/12/2025 11:31:46	783	350	96	96	0	Format24bppRgb	305:MAME 0.262.0 (Jan 31 2024)	1dcdead3a325abcab385a5f510f3d47c1fbb8114

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
terminal:screen	raster	0	783	350	50.486307	20275200	999	0	783	402	0	350	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

chip

type	tag	name	clock
audio	terminal:mono	Speaker
audio	terminal:beep	Beep	2000

device_ref

tag	name
:terminal	tandberg_tdv2100_disp_logic
:terminal:screen	screen
:terminal:palette	palette
:terminal:mono	speaker
:terminal:beep	beep
:terminal:serial	rs232
:terminal:uart	ay51013
:terminal:uart_clock	clock
:keyboard	tandberg_tdv2100_keyboard
:keyboard:scan_clock	clock

adjuster

name	default
Key-repeat delay (500ms - 1250ms)	40
Key-repeat rate (10Hz - 30Hz)	50

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keyboard		99		no

port, analog

port_tag	analog_masks
:keyboard:X0
:keyboard:X1
:keyboard:X10
:keyboard:X11
:keyboard:X12
:keyboard:X13
:keyboard:X14
:keyboard:X2
:keyboard:X3
:keyboard:X4
:keyboard:X5
:keyboard:X6
:keyboard:X7
:keyboard:X8
:keyboard:X9
:keyboard:key_repeat_delay
:keyboard:key_repeat_rate
:keyboard:sw_all_cap
:terminal:dsw_u39
:terminal:dsw_u61
:terminal:dsw_u73
:terminal:sw_invert_video
:terminal:sw_rs232_baud
:terminal:sw_rs232_settings

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
terminal:serial	terminal	serial_terminal	no
terminal:serial	sunkbd	sunkbd_adaptor	no
terminal:serial	votraxtnt	serial_votraxtnt	no
terminal:serial	rs_printer	rs_serial_printer	no
terminal:serial	dec_loopback	dec_rs232_loopback	no
terminal:serial	h19	serial_heath_h19	no
terminal:serial	ie15	ie15_terminal	no
terminal:serial	null_modem	null_modem	no
terminal:serial	keyboard	serial_keyboard	no
terminal:serial	patch	rs232_patch_box	no
terminal:serial	swtpc8212	swtpc8212_terminal	no
terminal:serial	printer	serial_printer	no
terminal:serial	scorpion	scorpion_ic	no
terminal:serial	loopback	rs232_loopback	no
terminal:serial	mockingboard	mockingboardd	no
terminal:serial	msystems_mouse	rs232_mouse_hle_msystems	no
terminal:serial	nss_tvi	nss_tvinterface	no
terminal:serial	rs232_sync_io	rs232_sync_io	no
terminal:serial	pty	pseudo_terminal	no

configuration

ALL CAP

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
ALL CAP	keyboard:sw_all_cap	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

INVERSE VIDEO

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
INVERSE VIDEO	terminal:sw_invert_video	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

SPEED SELECT [Note: Baud-rate]

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
SPEED SELECT [Note: Baud-rate]	terminal:sw_rs232_baud	7

setting

name	value	default
0: 110	0	no
1: 300	1	no
2: 600	2	no
3: 1200	3	no
4: 2400	4	no
5: 4800	5	no
6: 9600	6	yes
7: 19200	7	no

RS-232 Parity checking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RS-232 Parity checking	terminal:sw_rs232_settings	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

RS-232 Parity type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RS-232 Parity type	terminal:sw_rs232_settings	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Odd	0	no
Even	2	yes

RS-232 Number of stop bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RS-232 Number of stop bits	terminal:sw_rs232_settings	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
One	0	no
Two	4	yes

RS-232 Internal local echo when on-line (for half duplex)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RS-232 Internal local echo when on-line (for half duplex)	terminal:sw_rs232_settings	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

RS-232 Automatic CTS with RTS

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RS-232 Automatic CTS with RTS	terminal:sw_rs232_settings	16

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	16	no

RS-232 Automatic DSR with DTR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RS-232 Automatic DSR with DTR	terminal:sw_rs232_settings	32

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	32	no

dipswitch

ACK/NACK/ENQUIRY lamps

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
ACK/NACK/ENQUIRY lamps	terminal:dsw_u39	3

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Reset with CLEAR key	1	yes
Reset with SYN ctrl-char (^V)	2	no

Rx handshake source

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Rx handshake source	terminal:dsw_u39	12

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
DSR	4	yes
DCD	8	no

Operating mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Operating mode	terminal:dsw_u39	16

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
TTY mode (no CPU)	16	yes
CPU mode (CPU module required)	0	no

DTR/RTS signals

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
DTR/RTS signals	terminal:dsw_u39	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Affected by LINE/TRANS keys	32	yes
Permanently asserted	0	no

ON LINE lamp lit when

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
ON LINE lamp lit when	terminal:dsw_u39	192

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Only if both RTS and CTS	64	yes
RTS regardless of CTS	128	no

Automatic page-roll after end of page

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Automatic page-roll after end of page	terminal:dsw_u39	256

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	no
On	0	yes

RS-232 data length

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RS-232 data length	terminal:dsw_u39	512

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
8 data bits	512	no
7 data bits	0	yes

Horizontal space between chars

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Horizontal space between chars	terminal:dsw_u61	3

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Duplicate edge of previous char	1	yes
Draw gap	2	no

Automatic CR+LF after end of line

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Automatic CR+LF after end of line	terminal:dsw_u61	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	4	yes

Display mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Display mode	terminal:dsw_u61	8

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Undeline mode	8	no
Attribute mode	0	yes

Cursor blinking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor blinking	terminal:dsw_u61	48

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	no
On	32	yes

Hide Attribute-changes or Underlined chars

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hide Attribute-changes or Underlined chars	terminal:dsw_u61	64

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	no
On	0	yes

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	terminal:dsw_u61	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Hide ASCII control characters

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Hide ASCII control characters	terminal:dsw_u61	256

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	256	no
On	0	yes

Cursor shape

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor shape	terminal:dsw_u61	512

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Block	512	no
Line	0	yes

Automatic RTS with DTR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Automatic RTS with DTR	terminal:dsw_u73	3

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	2	no

Current-Loop RxD line (Unused)

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Current-Loop RxD line (Unused)	terminal:dsw_u73	12

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
10V zener-diode in series	4	no
47 Ohm series resistor	8	yes
