name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tenpindx	midway/astrocde.cpp		no	no	yes	yes	Ten Pin Deluxe	1983	Dave Nutting Associates / Bally Midway

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	352	240	60.054442	7159090	455	0	352	262	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
tpd_x1.bin	8192	ef424484	d70f8491059e24775ee05140c8c3b0afa6c1107c	maincpu	0	good	no
tpd_x2.bin	8192	a0f53af2	966a98f73bdd358601f105ca97c823575b33bab3	maincpu	2000	good	no
tpd_x9.bin	8192	ce9a9bd4	fcc48a66b6079c56992afef2ca8ab95c66f8f431	maincpu	c000	good	no
tpd_axfd.bin	16384	0aed11f3	09575cceda38178a77c6753074be82825d368334	sub	0	good	no
tpd_x3.bin	8192	d4645f6d	185bcd58f1ba69e26274475c57219de0353267e1	banks	4000	good	no
tpd_x4.bin	8192	acf474ba	b324dccac0991660f8ba2a70cbbdb06c9d25c361	banks	6000	good	no
tpd_x5.bin	8192	e206913f	bb9476516bca7bf7066df058db36e4fdd52a6ed2	banks	8000	good	no
tpd_x6.bin	8192	d90142fb	01ac2ba60105a8dc84359a8feafd2fea2a635369	banks	a000	good	no
tpd_x8.bin	8192	ae22cf50	bc6aa59e41cffc840e5cffcd352d8c12c053982d	banks	e000	good	no
tpd_x10.bin	8192	85d5b970	24206cb2829674910e7648ccd30b9fddda9bec95	banks	10000	good	no
tpd_x11.bin	8192	7bd3c90f	d6c2f547c83972668e123203906b3e7fb52c1696	banks	12000	good	no
tpd_x12.bin	8192	46078cc7	50ac83f73dcca74c736961001c0808b379a949f4	banks	14000	good	no
tpd_x13.bin	8192	b49767b4	71aba2967afe95f0d78f539aae9e7bf9a1315aa0	banks	16000	good	no
tpd_x14.bin	8192	29a28d40	c4d6b4b1881e674337e47f801291e94d73a0fcbd	banks	18000	good	no
tpd_x15.bin	8192	2ae98fb2	a8b4058189bf23fec281da3ff73393346bfead6f	banks	1a000	good	no
tpd_x16.bin	8192	8839d0e1	5f1e581066d1851ee996f152ebec83db40aa7073	banks	1c000	good	no
pls153a_cpu.u12	235	499a6fc5	633d647bcae2f762847a2abe8069741ac33b15b8	plds	0	good	no
pls153a_cpu.u16	235	9a5ea540	8619c7626e58eac09a4d91f5ad49742240f5f71e	plds	100	good	no
pls153a_epr.u6	235	d8454bf7	5e074a2cbac99ebbf02bc4cd331679ede30eea3f	plds	200	good	no
pls153a_epr.u7	235	fa831d9f	ca8c3d8db24e99537c682aaf9726cbcef86728dd	plds	300	good	no
pls153a_gam.u10	235	fe2157b0	577e6839190054f9b3aec6425e9d2a1810e11a08	plds	400	good	no
pls153a_gam.u11	235	5772f6d8	01a02aa67a42ff61e38e12683b02bf81c16519b8	plds	500	good	no
pls153a_gam.u5	235	b3f2c6b8	e49fb4ca7d9c8a769c145fd497b1244d6696831f	plds	600	good	no
pls153a_scr.u19	235	b5fff2db	beae4fc5664d15a4b83a885d97d21efd14977380	plds	700	good	no
pls153a_scr.u39	235	ba7ef5dd	7aea6e17edbf87dc1d47ca8c640b50ebdb65dd29	plds	800	good	no
pls153a_scr.u55	235	c3f47134	78ae2cc1d8b761b077e36343d4a91517298ce9e8	plds	900	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	1789772
cpu	sub	Zilog Z80	1789772
audio	mono	Speaker
audio	aysnd	AY-3-8912A PSG	1789772

device_ref

name
z80
palette
screen
address_map_bank
nvram
z80
z80ctc
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80ctc_channel
speaker
generic_latch_8
ay8912

sound

channels
1

input

players	coins	service	tilt
1	2	no	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
only_buttons		2		no

port, analog

port_tag	analog_masks
:DIPSW
:P60
:P61
:P62
:P63
:P64

dipswitch

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIPSW	1

location

name	number	inverted
S2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIPSW	2

location

name	number	inverted
S2	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIPSW	4

location

name	number	inverted
S2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIPSW	8

location

name	number	inverted
S2	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	8	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIPSW	16

location

name	number	inverted
S2	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	16	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIPSW	32

location

name	number	inverted
S2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	32	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIPSW	64

location

name	number	inverted
S2	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DIPSW	128

location

name	number	inverted
S2	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	P60	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	P61	1

location

name	number	inverted
S1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright	1	yes
Cocktail	0	no

Lockup

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lockup	P61	2

location

name	number	inverted
S1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	2	yes
Yes	0	no

Reset

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Reset	P61	4

location

name	number	inverted
S1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes

Beep

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Beep	P61	8

location

name	number	inverted
S1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	8	no
Yes	0	yes

Regulation

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Regulation	P61	16

location

name	number	inverted
S1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	16	yes
Yes	0	no

Ticket Dispenser

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Ticket Dispenser	P61	32

location

name	number	inverted
S1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	32	yes
Yes	0	no

Bill Acceptor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bill Acceptor	P61	64

location

name	number	inverted
S1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	64	yes
Yes	0	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	P61	128

location

name	number	inverted
S1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no
