mame (0289) • machine tg100 • TG100

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tg100	yamaha/tg100.cpp		no	no	no	yes	TG100	1991	Yamaha

snap

TG100 png snap

TG100 jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
tg100	7337	26/03/2026 09:19:39	640	480	96	96	0	Format24bppRgb	305:MAME 0.286 (mame0286)	1ec368d51c48dad22ee642cb4738e2b711d72141

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	lcd	0	96	8	80.000000	61440	96	0	96	8	0	8	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
xk731c0.ic4	131072	8fb6139c	483103a2ffc63a90a2086c597baa2b2745c3a1c2	prgrom	0	good	no
xk992a0.ic6	2097152	01dc6954	32ec77a46f4d005538c735f56ad48fa7243c63be	ymw258	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Hitachi HD6435208 (H8/520)	20000000
audio	speaker	Speaker
audio	ymw258	Yamaha YMW-258-F	9400000

device_ref

tag	name
:maincpu	hd6435208
:maincpu:intc	h8520_intc
:maincpu:adc	h8_adc_3337
:maincpu:frt	h8_timer16
:maincpu:frt:0	h8500_frt
:maincpu:frt:1	h8500_frt
:maincpu:tmr	h8_timer8_channel
:maincpu:port1	h8_digital_port
:maincpu:port2	h8_digital_port
:maincpu:port3	h8_digital_port
:maincpu:port4	h8_digital_port
:maincpu:port5	h8_digital_port
:maincpu:port6	h8_digital_port
:maincpu:port7	h8_digital_port
:maincpu:sci0	h8_sci
:maincpu:sci1	h8_sci
:maincpu:watchdog	h8_watchdog
:mdin	midi_port
:mdin:midiin	midiin_port
:mdin:midiin:midiinimg	midiin
:mdout	midi_port
:mdout:midiout	midiout_port
:mdout:midiout:midioutimg	midiout
:eeprom	93c46_16
:speaker	speaker
:ymw258	ymw258f
:screen	screen
:palette	palette
:lcd	hd44780

sound

channels
1

feature

type	status	overall
sound	imperfect

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
midiin	mdin:midiin:midiinimg				midiin	min
midiout	mdout:midiout:midioutimg				midiout	mout

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
midiin	mdin:midiin:midiinimg				mid, syx
midiout	mdout:midiout:midioutimg				mid

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
only_buttons		6		no

port, analog

port_tag	analog_masks
:BUTTONS
:HOST_SELECT
:LOOPBACK
:mdin:midiin:midiinimg:CFG

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
mdin	midiin	midiin_port	yes
mdout	midiout	midiout_port	yes

configuration

Host Select

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Host Select	HOST_SELECT	3

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
MIDI	0	yes
PC-2 (NEC PC-98)	1	no
PC-1 (IBM PC AT)	2	no
Macintosh	3	no

MIDI Loopback

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI Loopback	LOOPBACK	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	1	no

MIDI file mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
MIDI file mode	mdin:midiin:midiinimg:CFG	255

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Multi	255	yes
Poly: Channel 1	0	no
Poly: Channel 2	1	no
Poly: Channel 3	2	no
Poly: Channel 4	3	no
Poly: Channel 5	4	no
Poly: Channel 6	5	no
Poly: Channel 7	6	no
Poly: Channel 8	7	no
Poly: Channel 9	8	no
Poly: Channel 10	9	no
Poly: Channel 11	10	no
Poly: Channel 12	11	no
Poly: Channel 13	12	no
Poly: Channel 14	13	no
Poly: Channel 15	14	no
Poly: Channel 16	15	no
