TI-1680 - mame (0285) machine

MAME: 0285 - Released: 2026-01-29T17:50:05 - Machines: 49616 - rom: 367884 - disk: 1392

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ti1680	handheld/hh_tms1k.cpp		no	no	no	yes	TI-1680	1977	Texas Instruments

snap

TI-1680 png snap

TI-1680 jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems
ti1680	7265	29/12/2025 11:31:46	640	100	96	96	0	Format24bppRgb	305:MAME 0.234 (Jul 28 2021)

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	yes	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
tmc1981nl	4096	8467c5a1	d3a48f6c9dd41e2dc0e0cfafa84dac8d21aacaa3	maincpu	0	good	no
tms0980_common1_instr.pla	1246	42db9a38	2d127d98028ec8ec6ea10c179c25e447b14ba4d0	maincpu:ipla	0	good	no
tms0270_common2_micro.pla	2127	86737ac1	4aa0444f3ddf88738ea74aec404c684bf54eddba	maincpu:mpla	0	good	no
tms1980_ti1680_output.pla	525	188af340	eaf707266dde0d708870ef5d8f985ce88d35b43e	maincpu:opla	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS1980	300000

device_ref

tag	name
:maincpu	tms1980
:maincpu:ipla	pla
:maincpu:mpla	pla
:maincpu:opla	pla
:ram	tmc0999
:display	pwm_display

sound

channels
0

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad		24		no

port, analog

port_tag	analog_masks
:IN.0
:IN.1
:IN.2
:IN.3
:IN.4
:IN.5
