Titanic (coin dropper, CPU 1.01, display A1.01) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
titanic	pinball/whitestar.cpp	genpin	no	no	yes	yes	Titanic (coin dropper, CPU 1.01, display A1.01)	1998	Sega

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
decodmd:dmd	raster	0	128	32	60.000000	245760	128	0	128	32	0	32	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	yes	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
titacpu.101	131072	4217becf	8b7aacbe75717f13623f6ceaa4ba2de61b1b732a	maincpu	0	good	no
titadspa.101	524288	5b4300b6	c2b2de20f6c74b71d2a9ac43c17694eadd795586	decodmd	0	good	no
titau7.101	65536	544fe1ac	5c62eef6a42660b13e626d1a6bb8cd09b77b0cc1	decobsmt:soundcpu	0	good	no
titau17.100	524288	ab919e99	8735b632a62d9cd3db26b3c832785c48552ba231	decobsmt:bsmt	0	good	no
titau21.100	524288	76ca05f8	3e1c56fe37393c345111665fd8ab730d53cb6970	decobsmt:bsmt	80000	good	no
16v8d.u213	279	942d99fd	db33b16e582c6762ac6843a3613edb733cbeb499	plds	0	baddump	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC6809E	2000000
cpu	decobsmt:soundcpu	Motorola MC6809E	2000000
cpu	decobsmt:bsmt:bsmt2000	Texas Instruments TMS32015	24000000
cpu	decodmd:dmdcpu	Motorola MC6809E	2000000
audio	mechvol	Speaker
audio	samples	Samples
audio	speaker	Speaker
audio	decobsmt	Data East/Sega/Stern BSMT2000 Sound Board
audio	decobsmt:bsmt	BSMT2000	24000000

device_ref

name
mc6809e
nvram
speaker
samples
speaker
decobsmt
mc6809e
bsmt2000
tms32015
decodmd2
mc6809e
timer
mc6845
screen

sample

name
bumper
chime1
chime2
chime3
chime4
hole
knocker
sling
coinin
outhole
kickback
drop_target_reset
coil_coinlockout_engage
coil_coinlockout_release
relay_engage
relay_release
solenoid_engage
solenoid_release

sound

channels
2

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1	3	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		66		no

port, analog

port_tag	analog_masks
:DEDICATED
:DSW0
:X0
:X1
:X2
:X3
:X4
:X5
:X6
:X7
