Kasparov Team-Mate - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tmate	saitek/turbo16k.cpp		no	no	no	yes	Kasparov Team-Mate	1988	Saitek / Heuristic Software	conquist	conquist

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
1988_sx8a_saitek_31y0g84p.u1	16384	083e0346	32bd8609d16c885afbd5566c64330f84f3c46099	maincpu	0	good	no	1988_sx8a_saitek_31y0g84p.u1

chip

type	tag	name	clock
cpu	maincpu	Hitachi HD6301Y0	8000000
audio	speaker	Speaker
audio	dac	1-Bit DAC

device_ref

name
hd6301y0
sensorboard
pwm_display
speaker
dac

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keypad		17		no

port, analog

port_tag	analog_masks
:FREQ
:IN.0
:IN.1
:RESET
:board:BS_CHECK
:board:CONF
:board:RANK.1
:board:RANK.10
:board:RANK.2
:board:RANK.3
:board:RANK.4
:board:RANK.5
:board:RANK.6
:board:RANK.7
:board:RANK.8
:board:RANK.9
:board:SPAWN
:board:SS_CHECK
:board:UI
:board:UI_CHECK

configuration

CPU Frequency

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
CPU Frequency	FREQ	136

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
8MHz (Team-Mate)	8	yes
12MHz (Conquistador)	128	no

Remember Position

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Remember Position	board:CONF	3	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	1	no
Yes	2	no
Auto	0	yes

Show Pieces

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Show Pieces	board:CONF	4	UI_CHECK	4	ne	0

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	4	no
Yes	0	yes
