TMS9995 breadboard - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tms9995bb	ti/evmbug.cpp		no	no	no	yes	TMS9995 breadboard	19??	Stuart Conner	evmbug	evmbug

snap

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
tms9995bb	1057	29/12/2025 11:31:47	640	240	96	96	0	Format24bppRgb	305:MAME 0.242 (Apr 1 2022)	dc4eb29b64b98fe81644ae88a0b200c70623517e

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
terminal:terminal_screen	raster	0	640	240	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	yes	no

rom

name	size	crc	sha1	region	status	optional	bios
evmbug.bin	32768	a239ec56	65b500d7d0f897ce0c320cf3ec32ff4042774599	maincpu	good	no	evmbug
basicram.bin	32768	6ed5aba3	76e0e39c0c0028efca339fb3cebaf42351fadb94	maincpu	good	no	basicram
basicrom.bin	32768	ded6350b	83cf64834e59e216a91065c01ec91be1e10e7244	maincpu	good	no	basicrom
forth.bin	32768	eee8f390	59fc2a23c9ac52dce09a519c784db378782242b1	maincpu	good	no	forth
test1.bin	32768	9b110ffb	58ee990fb17822a879442b98f1b78ccf86b79f00	maincpu	good	no	test1
test2.bin	32768	e7a7832d	aa8c29097033804d1a0abf2af7cd846edfbd71a3	maincpu	good	no	test2
test3.bin	32768	a28579eb	477f853970f132592714bcdd048ec932e96c8593	maincpu	good	no	test3

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS9995	12000000
audio	terminal:bell	Speaker
audio	terminal:beeper	Beep	2000

device_ref

tag	name
:maincpu	tms9995
:terminal	generic_terminal
:terminal:terminal_screen	screen
:terminal:keyboard	generic_keyboard
:terminal:bell	speaker
:terminal:beeper	beep

biosset

name	description	default
evmbug	EVMBUG system monitor	no
basicram	EVMBUG system monitor and BASIC in RAM	no
basicrom	EVMBUG system monitor and BASIC in ROM	no
forth	EVMBUG system monitor and Forth	no
test1	Test EPROM 1	no
test2	Test EPROM 2	no
test3	Test EPROM 3	no

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keyboard		73		no

port, analog

port_tag	analog_masks
:terminal:TERM_CONF
:terminal:keyboard:GENKBD_CFG
:terminal:keyboard:GENKBD_MOD
:terminal:keyboard:GENKBD_ROW0
:terminal:keyboard:GENKBD_ROW1
:terminal:keyboard:GENKBD_ROW2
:terminal:keyboard:GENKBD_ROW3

configuration

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	terminal:TERM_CONF	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type	terminal:TERM_CONF	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Underline	0	no
Block	2	yes

Blinking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blinking	terminal:TERM_CONF	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	4	yes

Invert

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Invert	terminal:TERM_CONF	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Color	terminal:TERM_CONF	48

setting

name	value	default
Green	0	yes
Amber	16	no
White	32	no

Auto CR on LF

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto CR on LF	terminal:TERM_CONF	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	64	yes

Auto LF on CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto LF on CR	terminal:TERM_CONF	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	128	no

Local echo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Local echo	terminal:TERM_CONF	256

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	256	no

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	terminal:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	terminal:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	terminal:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no
