Top Draw (encrypted, set 1) - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
topdraw	misc/norautp.cpp		no	no	no	yes	Top Draw (encrypted, set 1)	198?	SMS Manufacturing Corp.

snap

Top Draw (encrypted, set 1) png snap

Top Draw (encrypted, set 1) jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
topdraw	1126	31/03/2026 14:27:23	464	248	96	96	0	Format24bppRgb	305:MAME 0.287 (mame0287)	0eace2df28cc9b377c42f7e33c9bd66b9271b7bd

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	464	248	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
nosticker_db_am27c256.u12	32768	e451df9c	30a2c42d87301df5fb82a59326c9754007737325	maincpu	0	good	no
u-31_top_draw_2732a.u31	4096	d0291d61	4db617f1683bd07b0e124a0566691535f56b66de	gfx	0	good	no
n82s129n.u51	256	e982df41	ddea558af8ff95913aef42bdc712b3974d621dc0	proms	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Intel 8080	2000000
audio	mono	Speaker
audio	discrete	Discrete Sound

device_ref

tag	name
:maincpu	i8080
:nvram	nvram
:ppi8255_0	i8255
:ppi8255_1	i8255
:ppi8255_2	i8255
:screen	screen
:gfxdecode	gfxdecode
:palette	palette
:hopper	coin_hopper
:mono	speaker
:discrete	discrete
:test_timer	timer

sound

channels
1

feature

type	status	overall
protection	imperfect

input

players	coins	service	tilt
1	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
gambling		11		no

port, analog

port_tag	analog_masks
:DSW1
:IN0
:IN1
:IN2
:hopper:TEST

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	1

location

name	number	inverted
DSW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	2

location

name	number	inverted
DSW1	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	4

location

name	number	inverted
DSW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	8

location

name	number	inverted
DSW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Cards to discard

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cards to discard	DSW1	16

location

name	number	inverted
DSW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
All 5 cards	16	yes
Max 3 cards	0	no

2 Jokers in Deck

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
2 Jokers in Deck	DSW1	96

location

name	number	inverted
DSW1	2	no
DSW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Never	96	yes
When 8 or more is bet	64	no
When 4 or more is bet	32	no
Always	0	no

Test Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Mode	DSW1	128

location

name	number	inverted
DSW1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

clones

name	description
topdrawa	Top Draw (encrypted, set 2)
topdrawb	Top Draw (encrypted, set 3)
topdrawba	Top Draw (encrypted, set 4)
