TS803H - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
ts803h	televideo/ts803.cpp		no	no	no	yes	TS803H	1983	Televideo

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	640	240	60.000000	9216000	640	0	640	240	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	status	optional
180001-37 rev d 803 5 23 84.a57	8192	0aa658a7	42d0a89c2ff9b6588cd88bdb1f800fac540dccbb	roms	good	no
8000134.a59	256	231fe6d6	3c052ba4b74547e0e2451fa1ae67bbcb83a18bab	proms	good	no
803h_vid.a119	2048	d5ce2814	ce527479464757223dffac384a85ab74b174952c	chargen	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	4000000
audio	fdc:0:525dd:flopsndout	Speaker
audio	fdc:0:525dd:floppysound	Floppy sound	44100
audio	fdc:1:525dd:flopsndout	Speaker
audio	fdc:1:525dd:floppysound	Floppy sound	44100

device_ref

name
z80
screen
palette
sy6545_1
clock
clock
z80sti
z80dart
z80dart_channel
z80dart_channel
rs232
serial_keyboard
fd1793
floppy_connector
floppy_525_dd
speaker
flopsnd
floppy_connector
floppy_525_dd
speaker
flopsnd

sound

channels
2

device, instance

type	tag	interface	fixed_image	mandatory	name	briefname
floppydisk	fdc:0:525dd	floppy_5_25			floppydisk1	flop1
floppydisk	fdc:1:525dd	floppy_5_25			floppydisk2	flop2

device, extension

type	tag	interface	fixed_image	mandatory	extension_names
floppydisk	fdc:0:525dd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	fdc:1:525dd	floppy_5_25			mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		73		no

port, analog

port_tag	analog_masks
:DSW
:rs232:keyboard:GENKBD_CFG
:rs232:keyboard:GENKBD_MOD
:rs232:keyboard:GENKBD_ROW0
:rs232:keyboard:GENKBD_ROW1
:rs232:keyboard:GENKBD_ROW2
:rs232:keyboard:GENKBD_ROW3
:rs232:keyboard:RS232_DATABITS
:rs232:keyboard:RS232_PARITY
:rs232:keyboard:RS232_STOPBITS
:rs232:keyboard:RS232_TXBAUD

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	yes
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	votraxtnt	serial_votraxtnt	no
rs232	rs_printer	rs_serial_printer	no
fdc:0	525dd	floppy_525_dd	yes
fdc:1	525dd	floppy_525_dd	yes

configuration

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	rs232:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	rs232:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	rs232:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	rs232:keyboard:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	rs232:keyboard:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	rs232:keyboard:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	rs232:keyboard:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
111900	22	no
115200	13	no

dipswitch

Printer Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Printer Baud	DSW	7

location

name	number	inverted
SW	1	no
SW	2	no
SW	3	no

value

name	value	default
9600	0	yes
4800	1	no
2400	2	no
1200	3	no
600	4	no
300	5	no
150	6	no
75	7	no

Model

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Model	DSW	8

location

name	number	inverted
SW	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
TS803	0	yes
TS803H	8	no

Model specific #1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Model specific #1	DSW	16

location

name	number	inverted
SW	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On - TS803 leave here, TS803H Local	0	yes
Off - TS803H remote	16	no

Model specific #2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Model specific #2	DSW	32

location

name	number	inverted
SW	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On - TS803 leave here, TS803H 2-head	0	yes
Off - TS803H 4-head	32	no

Mains frequency

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Mains frequency	DSW	64

location

name	number	inverted
SW	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
60 Hz	0	yes
50 Hz	64	no

Model specific #3

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Model specific #3	DSW	128

location

name	number	inverted
SW	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
On	0	no
Off - TS803H leave here	128	yes

Reverse Video

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Reverse Video	DSW	256

location

name	number	inverted
SW	9	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Reverse	0	no
Normal	256	yes
