Terebi Denwa Thomas the Tank Engine and Friends - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tvdenwat	seibu/banprestoms.cpp		no	no	no	yes	Terebi Denwa Thomas the Tank Engine and Friends	1992	Banpresto

snap

Terebi Denwa Thomas the Tank Engine and Friends png snap

Terebi Denwa Thomas the Tank Engine and Friends jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
tvdenwat	2635	29/12/2025 11:31:48	320	224	96	96	0	Format24bppRgb	305:MAME 0.268.1 (Aug 1 2024)	c68b50eaf6f041711ff00c2e5c07d7e4468dc238

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	224	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
s72_b02.u15	131072	db713202	4883152273925207929757da0eae333ac18aa585	maincpu	0	good	no
s72_b01.u14	131072	fe4e48ff	2a31520ddd3c4a61daf2868114cfd1f1a5f3f201	maincpu	1	good	no
s72_a05.u119	524288	9fda5789	5d1e37d42c9f255253bcb3714be8fd04238b47fa	spr_gfx	0	good	no
s72_a04.u18	524288	66fbbf66	4d46204661282c311ace3c749d9484c2e3e69500	gfx_tiles	0	good	no
s72_a03.u17	1048576	e7d09642	0cee5193497698239f44ef457d92f1d1d042c42b	oki	0	good	no
sc001.u110	260			plds	0	nodump	no
sc002.u235	260			plds	200	nodump	no
sc003.u36	341			plds	400	nodump	no
sc004c.u68	279			plds	600	nodump	no
sc006.u248	279			plds	800	nodump	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	16000000
audio	mono	Speaker
audio	oki	OKI MSM6295 ADPCM	1000000

device_ref

tag	name
:maincpu	m68000
:nvram	nvram
:ticket	ticket_dispenser
:screen	screen
:crtc	seibu_crtc
:rtc	lh5045
:gfxdecode	gfxdecode
:palette	palette
:spritegen	sei0211
:mono	speaker
:oki	okim6295

sound

channels
1

feature

type	status	overall
graphics	imperfect
sound	imperfect

input

players	coins	service	tilt
1	1	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
keypad		12		no

port, analog

port_tag	analog_masks
:DSW1
:IN1
:IN2
:ticket:TEST

dipswitch

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW1	3

location

name	number	inverted
DSW1	1	no
DSW1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Coin/1 Credit	3	yes
2 Coins/1 Credit	2	no
3 Coins/1 Credit	1	no
4 Coins/1 Credit	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	4

location

name	number	inverted
DSW1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	8

location

name	number	inverted
DSW1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	16

location

name	number	inverted
DSW1	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW1	32

location

name	number	inverted
DSW1	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSW1	192

location

name	number	inverted
DSW1	7	no
DSW1	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
Every 3rd cycle	64	no
Every 2nd cycle	128	no
On	192	yes

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	IN2	32

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no
