TX-1 (World) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
tx1	tatsumi/tx1.cpp		no	no	no	yes	TX-1 (World)	1983	Tatsumi (Atari/Namco/Taito license)

display

tag	type	width	height	refresh	pixclock	htotal	hbstart	vtotal	vbstart	flipx
lscreen	raster	256	240	59.185606	6000000	384	256	264	240	no
screen	raster	256	240	59.185606	6000000	384	256	264	240	no
rscreen	raster	256	240	59.185606	6000000	384	256	264	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
imperfect	good	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
8412-136027-244.22	16384	2e9cefa2	4ca04eae446e8df08ab793488a79217ed1a27875	main_cpu	20000	good	no
8412-136027-245.29	16384	ade7895c	1c33a574cae46fddb4cadb85f5de17f02ae7a596	main_cpu	20001	good	no
8412-136027-249.45	16384	9bcb82db	d1528c9b9c4c2848bdba15e4632927476d544f40	main_cpu	28000	good	no
8412-136027-250.54	16384	c8c9368f	0972d54d506216eb2b204cf22ccdff9210fb7b10	main_cpu	28001	good	no
8411-136027-152.146	8192	b65eeea2	b5f26e17520c598132b93c5cd7af7ebd03b10012	math_cpu	4000	good	no
8411-136027-151.132	8192	0d63dadc	0954174b25c08967d3efb31f5721fd05502d66dd	math_cpu	4001	good	no
8411-136027-157.11	8192	10ae3075	69c5f62f2473aba848383eed3cecf15e273d86ca	soundbrd:audio_cpu	0	good	no
8411-136027-156.204	16384	60f3c616	59c4361891e4274e27e6279c919e8fd6803af7cf	char_tiles	0	good	no
8411-136027-155.174	16384	e59a6b72	c10efa77ab421ac60b97227a8d547f50f8415670	char_tiles	4000	good	no
8411-136027-114.203	16384	fc91328b	e57fd2056b65d37cf2e1f0af56616c6555df3006	obj_tiles	0	good	no
8411-136027-116.258	16384	5745f671	6e471633cd6de9926b3361a84430c088e1f6a097	obj_tiles	4000	good	no
8411-136027-115.173	16384	720e5873	151d9063c35b26f5876cf94bdf0c2665ec701bbd	obj_tiles	8000	good	no
8411-136027-117.232	16384	3c68d0bc	2dbaf2a268b90214fd61c016ac945d4371057826	obj_tiles	c000	good	no
8411-136027-146.56	8192	5635b8c1	5cc9437a2ff0843f1917f2451852d4561c240b24	road	0	good	no
8411-136027-147.66	8192	03d83cf8	5c0cfc6bf02ad2b3f37e1ceb493f69eb9829ab1e	road	2000	good	no
8411-136027-148.76	8192	ad56013a	ae3a91f58f30daff334754476db33ad1d12569fc	road	4000	good	no
8411-136027-153.184	16384	acf754e8	06779e18636f0799efdaa09396e9ccd59f426257	au_data	0	good	no
8411-136027-154.185	16384	f89d3e20	4b4cf679b7e3d63cded9989d2b667941f718ff57	au_data	1	good	no
136027-143.ic223	512	22c77af6	1be8585b95316b4fc5712cdaef699e676320cd4d	au_data	8000	good	no
136027-142.ic213	512	f6b8b70b	b79374acf11d71db1e4ad3c494ac5f500a52677b	au_data	8001	good	no
8411-136027-119.106	16384	88eec0fb	81d7a69dc1a4b3b81d7f28d97a3f80697cdcc6eb	obj_map	0	good	no
8411-136027-120.73	16384	407cbe65	e1c11b65f3c6abde6d55afeaffdb39cdd6d66377	obj_map	4000	good	no
8411-136027-113.48	8192	4b3d7956	fc2432dd69f3be7007d4fd6f7c86c7c19453b1ba	obj_luts	0	good	no
8411-136027-118.281	16384	de418dc7	1233e2f7499ec5a73a40ee336d3fe26c06187784	obj_luts	2000	good	no
136027-133.57	256	3b387d01	1229548e3052ad34eeee9598743091d19f6b8f88	proms	0	good	no
136027-134.58	256	f6f4d7d9	866024b76b26d6942bd4e1d2494686299414f6be	proms	100	good	no
136027-135.59	256	824e7532	917ce74d2bae6af90f2c4e41d12a69f884320915	proms	200	good	no
136027-133.36	256	3b387d01	1229548e3052ad34eeee9598743091d19f6b8f88	proms	300	good	no
136027-134.37	256	f6f4d7d9	866024b76b26d6942bd4e1d2494686299414f6be	proms	400	good	no
136027-135.38	256	824e7532	917ce74d2bae6af90f2c4e41d12a69f884320915	proms	500	good	no
136027-133.8	256	3b387d01	1229548e3052ad34eeee9598743091d19f6b8f88	proms	600	good	no
136027-134.9	256	f6f4d7d9	866024b76b26d6942bd4e1d2494686299414f6be	proms	700	good	no
136027-135.10	256	824e7532	917ce74d2bae6af90f2c4e41d12a69f884320915	proms	800	good	no
136027-124.85	256	5aeef5cc	e123bf01d556178b0cf9d495bcce445f3f8421cd	proms	900	good	no
136027-124.116	256	5aeef5cc	e123bf01d556178b0cf9d495bcce445f3f8421cd	proms	a00	good	no
136027-124.148	256	5aeef5cc	e123bf01d556178b0cf9d495bcce445f3f8421cd	proms	b00	good	no
136027-136.276	512	7b675b8b	3a7617d8ca29aa5d9832e317736598646a466b8b	proms	c00	good	no
136027-136.277	512	7b675b8b	3a7617d8ca29aa5d9832e317736598646a466b8b	proms	e00	good	no
136027-123.25	256	616a7a85	b7c1060ecb128154092441212de64dc304aa3fcd	proms	1000	good	no
136027-138.ic33	512	fafb6917	30eb182c7623026dce7dba9e249bc8a9eb7a7f3e	proms	1100	good	no
136027-139.ic40	512	93deb894	5ae9a21298c836fe649a52f3df2b4067f9012b91	proms	1300	good	no
136027-140.ic49	512	aa5ed232	f33e7bc2dd33ac6d75fb06b93c4dd58e5d10010d	proms	1500	good	no
136027-141.ic50	512	6b424cea	83127326c20116b0a4be1126e163f9c6755e19dc	proms	1700	good	no

chip

type	tag	name	clock
cpu	main_cpu	Intel 8086	5000000
cpu	math_cpu	Intel 8086	5000000
cpu	soundbrd:audio_cpu	Zilog Z80	3000000
audio	soundbrd	TX-1 Custom Sound	6000000
audio	soundbrd:frontleft	Speaker
audio	soundbrd:frontright	Speaker
audio	soundbrd:aysnd	AY-3-8910A PSG	750000

device_ref

name
i8086
watchdog
i8086
nvram
palette
screen
screen
screen
tx1_sound
z80
i8255
speaker
speaker
ay8910

sound

channels
2

feature

type	status	overall
sound	imperfect

input

players	coins	service	tilt
1	2	no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
dial		1		no	0	15	20	6
pedal				no	0	31	25	10

port, analog

port_tag	analog_masks
:soundbrd:AN_ACCELERATOR	31
:soundbrd:AN_BRAKE	31
:soundbrd:AN_STEERING	15
:soundbrd:DSW
:soundbrd:PPI_PORTC

dipswitch

Game Cost

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Cost	soundbrd:DSW	12

location

name	number	inverted
DS.2	1	no
DS.2	2	no

value

name	value	default
1 Coin Unit for 1 Credit	0	yes
2 Coin Units for 1 Credit	4	no
3 Coin Units for 1 Credit	8	no
4 Coin Units for 1 Credit	12	no

Left Coin Mechanism

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Left Coin Mechanism	soundbrd:DSW	16

location

name	number	inverted
DS.2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 Coin for 1 Coin Unit	0	yes
1 Coin for 2 Coin Units	16	no

Right Coin Mechanism

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Right Coin Mechanism	soundbrd:DSW	96

location

name	number	inverted
DS.2	4	no
DS.2	5	no

value

name	value	default
1 Coin for 1 Coin Unit	0	yes
1 Coin for 4 Coin Units	32	no
1 Coin for 5 Coin Units	64	no
1 Coin for 6 Coin Units	96	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	soundbrd:DSW	128

location

name	number	inverted
DS.2	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	soundbrd:DSW	1792

location

name	number	inverted
DS.1	1	no
DS.1	2	no
DS.1	3	no

value

name	value	default
A (Easiest)	0	no
B	256	no
C	512	no
D	768	yes
E	1024	no
F	1280	no
G	1536	no
H (Hardest)	1792	no

Game Time

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Game Time	soundbrd:DSW	6144

location

name	number	inverted
DS.1	4	no
DS.1	5	no

value

name	value	default
A (Longest)	0	no
B	2048	no
C	4096	yes
D (Shortest)	6144	no

Bonus Adder

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Adder	soundbrd:DSW	57344

location

name	number	inverted
DS.1	6	no
DS.1	7	no
DS.1	8	no

value

name	value	default
No Bonus	0	no
2 Coin Units for 1 Credit	8192	no
3 Coin Units for 1 Credit	16384	no
4 Coin Units for 1 Credit	24576	no
5 Coin Units for 1 Credit	32768	no
4 Coin Units for 2 Credit	40960	no
Free Play	49152	no
No Bonus	57344	yes

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	soundbrd:PPI_PORTC	4

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no
