Ultimate Mortal Kombat 3 (rev 1.1) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
umk3r11	midway/midwunit.cpp		no	no	no	yes	Ultimate Mortal Kombat 3 (rev 1.1)	1994	Midway	umk3	umk3

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	400	254	54.706840	8000000	506	101	501	289	20	274	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
l2.0_mortal_kombat_3_u2_ultimate.u2	1048576	3838cfe5	e3d2901f3bae1362742fc6ee0aa31c9f63b4dfa3	dcs	0	good	no	l2.0_mortal_kombat_3_u2_ultimate.u2
l1_mortal_kombat_3_u3_music_spch.u3	1048576	856fe411	6165ebecfce7500e948d84492ffa19eed7f47091	dcs	200000	good	no	l1_mortal_kombat_3_u3_music_spch.u3
l1_mortal_kombat_3_u4_music_spch.u4	1048576	428a406f	e70ec83cd054de0da1e178720ed0035b8887f797	dcs	400000	good	no	l1_mortal_kombat_3_u4_music_spch.u4
l1_mortal_kombat_3_u5_music_spch.u5	1048576	3b98a09f	edf1d02a56dcf3349e6b4bb4097acfe7592305f4	dcs	600000	good	no	l1_mortal_kombat_3_u5_music_spch.u5
l1.1_mortal_kombat_3_u54_ultimate.u54	524288	8bb27659	a3ffe3d8f21c261b36c7510d620d691a8bbf665b	maincpu	0	good	no
l1.1_mortal_kombat_3_u63_ultimate.u63	524288	ea731783	2915626090650c4b5adf5b26e736c3ec91ce81a6	maincpu	1	good	no
463_mk3_ultimate.u64	4105	4f425218	7f26045ed2c9ca94fadcb673ce10f28208aa720e	serial_security:pic	0	good	no	463_mk3_ultimate.u64
l1_mortal_kombat_3_u133_game_rom.u133	1048576	79b94667	31bba640c351fdccc6685cadb74dd79a3f910ce8	video	0	good	no	l1_mortal_kombat_3_u133_game_rom.u133
l1_mortal_kombat_3_u132_game_rom.u132	1048576	13e95228	405b05f5a5a55667c2be17d4b399129bdacefd90	video	1	good	no	l1_mortal_kombat_3_u132_game_rom.u132
l1_mortal_kombat_3_u131_game_rom.u131	1048576	41001e30	2cec91116771951c0380cec5debf4cbb40c14c61	video	2	good	no	l1_mortal_kombat_3_u131_game_rom.u131
l1_mortal_kombat_3_u130_game_rom.u130	1048576	49379dd7	e6dfab4e23d9cc38ae56c1bbf10ccd160e8fad5e	video	3	good	no	l1_mortal_kombat_3_u130_game_rom.u130
l1_mortal_kombat_3_u129_game_rom.u129	1048576	a8b41803	9697e35e8bb51d6d36b1d7ae47377b446e57682f	video	400000	good	no	l1_mortal_kombat_3_u129_game_rom.u129
l1_mortal_kombat_3_u128_game_rom.u128	1048576	b410d72f	ac5c1c6f744186540f4ab100d9bd4ce6007e600b	video	400001	good	no	l1_mortal_kombat_3_u128_game_rom.u128
l1_mortal_kombat_3_u127_game_rom.u127	1048576	bd985be7	f5183abea2e5eb2c2c8cefa72c9ed321679f5128	video	400002	good	no	l1_mortal_kombat_3_u127_game_rom.u127
l1_mortal_kombat_3_u126_game_rom.u126	1048576	e7c32cf4	94ea7b2eed7dae66f5dd676c20d6b360140e3e0e	video	400003	good	no	l1_mortal_kombat_3_u126_game_rom.u126
l1_mortal_kombat_3_u125_game_rom.u125	1048576	9a52227e	0474a14fa8dbfea0b0889c1d1756b86391683558	video	800000	good	no	l1_mortal_kombat_3_u125_game_rom.u125
l1_mortal_kombat_3_u124_game_rom.u124	1048576	5c750ebc	45d68af1a56994376e086d840502453c8d6be700	video	800001	good	no	l1_mortal_kombat_3_u124_game_rom.u124
l1_mortal_kombat_3_u123_game_rom.u123	1048576	f0ab88a8	cdc9dc12e162255845c6627b1e35182b7e8502d0	video	800002	good	no	l1_mortal_kombat_3_u123_game_rom.u123
l1_mortal_kombat_3_u122_game_rom.u122	1048576	9b87cdac	a5f8db559293978f23e6f105543d8b2e170a2e0d	video	800003	good	no	l1_mortal_kombat_3_u122_game_rom.u122
mortal_kombat_iii_ultimate_u121_video_image.u121	1048576	cc4b95db	3d53180eec649e9616c4b87db55573f12d9bfee3	video	c00000	good	no	umk-u121.bin
mortal_kombat_iii_ultimate_u120_video_image.u120	1048576	1c8144cd	77cdc1eaf630ccb7233f5532f8b08191d00f0816	video	c00001	good	no	umk-u120.bin
mortal_kombat_iii_ultimate_u119_video_image.u119	1048576	5f10c543	24dc83b7aa531ebd399258ffa7b2e028f1c4a28e	video	c00002	good	no	umk-u119.bin
mortal_kombat_iii_ultimate_u118_video_image.u118	1048576	de0c4488	227cab34798c440b2a45223567113df5f17d913f	video	c00003	good	no	umk-u118.bin
mortal_kombat_iii_ultimate_u113_video_image.u113	1048576	99d74a1e	ed3068afa98287ea290d1f537f5009d3b6d683da	video	1400000	good	no	umk-u113.bin
mortal_kombat_iii_ultimate_u112_video_image.u112	1048576	b5a46488	dbf22e55d200eb9ff550f48b223cf0c6114a9357	video	1400001	good	no	umk-u112.bin
mortal_kombat_iii_ultimate_u111_video_image.u111	1048576	a87523c8	e70b7599fef82001f762fc2c48f7b85474431ccc	video	1400002	good	no	umk-u111.bin
mortal_kombat_iii_ultimate_u110_video_image.u110	1048576	0038f205	059c1c71a2d92ee6db36c09831d213a48a7e81d0	video	1400003	good	no	umk-u110.bin

chip

type	tag	name	clock
cpu	maincpu	Texas Instruments TMS34010	50000000
cpu	dcs:dcs	Analog Devices ADSP-2105	10000000
cpu	serial_security:pic	Microchip PIC16C57	4000000
audio	mono	Speaker
audio	dcs	DCS Audio 8K
audio	dcs:dac	DMA-driven DAC

device_ref

name
wunitvid
tms34010
nvram
palette
screen
speaker
dcs_audio_8k
adsp2105
timer
timer
dmadac
midway_serial_pic_emu
pic16c57

sound

channels
1

input

players	coins	service	tilt
2	4	yes	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	6	8	no
joy	2	6	8	no

port, analog

port_tag	analog_masks
:DSW
:IN0
:IN1
:IN2

dipswitch

Test Switch

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Switch	DSW	1

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Counters

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Counters	DSW	2

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
One	2	no
Two	0	yes

Coinage

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage	DSW	124

value

name	value	default
USA-1	124	yes
USA-2	60	no
USA-3	92	no
USA-4	28	no
USA-ECA	108	no
USA-Free Play	12	no
German-1	116	no
German-2	52	no
German-3	84	no
German-4	20	no
German-5	100	no
German-ECA	36	no
German-Free Play	4	no
French-1	120	no
French-2	56	no
French-3	88	no
French-4	24	no
French-ECA	104	no
French-Free Play	8	no

Coinage Source

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coinage Source	DSW	128

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Dipswitch	128	no
CMOS	0	yes

Powerup Test

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Powerup Test	DSW	512

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	512	no

Bill Validator

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bill Validator	DSW	1024

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1024	yes
On	0	no

Attract Sound

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Attract Sound	DSW	4096

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	4096	yes

Blood

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blood	DSW	16384

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	16384	yes

Violence

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Violence	DSW	32768

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	32768	yes
