DSP563xx unit tests - mame (0287) machine

machine

• XML • JSON • RUN

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
utdsp563xx	virtual/utdsp563xx.cpp		no	no	no	yes	DSP563xx unit tests	2025	MAME

snap

DSP563xx unit tests png snap

DSP563xx unit tests jpg snap thumbnail

Key	Length	LastWriteTime	Width	Height	HorizontalResolution	VerticalResolution	PaletteLength	PixelFormat	PropertyItems	PixelSHA1
utdsp563xx	36279	13/01/2026 10:03:48	1920	1080	96	96	0	Format24bppRgb	305:MAME 0.284 (mame0284)	6906cfd2a4a7aa04aaac440baca42507575d755d

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	1920	1080	60.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
spleen_16_32_256.bin	16384	d95ea771	4aacc4e088165bc4a83bfca3bbb94507efb5d617	font	0	good	no

chip

type	tag	name	clock
cpu	cpu	Motorola DSP56311	66000000
audio	speaker	Speaker

device_ref

tag	name
:cpu	dsp56311
:cpu:hi08	hi08
:screen	screen
:speaker	speaker

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3
joy		2	8	no

port, analog

port_tag	analog_masks
:CONTROL
