Cyber Troopers Virtual-On: Oratorio Tangram - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
von2o	sega/model3.cpp		no	no	no	yes	Cyber Troopers Virtual-On: Oratorio Tangram	1998	Sega	von2	von2

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	496	384	57.524160	16000000	656	0	496	424	0	384	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge
epr-20683.17	2097152	bb21aea7	8d75a79411f37c921b923329fa499fb96c3084b2	user1	6	good	no
epr-20684.18	2097152	5d40fedb	cae9215d27e6432ddc1c13221ce7947d821a59d0	user1	4	good	no
epr-20685.19	2097152	0664c568	0cdf445be783e939f4e8c32837e0c44d279e7a91	user1	2	good	no
epr-20686.20	2097152	e1b0ff65	8dab5c88ef213cc13e42a9b3762443ea467a65f9	user1	0	good	no
mpr-20647.1	4194304	e8586380	67dd49975b31ba2c3f889ff38a3bc4663145934a	user1	800006	good	no	mpr-20647.1
mpr-20648.2	4194304	107309e0	61657814a30020c0d4ea77625cb8f11a1db7e866	user1	800004	good	no	mpr-20648.2
mpr-20649.3	4194304	b8fd56ba	5e5051d4b752463e1da632f8294a6c8f9250dbc8	user1	800002	good	no	mpr-20649.3
mpr-20650.4	4194304	81f96649	0d7aba7654237b68de6e43811832fafaf61e2bec	user1	800000	good	no	mpr-20650.4
mpr-20651.5	4194304	8373cab3	1d36612668a3004e2448f99ab27d7184ff859478	user1	1800006	good	no	mpr-20651.5
mpr-20652.6	4194304	64c6fbb6	c8682bda20d3119b4f95bbd2dbde301bfd036608	user1	1800004	good	no	mpr-20652.6
mpr-20653.7	4194304	858e6bba	22b71826799249a577124a49d5a276908a53ce61	user1	1800002	good	no	mpr-20653.7
mpr-20654.8	4194304	763ef905	4d5f6b1770cf9bf6cecd4d3a91a822e5cc658464	user1	1800000	good	no	mpr-20654.8
mpr-20655.9	4194304	f0a471e9	8a40c9381e8b3733be297738c825b82abcb476d0	user1	2800006	good	no	mpr-20655.9
mpr-20656.10	4194304	466bee13	bc2087a138037188f462fa1cecc898e5efb3e8b8	user1	2800004	good	no	mpr-20656.10
mpr-20657.11	4194304	14bf8964	84444f7c489344ad1dd980b860364b5a4ed53038	user1	2800002	good	no	mpr-20657.11
mpr-20658.12	4194304	b80175b9	26dc97f6a6e8415cbb7e9e1f64389d80a2b761a1	user1	2800000	good	no	mpr-20658.12
mpr-20659.13	4194304	edb63e7b	761abcfc213e813967d053475c965459a9724a24	user1	3800006	good	no	mpr-20659.13
mpr-20660.14	4194304	d961d385	7e341c2cf24715c5cecb276c42166bf426860819	user1	3800004	good	no	mpr-20660.14
mpr-20661.15	4194304	50e6189e	04be5ff1379af4972edec3b320f148bdf09bfbb5	user1	3800002	good	no	mpr-20661.15
mpr-20662.16	4194304	7130cb61	39de0e3c2086f339156bfd734a196b667df7f5ac	user1	3800000	good	no	mpr-20662.16
mpr-20667.26	4194304	321e006f	687165bd2d2d22f861cd79083adcab62eb827c0f	user3	2	good	no	mpr-20667.26
mpr-20668.27	4194304	c2dd8053	52bc88d172d335b47e3ae3d582233382e9608de2	user3	0	good	no	mpr-20668.27
mpr-20669.28	4194304	63432497	b072741fe9ba49f1a7eed03301c8b1956af94d26	user3	6	good	no	mpr-20669.28
mpr-20670.29	4194304	f7b554fd	84fb08413345e0f3afb6e20c723aa8aa8156fdc7	user3	4	good	no	mpr-20670.29
mpr-20671.30	4194304	fee1a49b	a024a0564df65e065e8b1830e85513d17ebd8635	user3	a	good	no	mpr-20671.30
mpr-20672.31	4194304	e4b8c6e6	674d4d26285f2825050fd27dd3382ca6245d54c7	user3	8	good	no	mpr-20672.31
mpr-20673.32	4194304	e7b6403b	0f74f7a916c091d49eed8222050981a6b73d4bdd	user3	e	good	no	mpr-20673.32
mpr-20674.33	4194304	9be22e13	a00b0c69b6ed086f3f61d4f767df6c4ddea45052	user3	c	good	no	mpr-20674.33
mpr-20675.34	4194304	6a7c3862	f77145c2a5e373f567783cf5db70e25b71e77bf5	user4	2	good	no	mpr-20675.34
mpr-20676.35	4194304	dd299648	c222c10cb23753ac3d6d1c779b2d026a64c61bc4	user4	0	good	no	mpr-20676.35
mpr-20677.36	4194304	3fc5f330	778c1932b093a4de96c76ea704463b7c67cdcb33	user4	6	good	no	mpr-20677.36
mpr-20678.37	4194304	62f794a1	fc7adafb49056b23b6cc483978ffe4fd3635977d	user4	4	good	no	mpr-20678.37
mpr-20679.38	4194304	35a37c53	cd727a8914c3c01e302378048e3998b4cd849c4a	user4	a	good	no	mpr-20679.38
mpr-20680.39	4194304	81fec46e	43b3fbb544d920a87f77437860e32a628ae2865b	user4	8	good	no	mpr-20680.39
mpr-20681.40	4194304	d517873b	8e50dd149716ae6b0b8d7ac99cd425a17b3c0a46	user4	e	good	no	mpr-20681.40
mpr-20682.41	4194304	5b43250c	fccb40cd03c096360ca3c565e8621d4110b273ab	user4	c	good	no	mpr-20682.41
epr-20687.21	524288	fa084de5	8a760b76bc12d60d4727f93106830f19179c9046	audiocpu	0	good	no	epr-20687.21
mpr-20663.22	4194304	977eb6a4	9dbba51630cbef2351d79b82ab6ae3af4aed99f0	samples	0	good	no	mpr-20663.22
mpr-20665.24	4194304	0efc0ca8	1414becad21eb7d03d816a8cba47506f941b3c29	samples	400000	good	no	mpr-20665.24
mpr-20664.23	4194304	89220782	18a3585af960a76eb08f187223e9b69ad16809a1	samples	800000	good	no	mpr-20664.23
mpr-20666.25	4194304	3ecb2606	a38d1f61933c8873deaff0a913c657b768f9783d	samples	c00000	good	no	mpr-20666.25

chip

type	tag	name	clock
cpu	maincpu	IBM PowerPC 603R	166000000
cpu	audiocpu	Motorola MC68000	11289600
cpu	billboard:billcpu	Zilog Z80	8000000
cpu	comm_board:m3commcpu	Motorola MC68000	10000000
audio	speaker	Speaker
audio	scsp1	Yamaha YMF292-F SCSP	22579200
audio	scsp2	Yamaha YMF292-F SCSP	22579200

device_ref

name
ppc603r
m68000
93c46_16
nvram
rtc72421
315_5649
screen
palette
gfxdecode
speaker
scsp
scsp
segabill
z80
315_5338a
m3comm
m68000
ram
sega315_5881

sound

channels
1

feature

type	status	overall
graphics	imperfect
sound	imperfect

input

players	coins	service	tilt
1	2	yes	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
doublejoy		4	8	no					8

port, analog

port_tag	analog_masks
:AN0
:AN1
:AN2
:AN3
:AN4
:AN5
:AN6
:AN7
:DSW
:IN0
:IN1
:IN2
:IN3
:billboard:dsw

dipswitch

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	1

location

name	number	inverted
SW	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	2

location

name	number	inverted
SW	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	4

location

name	number	inverted
SW	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	8

location

name	number	inverted
SW	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	16

location

name	number	inverted
SW	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	32

location

name	number	inverted
SW	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	64

location

name	number	inverted
SW	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	64	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	DSW	128

location

name	number	inverted
SW	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	128	yes
On	0	no

Test Winner LED P1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Winner LED P1	billboard:dsw	1

location

name	number	inverted
DSW	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	1	yes
On	0	no

Test Winner LED P2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test Winner LED P2	billboard:dsw	2

location

name	number	inverted
DSW	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	2	yes
On	0	no

Test 7-Segment P1

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test 7-Segment P1	billboard:dsw	4

location

name	number	inverted
DSW	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	4	yes
On	0	no

Test 7-Segment P2

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Test 7-Segment P2	billboard:dsw	8

location

name	number	inverted
DSW	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	billboard:dsw	16

location

name	number	inverted
DSW	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	billboard:dsw	32

location

name	number	inverted
DSW	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Demo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo	billboard:dsw	64

location

name	number	inverted
DSW	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Testmode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Testmode	billboard:dsw	128

location

name	number	inverted
DSW	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no
