VT100 - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
vt100	dec/vt100.cpp		no	no	no	yes	VT100	1978	Digital Equipment Corporation

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	800	250	60.054382	16048933	1020	0	800	262	0	250	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	unsupported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
23-031e2-00.e56	2048			maincpu	0	nodump	no		vt100o
23-061e2-00.e56	2048	3dae97ff	e3437850c33565751b86af6c2fe270a491246d15	maincpu	0	good	no		vt100
23-032e2-00.e52	2048	3d86db99	cdd8bdecdc643442f6e7d2c83cf002baf8101867	maincpu	800	good	no
23-033e2-00.e45	2048	384dac0a	22aaf5ab5f9555a61ec43f91d4dea3029f613e64	maincpu	1000	good	no
23-034e2-00.e40	2048	4643184d	27e6c19d9932bf13fdb70305ef4d806e90d60833	maincpu	1800	good	no
23-018e2-00.e4	2048	6958458b	103429674fc01c215bbc2c91962ae99231f8ae53	chargen	0	good	no
23-094e2-00.e9	2048			chargen	800	nodump	yes

chip

type	tag	name	clock
cpu	maincpu	Intel 8080	2764800
audio	keyboard:mono	Speaker
audio	keyboard:beeper	Beep	786

device_ref

name
i8080
screen
gfxdecode
vt100_video
palette
i8251
rs232
com5016_013
er1400
vt100_kbd
speaker
beep
ay31015
ripple_counter
ay31015
rst_pos_buffer

biosset

name	description	default
vt100o	VT100 older ROMs	no
vt100	VT100 newer ROMs	yes

sound

channels
1

feature

type	status	overall
graphics	imperfect

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		83		no

port, analog

port_tag	analog_masks
:keyboard:LINE0
:keyboard:LINE1
:keyboard:LINE2
:keyboard:LINE3
:keyboard:LINE4
:keyboard:LINE5
:keyboard:LINE6
:keyboard:LINE7
:keyboard:LINE8
:keyboard:LINE9
:keyboard:LINEA
:keyboard:LINEB
:keyboard:LINEC
:keyboard:LINED
:keyboard:LINEE
:keyboard:LINEF
:phosphor

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
rs232	terminal	serial_terminal	no
rs232	sunkbd	sunkbd_adaptor	no
rs232	dec_loopback	dec_rs232_loopback	no
rs232	ie15	ie15_terminal	no
rs232	null_modem	null_modem	no
rs232	keyboard	serial_keyboard	no
rs232	patch	rs232_patch_box	no
rs232	swtpc8212	swtpc8212_terminal	no
rs232	printer	serial_printer	no
rs232	scorpion	scorpion_ic	no
rs232	loopback	rs232_loopback	no
rs232	mockingboard	mockingboardd	no
rs232	msystems_mouse	rs232_mouse_hle_msystems	no
rs232	nss_tvi	nss_tvinterface	no
rs232	rs232_sync_io	rs232_sync_io	no
rs232	pty	pseudo_terminal	no
rs232	votraxtnt	serial_votraxtnt	no
rs232	rs_printer	rs_serial_printer	no

configuration

Phosphor Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Phosphor Color	phosphor	3

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Green	0	yes
Amber	1	no
White	2	no
