Wardner (World) - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
wardner	toaplan/wardner.cpp		no	no	no	yes	Wardner (World)	1987	Toaplan / Taito Corporation Japan

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	320	240	54.877858	7000000	446	0	320	286	0	240	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional
b25-31.6m	32768	c5dd56fd	f0a09557150e9c1c6b9d8e125f5408fc269c9d17	maincpu	0	good	no
b25-18.7m	65536	9aab8ee2	16fa44b75f4a3a5b1ff713690a299ecec2b5a4bf	maincpu	10000	good	no
b25-19.8m	65536	95b68813	06ea1b1d6e2e6326ceb9324fc471d082fda6112e	maincpu	20000	good	no
b25-32.10m	32768	347f411b	1fb2883d74d10350cb1c62fb58d5783652861b37	maincpu	38000	good	no
b25-16.4k	32768	e5202ff8	15ae8c0bb16a20bee14e8d80d81c249404ab1463	audiocpu	0	good	no
d70012u_gxc-02_mcu_71001	3072	eee0ff59	dad4570815ec444e34cc73f7cd90f9ca8f7b3eb8	dsp	0	baddump	no
b25-28.10f	16384	1392b60d	86b9eab87f8d5f68fda500420f4ed61331089fc2	chars	0	good	no
b25-27.8f	16384	0ed848da	e4b38e21c101a28a8961a9fe30c9cb10919cc148	chars	4000	good	no
b25-26.7f	16384	79792c86	648b97f1ec30d46e40e60eb13159b4f6f86e9243	chars	8000	good	no
b25-12.18f	32768	15d08848	e2e62d95a3f240664b5e0ac0f163a0d5cefa5312	fg_tiles	0	good	no
b25-15.23f	32768	cdd2d408	7e4d77f8725fa30d4d65e811d10e0b2c00b23cfe	fg_tiles	8000	good	no
b25-14.21f	32768	5a2aef4f	60f4ab2582a924defb5241ab367826ae1f4b3f5e	fg_tiles	10000	good	no
b25-13.19f	32768	be21db2b	7fc1809618f2432c9ec6eb33ce57a5faffd44974	fg_tiles	18000	good	no
b25-08.12f	32768	883ccaa3	90d686094eac6e80caf8e2cf90c00bb41a0d26e2	bg_tiles	0	good	no
b25-11.16f	32768	d6ebd510	d65e0db7756ebe6828bf637a6c915bb06082636c	bg_tiles	8000	good	no
b25-10.15f	32768	b9a61e81	541e579664d583fbbf81111046115018fdaff073	bg_tiles	10000	good	no
b25-09.14f	32768	585411b7	67c0f4b7ab303341d5481c4024dc4199acb7c279	bg_tiles	18000	good	no
b25-01.14c	65536	42ec01fb	646192a2e89f795ed016860cdcdc0b5ef645fca2	scu	0	good	no
b25-02.16c	65536	6c0130b7	8b6ad72848d03c3d4ee3acd35abbb3a0e678122c	scu	10000	good	no
b25-03.17c	65536	b923db99	2f4be81afdf200586bc44b1e94553d84d16d0b62	scu	20000	good	no
b25-04.19c	65536	8059573c	75bd19e504433438b85ed00e50e85fb98eebf4de	scu	30000	good	no
82s129.b19	256	24e7d62f	1c06a1ef1b6a722794ca1d5ee2c476ecaa5178a3	proms	0	good	no
82s129.b18	256	a50cef09	55cafb5b2551b80ae708e9b966cf37c70a16d310	proms	100	good	no
82s123.b21	32	f72482db	b0cb911f9c81f6088a5aa8760916ddae1f8534d7	proms	200	good	no
82s123.c6	32	bc88cced	5055362710c0f58823c05fb4c0e0eec638b91e3d	proms	220	good	no
82s123.f1	32	4fb5df2a	506ef2c8e4cf45c256d6831a0a5760732f2de422	proms	240	good	no

chip

type	tag	name	clock
cpu	maincpu	Zilog Z80	6000000
cpu	audiocpu	Zilog Z80	3500000
cpu	dsp	Texas Instruments TMS32010	14000000
audio	mono	Speaker
audio	ymsnd	YM3812 OPL2	3500000

device_ref

name
z80
z80
tms32010
ls259
ls259
hd6845s
toaplan_scu
buffered_spriteram8
screen
gfxdecode
palette
speaker
ym3812

sound

channels
1

input

players	coins	service	tilt
2	2	no	yes

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
joy	1	2	8	no
joy	2	2	8	no

port, analog

port_tag	analog_masks
:DSWA
:DSWB
:P1
:P2
:SYSTEM

dipswitch

Cabinet

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cabinet	DSWA	1

location

name	number	inverted
SW1	1	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Upright	1	yes
Cocktail	0	no

Flip Screen

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Flip Screen	DSWA	2

location

name	number	inverted
SW1	2	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	2	no

Service Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Service Mode	DSWA	4

location

name	number	inverted
SW1	3	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	4	no

Demo Sounds

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Demo Sounds	DSWA	8

location

name	number	inverted
SW1	4	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	8	no
On	0	yes

Coin A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin A	DSWA	48

location

name	number	inverted
SW1	5	yes
SW1	6	yes

value

name	value	default
4 Coins/1 Credit	48	no
3 Coins/1 Credit	32	no
2 Coins/1 Credit	16	no
1 Coin/1 Credit	0	yes

Coin B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Coin B	DSWA	192

location

name	number	inverted
SW1	7	yes
SW1	8	yes

value

name	value	default
1 Coin/2 Credits	0	yes
1 Coin/3 Credits	64	no
1 Coin/4 Credits	128	no
1 Coin/6 Credits	192	no

Difficulty

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Difficulty	DSWB	3

location

name	number	inverted
SW2	1	yes
SW2	2	yes

value

name	value	default
Easy	1	no
Normal	0	yes
Hard	2	no
Very Hard	3	no

Bonus Life

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Bonus Life	DSWB	12

location

name	number	inverted
SW2	3	yes
SW2	4	yes

value

name	value	default
30k 80k 50k+	0	yes
50k 100k 50k+	4	no
30k Only	8	no
50k Only	12	no

Lives

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Lives	DSWB	48

location

name	number	inverted
SW2	5	yes
SW2	6	yes

value

name	value	default
1	48	no
3	0	yes
4	16	no
5	32	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWB	64

location

name	number	inverted
SW2	7	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	64	no

Unused

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unused	DSWB	128

location

name	number	inverted
SW2	8	yes

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	yes
On	128	no
