WY-100 - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
wy100	wyse/wy100.cpp		no	no	no	yes	WY-100	1981	Wyse Technology

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	800	286	60.000000	18480000	1000	0	800	308	0	286	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
good	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
wy100_00401f.bin	4096	1f71de8f	2bd9f712aba8b44823ce0b3e111da7b472a1ab38	maincpu	0	good	no
wy100_23-002-01c.bin	2048	93c31537	085e5ad110a76bee83e819a718a7d4cbfb8e07e7	chargen	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Intel 8039	10137600
audio	mono	Speaker
audio	speaker	Filtered DAC

device_ref

name
i8039
wy100kb
address_map_bank
scn2651
screen
i8276
i8276
speaker
speaker_sound_device
ipt_merge_all_hi
rs232
rs232_loopback
rs232
wy100_loopback

sound

channels
1

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		104		no

port, analog

port_tag	analog_masks
:keyboard:COL0
:keyboard:COL1
:keyboard:COL10
:keyboard:COL11
:keyboard:COL12
:keyboard:COL13
:keyboard:COL14
:keyboard:COL15
:keyboard:COL2
:keyboard:COL3
:keyboard:COL4
:keyboard:COL5
:keyboard:COL6
:keyboard:COL7
:keyboard:COL8
:keyboard:COL9

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
modem	terminal	serial_terminal	no
modem	sunkbd	sunkbd_adaptor	no
modem	dec_loopback	dec_rs232_loopback	no
modem	ie15	ie15_terminal	no
modem	null_modem	null_modem	no
modem	keyboard	serial_keyboard	no
modem	patch	rs232_patch_box	no
modem	swtpc8212	swtpc8212_terminal	no
modem	printer	serial_printer	no
modem	scorpion	scorpion_ic	no
modem	loopback	rs232_loopback	yes
modem	mockingboard	mockingboardd	no
modem	msystems_mouse	rs232_mouse_hle_msystems	no
modem	nss_tvi	nss_tvinterface	no
modem	rs232_sync_io	rs232_sync_io	no
modem	pty	pseudo_terminal	no
modem	votraxtnt	serial_votraxtnt	no
modem	rs_printer	rs_serial_printer	no
aux	terminal	serial_terminal	no
aux	sunkbd	sunkbd_adaptor	no
aux	ie15	ie15_terminal	no
aux	null_modem	null_modem	no
aux	keyboard	serial_keyboard	no
aux	patch	rs232_patch_box	no
aux	swtpc8212	swtpc8212_terminal	no
aux	printer	serial_printer	no
aux	scorpion	scorpion_ic	no
aux	loopback	wy100_loopback	yes
aux	mockingboard	mockingboardd	no
aux	msystems_mouse	rs232_mouse_hle_msystems	no
aux	nss_tvi	nss_tvinterface	no
aux	rs232_sync_io	rs232_sync_io	no
aux	pty	pseudo_terminal	no
aux	votraxtnt	serial_votraxtnt	no
aux	rs_printer	rs_serial_printer	no

dipswitch

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	keyboard:COL10	3

location

name	number	inverted
DS2	2	no
DS2	4	no

value

name	value	default
Odd	1	no
Even	0	no
Space	3	yes
Mark	2	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	keyboard:COL10	4

location

name	number	inverted
DS2	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1	4	yes
2	0	no

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	keyboard:COL10	8

location

name	number	inverted
DS2	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
7	8	no
8	0	yes

Communications Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Communications Baud Rate	keyboard:COL10	240

location

name	number	inverted
DS2	5	no
DS2	6	no
DS2	7	no
DS2	8	no

value

name	value	default
50	0	no
75	128	no
110	64	no
134.5	192	no
150	32	no
300	160	no
600	96	no
1200	224	no
1800	16	no
2000	144	no
2400	80	no
3600	208	no
4800	48	no
7200	176	no
9600	112	yes

EOL & EOT Sequences

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
EOL & EOT Sequences	keyboard:COL11	1

location

name	number	inverted
DS1	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
US, CR	1	yes
CR/LF/NULL, ETX	0	no

Enter & Return Keys

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Enter & Return Keys	keyboard:COL11	2

location

name	number	inverted
DS1	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
TAB, CR/LF	2	yes
CR Only	0	no

Auto New Line

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto New Line	keyboard:COL11	4

location

name	number	inverted
DS1	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	0	no
On	4	yes

Editing Keys

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Editing Keys	keyboard:COL11	8

location

name	number	inverted
DS1	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Local	8	yes
Duplex	0	no

Printer Baud Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Printer Baud Rate	keyboard:COL11	240

location

name	number	inverted
DS1	5	no
DS1	6	no
DS1	7	no
DS1	8	no

value

name	value	default
Diagnostic Self-Test	240	no
50	0	no
75	128	no
110	64	no
134.5	192	no
150	32	no
300	160	no
600	96	no
1200	224	no
1800	16	no
2000	144	no
2400	80	no
3600	208	no
4800	48	no
7200	176	no
9600	112	yes

Refresh Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Refresh Rate	keyboard:COL9	1

location

name	number	inverted
DS3	2	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
50 Hz	0	no
60 Hz	1	yes

Screen Background

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Screen Background	keyboard:COL9	2

location

name	number	inverted
DS3	5	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Black	2	yes
Green	0	no

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	keyboard:COL9	4

location

name	number	inverted
DS3	6	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Non-blinking	0	no
Blinking	4	yes

Memory Pages

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Memory Pages	keyboard:COL9	8

location

name	number	inverted
DS3	1	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
1 (1920 characters)	8	no
2 (3840 characters)	0	yes

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	keyboard:COL9	16

location

name	number	inverted
DS3	3	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	16	yes
On	0	no

Unknown

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Unknown	keyboard:COL9	32

location

name	number	inverted
DS3	4	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Off	32	yes
On	0	no

Duplex

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Duplex	keyboard:COL9	64

location

name	number	inverted
DS3	7	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Full Duplex	64	yes
Half Duplex	0	no

Conversation Mode

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Conversation Mode	keyboard:COL9	128

location

name	number	inverted
DS3	8	no

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Conversation Mode	128	yes
Block Mode	0	no
