XDS-19P - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
xds19p	visual/xds.cpp		no	no	no	yes	XDS-19P	1990	Visual Technology

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
screen	raster	0	1152	904	72.194243	100000000	1472	0	1152	941	0	904	no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	good	supported	no	no	no	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
boot_30.e6	131072	32449da2	e1bc41987fb9c7da5b7fed5d6714c3451be4438c	maincpu	0	good	no
boot_30.e15	131072	a577087f	2fe9d4d49fd6e8ecd230f8097f7004238afbb626	maincpu	1	good	no
1837.e06d	256	b5d9f883	28303155c515ac2638a06123fbf7e55f89dd2af9	prom	0	good	no
x15-3.1l	1045320	5de8fdf1	4203ffbba775a8c4a1b827621d116ba00839f91a	tftp	0	good	no

chip

type	tag	name	clock
cpu	maincpu	Motorola MC68000	16667000

device_ref

name
m68000
nvram
screen
mc6845
am7990
mc68681
duart_channel
duart_channel
rs232
rs232_mouse_hle_msystems
rs232
acia6850
clock
xds_kbd_hle

sound

channels
0

feature

type	status	overall
sound	unemulated

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
mouse		3		no	0	61440	100
keyboard		111		no

port, analog

port_tag	analog_masks
:kbd:row_0
:kbd:row_1
:kbd:row_2
:kbd:row_3
:kbd:row_4
:kbd:row_5
:kbd:row_6
:kbd:row_7
:mouseport:msystems_mouse:BTN
:mouseport:msystems_mouse:X	4095
:mouseport:msystems_mouse:Y	4095
:sw1

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
mouseport	msystems_mouse	rs232_mouse_hle_msystems	yes
serialport	terminal	serial_terminal	no
serialport	sunkbd	sunkbd_adaptor	no
serialport	dec_loopback	dec_rs232_loopback	no
serialport	ie15	ie15_terminal	no
serialport	null_modem	null_modem	no
serialport	keyboard	serial_keyboard	no
serialport	patch	rs232_patch_box	no
serialport	swtpc8212	swtpc8212_terminal	no
serialport	printer	serial_printer	no
serialport	scorpion	scorpion_ic	no
serialport	loopback	rs232_loopback	no
serialport	mockingboard	mockingboardd	no
serialport	msystems_mouse	rs232_mouse_hle_msystems	no
serialport	nss_tvi	nss_tvinterface	no
serialport	rs232_sync_io	rs232_sync_io	no
serialport	pty	pseudo_terminal	no
serialport	votraxtnt	serial_votraxtnt	no
serialport	rs_printer	rs_serial_printer	no

dipswitch

Video Mode?

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Video Mode?	sw1	15

value

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
0	0	no
1 - 1152x904 @72	1	no
2 - 1024x864 @72	2	no
3	3	no
4	4	no
5 - 1152x904 @72	5	yes
6 - 1152x904 @66	6	no
7 - 1024x800 @88	7	no
8	8	no
9	9	no
a	10	no
b	11	no
c	12	no
d	13	no
e	14	no
f	15	no
