XOR S-100-12 - mame (0280) machine

MAME: 0280 - Released: 2025-08-29T22:26:57 - Machines: 48893 - rom: 364836 - disk: 1378

machine

• XML • JSON • AO

name	sourcefile	sampleof	isbios	isdevice	ismechanical	runnable	description	year	manufacturer	cloneof	romof
xor100	skeleton/xor100.cpp		no	no	no	yes	XOR S-100-12	1980	XOR Data Science

display

tag	type	rotate	width	height	refresh	pixclock	htotal	hbend	hbstart	vtotal	vbend	vbstart	flipx
rs232b:terminal:terminal_screen	raster	0	640	240	50.000000								no

driver

status	emulation	savestate	requiresartwork	unofficial	nosoundhardware	incomplete	cocktail
preliminary	preliminary	supported	no	no	yes	no

rom

name	size	crc	sha1	region	offset	status	optional	merge	bios
xp 185.8b	2048	0d0bda8d	11c83f7cd7e6a570641b44a2f2cc5737a7dd8ae3	5b	0	good	no		v185

chip

type	tag	name	clock
cpu	5b	Zilog Z80	4000000
audio	rs232b:terminal:bell	Speaker
audio	rs232b:terminal:beeper	Beep	2000
audio	wd1795:0:8ssdd:flopsndout	Speaker
audio	wd1795:0:8ssdd:floppysound	Floppy sound	44100
audio	wd1795:1:8ssdd:flopsndout	Speaker
audio	wd1795:1:8ssdd:floppysound	Floppy sound	44100

device_ref

name
z80
i8251
rs232
i8251
rs232
serial_terminal
screen
generic_keyboard
speaker
beep
com8116
i8255
z80ctc
z80ctc_channel
z80ctc_channel
z80ctc_channel
z80ctc_channel
fd1795
floppy_connector
floppy_8_ssdd
speaker
flopsnd
floppy_connector
floppy_8_ssdd
speaker
flopsnd
floppy_connector
floppy_connector
centronics
centronics_printer
printer_image
output_latch
s100_bus
s100_slot
s100_slot
s100_slot
s100_slot
s100_slot
s100_slot
s100_slot
s100_slot
s100_slot
s100_slot
ram

biosset

name	description	default
v185	v1.85	no

sound

channels
3

ramoption

name	default
128K
192K
256K
320K
384K
448K
512K
64K	yes

device, instance

type	tag	interface	name	briefname
floppydisk	wd1795:0:8ssdd	floppy_8	floppydisk1	flop1
floppydisk	wd1795:1:8ssdd	floppy_8	floppydisk2	flop2
printout	centronics:printer:printer		printout	prin

device, extension

type	tag	interface	extension_names
floppydisk	wd1795:0:8ssdd	floppy_8	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
floppydisk	wd1795:1:8ssdd	floppy_8	mfi, dfi, mfm, td0, imd, 86f, d77, d88, 1dd, cqm, cqi, dsk
printout	centronics:printer:printer		prn

input

players	coins	service	tilt
1		no	no

control

type	player	buttons	ways	reverse	minimum	maximum	sensitivity	keydelta	ways2	ways3	reqbuttons
keyboard		73		no

port, analog

port_tag	analog_masks
:DSW0
:J1
:J2
:J3
:J4-J5
:J6
:J7
:J8
:J9
:rs232b:terminal:RS232_DATABITS
:rs232b:terminal:RS232_PARITY
:rs232b:terminal:RS232_RXBAUD
:rs232b:terminal:RS232_STOPBITS
:rs232b:terminal:RS232_TXBAUD
:rs232b:terminal:TERM_CONF
:rs232b:terminal:keyboard:GENKBD_CFG
:rs232b:terminal:keyboard:GENKBD_MOD
:rs232b:terminal:keyboard:GENKBD_ROW0
:rs232b:terminal:keyboard:GENKBD_ROW1
:rs232b:terminal:keyboard:GENKBD_ROW2
:rs232b:terminal:keyboard:GENKBD_ROW3

slot, slotoption

slot_name	slotoption_name	slotoption_devname	slotoption_default
rs232a	terminal	serial_terminal	no
rs232a	sunkbd	sunkbd_adaptor	no
rs232a	dec_loopback	dec_rs232_loopback	no
rs232a	ie15	ie15_terminal	no
rs232a	null_modem	null_modem	no
rs232a	keyboard	serial_keyboard	no
rs232a	patch	rs232_patch_box	no
rs232a	swtpc8212	swtpc8212_terminal	no
rs232a	printer	serial_printer	no
rs232a	scorpion	scorpion_ic	no
rs232a	loopback	rs232_loopback	no
rs232a	mockingboard	mockingboardd	no
rs232a	msystems_mouse	rs232_mouse_hle_msystems	no
rs232a	nss_tvi	nss_tvinterface	no
rs232a	rs232_sync_io	rs232_sync_io	no
rs232a	pty	pseudo_terminal	no
rs232a	votraxtnt	serial_votraxtnt	no
rs232a	rs_printer	rs_serial_printer	no
rs232b	terminal	serial_terminal	yes
rs232b	sunkbd	sunkbd_adaptor	no
rs232b	dec_loopback	dec_rs232_loopback	no
rs232b	ie15	ie15_terminal	no
rs232b	null_modem	null_modem	no
rs232b	keyboard	serial_keyboard	no
rs232b	patch	rs232_patch_box	no
rs232b	swtpc8212	swtpc8212_terminal	no
rs232b	printer	serial_printer	no
rs232b	scorpion	scorpion_ic	no
rs232b	loopback	rs232_loopback	no
rs232b	mockingboard	mockingboardd	no
rs232b	msystems_mouse	rs232_mouse_hle_msystems	no
rs232b	nss_tvi	nss_tvinterface	no
rs232b	rs232_sync_io	rs232_sync_io	no
rs232b	pty	pseudo_terminal	no
rs232b	votraxtnt	serial_votraxtnt	no
rs232b	rs_printer	rs_serial_printer	no
wd1795:0	8ssdd	floppy_8_ssdd	yes
wd1795:1	8ssdd	floppy_8_ssdd	yes
wd1795:2	8ssdd	floppy_8_ssdd	no
wd1795:3	8ssdd	floppy_8_ssdd	no
centronics	nlq401	nlq401	no
centronics	smartboard	centronics_smartboard	no
centronics	chessmec	centronics_chessmec	no
centronics	samdac	centronics_samdac	no
centronics	covox_stereo	covox_stereo	no
centronics	adaptator	adaptator_multitap	no
centronics	digiblst	cpcdigiblst	no
centronics	lx800	lx800	no
centronics	jx80	epson_jx80	no
centronics	ap2000	ap2000	no
centronics	ex800	ex800	no
centronics	fx80	epson_fx80	no
centronics	rx80	epson_rx80	no
centronics	mz1p16	mz1p16	no
centronics	covox	covox	no
centronics	pl80	comx_pl80	no
centronics	lx810l	lx810l	no
centronics	p72	p72	no
centronics	printer	centronics_printer	yes
s100:1
s100:2
s100:3
s100:4
s100:5
s100:6
s100:7
s100:8
s100:9
s100:10

configuration

J1 Wait State

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
J1 Wait State	J1	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No Wait States	0	no
1 M1 Wait State	1	yes

J2 CPU Speed

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
J2 CPU Speed	J2	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2 MHz	0	no
4 MHz	1	yes

J3

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
J3	J3	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
	0	yes
	1	no

J4/J5 EPROM Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
J4/J5 EPROM Type	J4-J5	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
2708	0	no
2716	1	yes

J6 EPROM

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
J6 EPROM	J6	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Disabled	0	no
Enabled	1	yes

J7 I/O Port Addresses

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
J7 I/O Port Addresses	J7	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
00-0F	0	yes
10-1F	1	no

J8

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
J8	J8	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
	0	yes
	1	no

J9 Power On RAM

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
J9 Power On RAM	J9	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Enabled	0	no
Disabled	1	yes

Data Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Data Bits	rs232b:terminal:RS232_DATABITS	255

setting

name	value	default
5	0	no
6	1	no
7	2	no
8	3	yes

Parity

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Parity	rs232b:terminal:RS232_PARITY	255

setting

name	value	default
None	0	yes
Odd	1	no
Even	2	no
Mark	3	no
Space	4	no

RX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
RX Baud	rs232b:terminal:RS232_RXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
111900	22	no
115200	13	no

Stop Bits

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Stop Bits	rs232b:terminal:RS232_STOPBITS	255

setting

name	value	default
0	0	no
1	1	yes
1.5	2	no
2	3	no

TX Baud

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
TX Baud	rs232b:terminal:RS232_TXBAUD	255

setting

name	value	default
50	14	no
75	15	no
110	0	no
134.5	16	no
150	1	no
200	17	no
300	2	no
600	3	no
1200	4	no
1800	18	no
2000	19	no
2400	5	no
3600	20	no
4800	6	no
7200	21	no
9600	7	yes
14400	8	no
19200	9	no
28800	10	no
38400	11	no
57600	12	no
111900	22	no
115200	13	no

Cursor

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Cursor	rs232b:terminal:TERM_CONF	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	1	yes

Type

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Type	rs232b:terminal:TERM_CONF	2

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
Underline	0	no
Block	2	yes

Blinking

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Blinking	rs232b:terminal:TERM_CONF	4

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	4	yes

Invert

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Invert	rs232b:terminal:TERM_CONF	8

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	8	yes

Color

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Color	rs232b:terminal:TERM_CONF	48

setting

name	value	default
Green	0	yes
Amber	16	no
White	32	no

Auto CR on LF

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto CR on LF	rs232b:terminal:TERM_CONF	64

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	no
Yes	64	yes

Auto LF on CR

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Auto LF on CR	rs232b:terminal:TERM_CONF	128

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	128	no

Local echo

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Local echo	rs232b:terminal:TERM_CONF	256

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
No	0	yes
Yes	256	no

Layout

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Layout	rs232b:terminal:keyboard:GENKBD_CFG	1

setting

name	value	default	condition_tag	condition_mask	condition_relation	condition_value
ANSI	0	yes
JIS	1	no

Typematic Delay

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Delay	rs232b:terminal:keyboard:GENKBD_CFG	6

setting

name	value	default
0.25s	0	no
0.5s	2	no
0.75s	4	yes
1.0s	6	no

Typematic Rate

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Typematic Rate	rs232b:terminal:keyboard:GENKBD_CFG	248

setting

name	value	default
2.0cps	0	no
2.1cps	8	no
2.5cps	16	no
2.7cps	24	no
2.0cps	32	no
2.1cps	40	no
2.5cps	48	no
2.7cps	56	no
3.3cps	64	no
3.8cps	72	no
4.0cps	80	no
4.3cps	88	no
4.6cps	96	no
5.0cps	104	no
5.5cps	112	no
6.0cps	120	no
8.0cps	128	no
8.6cps	136	no
9.2cps	144	no
10.0cps	152	yes
10.9cps	160	no
12.0cps	168	no
13.3cps	176	no
15.0cps	184	no
16.0cps	192	no
17.1cps	200	no
18.5cps	208	no
20.0cps	216	no
21.8cps	224	no
24.0cps	232	no
26.7cps	240	no
30.0cps	248	no

dipswitch

Serial Port A

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Serial Port A	DSW0	15

value

name	value	default
50 baud	0	no
75 baud	1	no
110 baud	2	no
134.5 baud	3	no
150 baud	4	no
300 baud	5	yes
600 baud	6	no
1200 baud	7	no
1800 baud	8	no
2000 baud	9	no
2400 baud	10	no
3600 baud	11	no
4800 baud	12	no
7200 baud	13	no
9600 baud	14	no
19200 baud	15	no

Serial Port B

name	tag	mask	condition_tag	condition_mask	condition_relation	condition_value
Serial Port B	DSW0	240

value

name	value	default
50 baud	0	no
75 baud	16	no
110 baud	32	no
134.5 baud	48	no
150 baud	64	no
300 baud	80	no
600 baud	96	no
1200 baud	112	no
1800 baud	128	no
2000 baud	144	no
2400 baud	160	no
3600 baud	176	no
4800 baud	192	no
7200 baud	208	no
9600 baud	224	yes
19200 baud	240	no
